Icom IC-80AD Service Manual page 37

[LOGIC UNIT]
REF PARTS
DESCRIPTION
NO. NO.
C116 4030017490 S.CER C1608 JB 1A 105K-T
C117 4030017460 S.CER ECJ0EB1E102K
C118 4030016930 S.CER ECJ0EB1A104K
C119 4030017400 S.CER ECJ0EC1H220J
C120 4030017700 S.CER ECJ0EC1H151J
C121 4030016790 S.CER ECJ0EB1C103K
C123 4030017460 S.CER ECJ0EB1E102K
C124 4030016930 S.CER ECJ0EB1A104K
C150 4030017460 S.CER ECJ0EB1E102K
C151 4030017460 S.CER ECJ0EB1E102K
C152 4030017460 S.CER ECJ0EB1E102K
C214 4030017460 S.CER ECJ0EB1E102K
C215 4030017460 S.CER ECJ0EB1E102K
C216 4030017460 S.CER ECJ0EB1E102K
C217 4030017460 S.CER ECJ0EB1E102K
C219 4030017460 S.CER ECJ0EB1E102K
C220 4030017460 S.CER ECJ0EB1E102K
C221 4030017460 S.CER ECJ0EB1E102K
C222 4030017460 S.CER ECJ0EB1E102K
C223 4550007940 S.TAN TCP0J226M8R
C300 4030018860 S.CER ECJ0EB0J105K
C301 4030017460 S.CER ECJ0EB1E102K
C302 4030017460 S.CER ECJ0EB1E102K
C303 4030016950 S.CER ECJ0EB1A473K
C304 4030017460 S.CER ECJ0EB1E102K
C305 4030016790 S.CER ECJ0EB1C103K
C306 4030018860 S.CER ECJ0EB0J105K
C307 4030017460 S.CER ECJ0EB1E102K
C308 4030019460 S.CER C1608 JB 0J 106M-T
C309 4030016930 S.CER ECJ0EB1A104K
C310 4030019460 S.CER C1608 JB 0J 106M-T
C311 4030016930 S.CER ECJ0EB1A104K
C312 4030016930 S.CER ECJ0EB1A104K
C313 4030018860 S.CER ECJ0EB0J105K
C314 4030016930 S.CER ECJ0EB1A104K
C315 4030017770 S.CER ECJ0EB1E332K
C316 4030016790 S.CER ECJ0EB1C103K
C317 4030016930 S.CER ECJ0EB1A104K
C318 4030017460 S.CER ECJ0EB1E102K
C319 4030016930 S.CER ECJ0EB1A104K
C320 4030016790 S.CER ECJ0EB1C103K
C321 4030019460 S.CER C1608 JB 0J 106M-T
C322 4030017460 S.CER ECJ0EB1E102K
C324 4030017460 S.CER ECJ0EB1E102K
C325 4030016950 S.CER ECJ0EB1A473K
C326 4030018390 S.CER ECJ0EB1A563K
C327 4030017920 S.CER ECJ0EB1A683K
C328 4030018860 S.CER ECJ0EB0J105K
C329 4030017710 S.CER ECJ0EC1H181J
C330 4030017460 S.CER ECJ0EB1E102K
C331 4030018860 S.CER ECJ0EB0J105K
C332 4030016790 S.CER ECJ0EB1C103K
C333 4550007940 S.TAN TCP0J226M8R
C334 4030018110 S.CER ECJ0EB1H272K
C335 4030018140 S.CER ECJ0EB1H391K
C336 4030019460 S.CER C1608 JB 0J 106M-T
C337 4030017920 S.CER ECJ0EB1A683K
C338 4030017040 S.CER ECJ0EB1A333K
C339 4030017460 S.CER ECJ0EB1E102K
C340 4030017040 S.CER ECJ0EB1A333K
C341 4030016960 S.CER ECJ0EB1C183K
C342 4030017460 S.CER ECJ0EB1E102K
C343 4030018860 S.CER ECJ0EB0J105K
C344 4030017460 S.CER ECJ0EB1E102K
C347 4030017460 S.CER ECJ0EB1E102K
C400 4030017460 S.CER ECJ0EB1E102K
C401 4030017460 S.CER ECJ0EB1E102K
C403 4030017460 S.CER ECJ0EB1E102K
C404 4030017460 S.CER ECJ0EB1E102K
C405 4030018860 S.CER ECJ0EB0J105K
C408 4030017460 S.CER ECJ0EB1E102K
C409 4030016930 S.CER ECJ0EB1A104K
C412 4550006250 S.TAN TEESVA 1A 106M8R
C413 4030016930 S.CER ECJ0EB1A104K
C414 4510009340 S.ELE EEEHA1C101WP
C415 4030016950 S.CER ECJ0EB1A473K
