Icom IC-80AD Service Manual page 33

[MAIN UNIT]
REF PARTS
DESCRIPTION
NO. NO.
IC100 1110003201 S.IC TA31136FNG(EL)
IC150 1110006380 S.IC LM2904PWR
IC500 1130011770 S.IC CD4066BPWR
IC501 1110003800 S.IC NJM2904V-TE1-#FMZB
IC600 1190002930 S.IC BU2502MUV-E2
IC701 1130011760 S.IC CD4094BPWR
IC702 1130011760 S.IC CD4094BPWR
IC800 1110006380 S.IC LM2904PWR
IC1000 1130009981 S.IC TC7W53FK(TE85L,F)
Q1 1530002601 S.TRA 2SC4215-O(TE85R,F)
Q2 1530002601 S.TRA 2SC4215-O(TE85R,F)
Q100 1530002601 S.TRA 2SC4215-O(TE85R,F)
Q101 1590003291 S.TRA UNR9213G0L
Q102 1590002010 S.TRA XP1114(TX)
Q103 1590001190 S.TRA XP6501-(TX).AB
Q104 1590001190 S.TRA XP6501-(TX).AB
Q105 1590003251 S.TRA UNR9115G0L
Q150 1590003251 S.TRA UNR9115G0L
Q152 1590003291 S.TRA UNR9213G0L
Q153 1590003251 S.TRA UNR9115G0L
Q154 1590003431 S.TRA UNR911HG0L
Q159 1590003291 S.TRA UNR9213G0L
Q200 1590003291 S.TRA UNR9213G0L
Q201 1590002010 S.TRA XP1114(TX)
Q450 1530002601 S.TRA 2SC4215-O(TE85R,F)
Q451 1530002601 S.TRA 2SC4215-O(TE85R,F)
Q452 1530003630 S.TRA 2SC4617 TLS
Q500 1590003281 S.TRA UNR9211G0L
Q552 1530004000 S.TRA 2SC4738-GR(TE85L,F)
Q700 1550000160 S.FET CPH3313-TL-E
Q701 1590003291 S.TRA UNR9213G0L
Q800 1510001100 S.TRA 2SA1832-GR(TE85R,F)
Q801 1590003291 S.TRA UNR9213G0L
Q803 1590003281 S.TRA UNR9211G0L
Q804 1520000460 S.TRA 2SB1132 T100 R
Q805 1590001170 S.TRA XP1501-(TX).AB
D2 1750001070 S.DIO DAN235ETL
D3 1750001070 S.DIO DAN235ETL
D4 1790000980 S.DIO MA742(TX)
D10 1750001210 S.DIO HSB88ASTR-E
D100 1790001241 S.DIO MA2S7280GL
D102 1790001251 S.DIO MA2S1110GL
D103 1790001251 S.DIO MA2S1110GL
D104 1790001241 S.DIO MA2S7280GL
D105 1790001251 S.DIO MA2S1110GL
D106 1790001251 S.DIO MA2S1110GL
D150 1790001251 S.DIO MA2S1110GL
D151 1790001251 S.DIO MA2S1110GL
D450 1750001070 S.DIO DAN235ETL
D700 1790001241 S.DIO MA2S7280GL
D800 1730002261 S.ZEN MAZ8030GHL
FI2 2020001800 S.CER SFECV13M3DA0001-R0
(SFECV13.35M)
FI50 2030000720 S.MON FL-429 MFT61.6M 61.650 MHz
FI100 2020002490 CER LTM450EW <JJE>
FI200 2020002570 CER LTM450HW <JJE>
X100 6070000300 S.DIS JTBM450CX24 <JJE>
X450 6050012830 S.XTA CR-875 TTS14VSB-A4 15.3 MHz
L1 6200005140 S.COI MLF1608D R33K-T
L10 6200010381 S.COI ELJRE R15JFA
L30 6200009181 S.COI ELJRE R10JFA
L100 6200007170 S.COI MLF1608A 3R3K-T
L101 6200003131 S.COI NLV32T-120J
L450 6200005190 S.COI MLF1608D R56K-T
L451 6200005190 S.COI MLF1608D R56K-T
L452 6200003540 S.COI MLF1608D R22K-T
L453 6200003630 S.COI MLF1608D R68K-T
L454 6200003630 S.COI MLF1608D R68K-T