C416 4510009020 S.ELE EEE0JA331P
C417 4030017460 S.CER ECJ0EB1E102K
C418 4030017460 S.CER ECJ0EB1E102K
C420 4510008040 S.ELE EEFCD 0K 330R
C421 4030018520 S.CER C1608 JB 0J 225M-T
C422 4030017420 S.CER ECJ0EC1H470J
C423 4030016930 S.CER ECJ0EB1A104K
C500 4030016930 S.CER ECJ0EB1A104K
C501 4030017460 S.CER ECJ0EB1E102K
C503 4030017460 S.CER ECJ0EB1E102K
C504 4030016930 S.CER ECJ0EB1A104K
C505 4030016930 S.CER ECJ0EB1A104K
C506 4030017460 S.CER ECJ0EB1E102K
C507 4030017400 S.CER ECJ0EC1H220J
C508 4030018860 S.CER ECJ0EB0J105K
C509 4030017460 S.CER ECJ0EB1E102K
C510 4030016930 S.CER ECJ0EB1A104K
C511 4030016930 S.CER ECJ0EB1A104K
C512 4030017030 S.CER ECJ0EB1A273K
C513 4030017030 S.CER ECJ0EB1A273K
C514 4030017460 S.CER ECJ0EB1E102K
C515 4030016930 S.CER ECJ0EB1A104K
C516 4030017760 S.CER ECJ0EB1H222K
C517 4030016930 S.CER ECJ0EB1A104K
C518 4030016930 S.CER ECJ0EB1A104K
C519 4030018520 S.CER C1608 JB 0J 225M-T
C520 4030017420 S.CER ECJ0EC1H470J
C521 4030019460 S.CER C1608 JB 0J 106M-T
All manuals and user guides at all-guides.com
[LOGIC UNIT]
H/V REF
M.
LOCATION
T 52.5/43.6 C522
T 51.1/43.7 C523
B 80.9/49.4 C524
B 86.9/50.6 C525
B 88.6/41.7 C526
B 88.6/20.5 C527
B 90.3/29.7 C528
B 89.4/29.7 C529
B 86.4/3.8 C530
T 49.3/21.2 C531
T 45.4/23.3 C532
T 37.6/12.4 C534
T 35.9/12.4 C535
T 38.3/14.6 C536
T 51.1/50.1 C537
T 56/49.1 C538
T 2.8/24.8 C539
T 2.4/32.4 C540
T 2.3/26.5 C541
T 54.6/49.7 C542
B 28.2/43.8 C543
B 28.7/47.3 C544
B 28.7/48.2 C545
B 27.3/43.8 C546
B 32.1/42 C547
B 31.6/44.5 C548
B 34.7/47.1 C549
B 35.6/47.1 C550
B 31.9/46.6 C551
B 34.6/45 C552
B 39/45.2 C553
B 34.3/42.8 C554
B 34.7/39.6 C555
B 37.9/39.6 C556
B 30.6/34 C557
B 28.8/35.5 C558
B 29.7/36.3 C603
B 33.9/37.8 C606
B 30.6/38.6 C607
B 34.7/32.8 C608
B 36.2/37.6 C609
B 38/35.9 C610
B 43.8/19.1
B 44.7/19.1
B 37.1/31.9 J1
B 35.9/30.5 J2
B 41.9/22.8 J50
B 41.9/21.8 J600
B 41.5/24.4
B 43.6/25.1
B 40.6/29.1 DS1
B 41.5/26.5 DS201
B 42.9/27.2 DS202
B 37.3/21.7 DS203
B 34.3/22.9 DS204
B 41.6/20.5 DS205
B 31.2/31.3 DS206
B 30.9/32.5 DS207
B 28/32.2 DS208
B 32.8/25.8 DS209
B 30.1/24.1 DS210
B 29.4/28.8 DS211
B 32.8/29.1 DS212
B 30.6/25.3
B 37/34.7
B 38.1/10.1 MC300
B 55.5/5
B 26.3/4.9
B 28.7/3.4 SP1
B 29.6/3.4
B 46.4/14.3
B 31.8/36.1 W1
B 50/23.6 W2
B 46.4/15.2
B 42.1/14.6
B 57.4/18.2
B 44.8/5.6 EP50
B 38.8/5 EP51
B 53.6/34.4 EP52
B 30.3/18.6 EP53
B 27.7/3.9 EP100
B 57.3/20.2 EP101
B 47.5/18.6 EP102
B 71.9/10.5 EP500
B 66.5/11.4 EP501
B 66.3/12.8 EP502
B 64.9/10.3 EP503
B 65.3/16.1 EP504
B 65.1/17.3 EP505
B 44.1/45.3 EP506
B 50.8/38.2 EP507
B 50.1/44.6 EP508
B 44.4/32.9 EP509
B 43.5/34.4
B 42.1/35.2
B 40.5/37.7 MP500
B 43.5/32.8 MP510
B 41/31.4
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
B 46.5/33.7
B 77.8/43.7
B 73.4/43.7
B 75.2/44
B 79/43.7
B 61.6/40.9
6 - 9
PARTS
DESCRIPTION
NO. NO.