R6 7030007290 S.RES ERJ2GEJ 222 X (2.2K)
R7 7030007290 S.RES ERJ2GEJ 222 X (2.2K)
R8 7030004990 S.RES ERJ2GEJ 221 X (220)
R9 7030004990 S.RES ERJ2GEJ 221 X (220)
R10 7030007290 S.RES ERJ2GEJ 222 X (2.2K)
R11 7030007290 S.RES ERJ2GEJ 222 X (2.2K)
R14 7030009200 S.RES ERJ2GEJ 390 X (39)
R15 7030005170 S.RES ERJ2GEJ 474 X (470K)
R16 7030004980 S.RES ERJ2GEJ 101 X (100)
R17 7030005170 S.RES ERJ2GEJ 474 X (470K)
7030005170 S.RES ERJ2GEJ 474 X (470K)
7030005170 S.RES ERJ2GEJ 474 X (470K)
7030005090 S.RES ERJ2GEJ 104 X (100K)
7030005170 S.RES ERJ2GEJ 474 X (470K)
7030005170 S.RES ERJ2GEJ 474 X (470K)
7030005170 S.RES ERJ2GEJ 474 X (470K)
7030005170 S.RES ERJ2GEJ 474 X (470K)
7030005170 S.RES ERJ2GEJ 474 X (470K)
7030005170 S.RES ERJ2GEJ 474 X (470K)
R18 7030007280 S.RES ERJ2GEJ 331 X (330)
7030007280 S.RES ERJ2GEJ 331 X (330)
7030007280 S.RES ERJ2GEJ 331 X (330)
7030007570 S.RES ERJ2GEJ 122 X (1.2K)
7030007280 S.RES ERJ2GEJ 331 X (330)
All manuals and user guides at all-guides.com
[MAIN UNIT]
H/V REF
M.
LOCATION
B 47.3/27.4 R18
B 18.3/29.3
B 18.4/40.5
B 18.3/20.3
T 22.2/16.8
B 12.5/9 R19
T 12.5/9.1 R23
B 34/15.9 R24
T 28.6/30.9 R25
T 27/21.6
T 31/27.4
B 47.2/37.9
T 40.4/33.4
T 42.7/34.2
B 31.8/34.1
B 25.5/38.9
T 24.7/38.4 R55
T 20.3/38.9 R100
B 44/33.6 R101
B 39.9/13.9 R102
B 23/20.9 R104
T 42.4/27.7 R105
T 33.9/43.4 R106
T 36.5/42.8 R107
B 35.4/8.2 R108
B 41.7/9.2 R109
B 45.7/7.1 R110
B 13/15.9 R111
T 18.6/32.3 R112
T 4.8/43.1 R113
T 4.6/39.4 R114
B 32.3/8.2 R115
B 30.9/13.1 R116
T 30.7/16.7 R117
T 31.8/9.4 R119
T 33.8/15 R120
R121
R122
B 25.8/20.1 R123
B 37.8/35.9 R124
B 35.6/36.8 R125
T 29.3/23.4 R126
T 30.3/35.3 R127
B 48.8/15.7 R129
B 48.8/19.1 R130
B 26.4/35.3 R133
B 47.6/15.7 R150
B 47.6/19.1 R151
B 42.2/15.6 R152
B 42.2/19 R153
B 48/13.3 R154
T 8.1/43.6 R155
B 35.6/25.3 R156
R157
R158
R159
B 37.1/32.5 R161
B 27.6/27.6 R162
R163
R164
R165
R166
T 47.5/35.8 R190
T 46.4/8.3 R210
R217
R218
T 27.3/24.5 R219
B 27.2/17 R260
B 28.4/17 R450
B 48.7/35.1 R451
T 41.8/37 R452
B 43.7/8.2 R453
B 45.2/10.8 R455
B 47.4/6.2 R456
B 48.5/9.8 R457
B 47.4/8.1 R458
R459
B 26.6/22
B 28.7/20.8
B 29/22.2
B 27.5/32.5
B 29.3/33.4
B 38.7/37.2
B 29.5/19.2
T 28.7/20.5
T 27.8/26.3 R460
[EUR] T 28.3/27.5 R470
[UK] R471
[ITR] R473
[USA] R474
[FRA] R475
[SEA] R500
[CHN] R501
[KOR] R502
[AUS] R503
[EXP] R504
[EUR] T 27.4/27.5 R505
[UK] R506
[ITR] R507
[USA] R508
[FRA] R509
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
6 - 5
PARTS
DESCRIPTION
NO. NO.
7030007280 S.RES ERJ2GEJ 331 X (330)
7030007280 S.RES ERJ2GEJ 331 X (330)
7030007280 S.RES ERJ2GEJ 331 X (330)
7030007280 S.RES ERJ2GEJ 331 X (330)
7030007280 S.RES ERJ2GEJ 331 X (330)
7030007290 S.RES ERJ2GEJ 222 X (2.2K)
7030010040 S.RES ERJ2GEJ-JPW
7030007280 S.RES ERJ2GEJ 331 X (330)
7030005290 S.RES ERJ2GEJ 682 X (6.8K)
7030005290 S.RES ERJ2GEJ 682 X (6.8K)
7030005290 S.RES ERJ2GEJ 682 X (6.8K)
7030005050 S.RES ERJ2GEJ 103 X (10K)
7030005290 S.RES ERJ2GEJ 682 X (6.8K)
7030005290 S.RES ERJ2GEJ 682 X (6.8K)
7030005290 S.RES ERJ2GEJ 682 X (6.8K)
7030005290 S.RES ERJ2GEJ 682 X (6.8K)
7030005290 S.RES ERJ2GEJ 682 X (6.8K)
7030005290 S.RES ERJ2GEJ 682 X (6.8K)
7030005120 S.RES ERJ2GEJ 102 X (1K)
7030008290 S.RES ERJ2GEJ 183 X (18K)
7030008410 S.RES ERJ2GEJ 392 X (3.9K)
7030004990 S.RES ERJ2GEJ 221 X (220)
7030004990 S.RES ERJ2GEJ 221 X (220)
7030007570 S.RES ERJ2GEJ 122 X (1.2K)
7030007570 S.RES ERJ2GEJ 122 X (1.2K)
7030005240 S.RES ERJ2GEJ 473 X (47K)
7030005030 S.RES ERJ2GEJ 152 X (1.5K)
7030005720 S.RES ERJ2GEJ 563 X (56K)
7030007340 S.RES ERJ2GEJ 153 X (15K)
7030005100 S.RES ERJ2GEJ 154 X (150K)
7030005120 S.RES ERJ2GEJ 102 X (1K)
7030005310 S.RES ERJ2GEJ 124 X (120K)
7030008010 S.RES ERJ2GEJ 123 X (12K)
7030005050 S.RES ERJ2GEJ 103 X (10K)
7030005050 S.RES ERJ2GEJ 103 X (10K)
7030009290 S.RES ERJ2GEJ 562 X (5.6K)
7030008010 S.RES ERJ2GEJ 123 X (12K)
7030005030 S.RES ERJ2GEJ 152 X (1.5K)
7030005120 S.RES ERJ2GEJ 102 X (1K)
7030005240 S.RES ERJ2GEJ 473 X (47K)
7030005100 S.RES ERJ2GEJ 154 X (150K)
7030005170 S.RES ERJ2GEJ 474 X (470K)
7030005600 S.RES ERJ2GEJ 273 X (27K)
7030005060 S.RES ERJ2GEJ 333 X (33K)
7030005040 S.RES ERJ2GEJ 472 X (4.7K)
7030004980 S.RES ERJ2GEJ 101 X (100)
7030007340 S.RES ERJ2GEJ 153 X (15K)
7030007350 S.RES ERJ2GEJ 393 X (39K)
7030005050 S.RES ERJ2GEJ 103 X (10K)
7030005090 S.RES ERJ2GEJ 104 X (100K)
7030005080 S.RES ERJ2GEJ 823 X (82K)
7030005080 S.RES ERJ2GEJ 823 X (82K)
7030005080 S.RES ERJ2GEJ 823 X (82K)
7030005230 S.RES ERJ2GEJ 334 X (330K)
7030005100 S.RES ERJ2GEJ 154 X (150K)
7030005070 S.RES ERJ2GEJ 683 X (68K)
7030005240 S.RES ERJ2GEJ 473 X (47K)
7030005160 S.RES ERJ2GEJ 105 X (1M)
7030005090 S.RES ERJ2GEJ 104 X (100K)
7030005050 S.RES ERJ2GEJ 103 X (10K)
7030005050 S.RES ERJ2GEJ 103 X (10K)
7030005060 S.RES ERJ2GEJ 333 X (33K)
7030005030 S.RES ERJ2GEJ 152 X (1.5K)
7030005050 S.RES ERJ2GEJ 103 X (10K)
7030005090 S.RES ERJ2GEJ 104 X (100K)
7030007290 S.RES ERJ2GEJ 222 X (2.2K)
7030005050 S.RES ERJ2GEJ 103 X (10K)
7030009140 S.RES ERJ2GEJ 272 X (2.7K)
7030005120 S.RES ERJ2GEJ 102 X (1K)
7030005090 S.RES ERJ2GEJ 104 X (100K)
7030007060 S.RES ERJ2GEJ 684X (680K)
7030007340 S.RES ERJ2GEJ 153 X (15K)
7030008300 S.RES ERJ2GEJ 184 X (180K)
7030005090 S.RES ERJ2GEJ 104 X (100K)
7030004980 S.RES ERJ2GEJ 101 X (100)
7030005070 S.RES ERJ2GEJ 683 X (68K)
7030005080 S.RES ERJ2GEJ 823 X (82K)
7030005120 S.RES ERJ2GEJ 102 X (1K)
7030005000 S.RES ERJ2GEJ 471 X (470)
7030005000 S.RES ERJ2GEJ 471 X (470)
7030005000 S.RES ERJ2GEJ 471 X (470)
7030007290 S.RES ERJ2GEJ 222 X (2.2K)
7030005000 S.RES ERJ2GEJ 471 X (470)
7030005000 S.RES ERJ2GEJ 471 X (470)
7030005000 S.RES ERJ2GEJ 471 X (470)
7030005000 S.RES ERJ2GEJ 471 X (470)
7030005000 S.RES ERJ2GEJ 471 X (470)
7030005000 S.RES ERJ2GEJ 471 X (470)
7030005090 S.RES ERJ2GEJ 104 X (100K)
7030008280 S.RES ERJ2GEJ 271 X (270)
7030008300 S.RES ERJ2GEJ 184 X (180K)
7030005050 S.RES ERJ2GEJ 103 X (10K)
7030005040 S.RES ERJ2GEJ 472 X (4.7K)
7030005050 S.RES ERJ2GEJ 103 X (10K)
7030005090 S.RES ERJ2GEJ 104 X (100K)
7030005120 S.RES ERJ2GEJ 102 X (1K)
7030008010 S.RES ERJ2GEJ 123 X (12K)
7030007340 S.RES ERJ2GEJ 153 X (15K)
7030007060 S.RES ERJ2GEJ 684X (680K)
7030005110 S.RES ERJ2GEJ 224 X (220K)
7030005090 S.RES ERJ2GEJ 104 X (100K)
7030005220 S.RES ERJ2GEJ 223 X (22K)
7030005220 S.RES ERJ2GEJ 223 X (22K)
7030005220 S.RES ERJ2GEJ 223 X (22K)
H/V
M.
LOCATION
[SEA] T 27.4/27.5
[CHN]
[KOR]
[AUS]
[EXP]
B 36.5/40.4
B 34.5/29.4
B 38.7/29.8
[EUR] T 31.5/25.5
[UK]
[ITR]
[USA]
[FRA]
[SEA]
[CHN]
[KOR]
[AUS]
[EXP]
B 27.7/5.4
B 46.8/33.9
B 46.3/35.2
B 44.9/38.1
B 45.4/36
T 42.6/39.3
T 51.3/34.8
B 48.7/32.7
B 48.3/23.1
T 45.7/28.3
T 44.1/27.4
T 45.7/26.5
T 44.1/26.5
T 45/24.1
T 48.2/23.2
B 50.1/17.4
B 50.1/18.3
B 48.4/17.4
B 47.7/20.7
B 28.4/36
B 28.4/36.9
B 32.2/36
B 29.9/34.7
B 26.1/36.3
B 23.9/42.3
B 22.2/42.3
B 22.2/40.4
T 26.2/37.8
B 29/34.6
B 18.4/44.8
B 20.7/35.9
B 21.9/36.6
B 19.5/35.8
B 19.1/34.6
B 17.8/34.1
B 15.5/27.3
B 14/31.6
B 14.9/31.6
B 14.8/30.4
B 13.7/29.2
B 12.5/28.7
B 41/17.9
B 41/16.6
T 43.4/29.2
B 45.4/34.3
T 51.3/23.7
T 23.9/37.1
B 17.4/15.2
T 18.9/23.1
B 12.9/44.8
B 13.4/43.6
B 22.1/38.7
T 50/8.3
T 44/11.7
T 46.1/11.3
T 49.4/11.3
B 37.6/8.4
B 38.1/7.2
B 36.1/5.9
B 35.2/5.9
[EUR] B 42.5/6.6
[UK]
[ITR]
[USA]
[FRA]
[SEA]
[CHN]
[KOR]
[AUS]
[EXP]
B 41.3/7.5
B 48.5/5.1
B 45.3/5.5
B 45.7/12.7
B 45.7/14.2
B 49.2/11.3
B 12.1/19.4
B 12.5/20.7
B 12.2/22
B 15/23.8
B 18.2/24.6
B 14.6/20.8
B 14.6/19
B 15.5/17.8
B 15.5/16.2
B 15.9/14.9
S.=Surface mount