4030016930 S.CER ECJ0EB1A104K
4030016930 S.CER ECJ0EB1A104K
4030016970 S.CER ECJ0EB1C223K
4030016950 S.CER ECJ0EB1A473K
4030016930 S.CER ECJ0EB1A104K
4030016930 S.CER ECJ0EB1A104K
4030018860 S.CER ECJ0EB0J105K
4030016930 S.CER ECJ0EB1A104K
4030016930 S.CER ECJ0EB1A104K
4030016930 S.CER ECJ0EB1A104K
4030017460 S.CER ECJ0EB1E102K
4030017460 S.CER ECJ0EB1E102K
4030016930 S.CER ECJ0EB1A104K
4030016930 S.CER ECJ0EB1A104K
4030016930 S.CER ECJ0EB1A104K
4030016930 S.CER ECJ0EB1A104K
4030016930 S.CER ECJ0EB1A104K
4030016930 S.CER ECJ0EB1A104K
4030016930 S.CER ECJ0EB1A104K
4030016930 S.CER ECJ0EB1A104K
4030016930 S.CER ECJ0EB1A104K
4030016930 S.CER ECJ0EB1A104K
4030016930 S.CER ECJ0EB1A104K
4030017420 S.CER ECJ0EC1H470J
4030017460 S.CER ECJ0EB1E102K
4030018520 S.CER C1608 JB 0J 225M-T
4030017460 S.CER ECJ0EB1E102K
4030017460 S.CER ECJ0EB1E102K
4030012610 S.CER C2012 JB 1C 474K-T
4030018860 S.CER ECJ0EB0J105K
4030018860 S.CER ECJ0EB0J105K
4030018860 S.CER ECJ0EB0J105K
4030018860 S.CER ECJ0EB0J105K
4030016930 S.CER ECJ0EB1A104K
4550007940 S.TAN TCP0J226M8R
4030019460 S.CER C1608 JB 0J 106M-T
4030017460 S.CER ECJ0EB1E102K
4030017460 S.CER ECJ0EB1E102K
4030016930 S.CER ECJ0EB1A104K
4030016930 S.CER ECJ0EB1A104K
4030016930 S.CER ECJ0EB1A104K
4030016930 S.CER ECJ0EB1A104K
6510025371 S.CON AXK816145WG
6510027160 S.CON IMSA-9631S-48Y923
6510024580 S.CON HSJ1621-019011
6510024132 S.CON IMSA-9637S-40Y905
5030003210 LCD A01B010X 3155 LCD
5040002670 S.LED CL-165HR/YG
5040003480 S.LED VFY1111C-4BX-4C-TR
5040003480 S.LED VFY1111C-4BX-4C-TR
5040003480 S.LED VFY1111C-4BX-4C-TR
5040003480 S.LED VFY1111C-4BX-4C-TR
5040003480 S.LED VFY1111C-4BX-4C-TR
5040003480 S.LED VFY1111C-4BX-4C-TR
5040003480 S.LED VFY1111C-4BX-4C-TR
5040003480 S.LED VFY1111C-4BX-4C-TR
5040003480 S.LED VFY1111C-4BX-4C-TR
5040003480 S.LED VFY1111C-4BX-4C-TR
5040003480 S.LED VFY1111C-4BX-4C-TR
7700002850 MIC EM6022P-65B-G <HOR>
2510001420 SPE PSC-2849PA <PRI>
7120000470 JUM ERDS2T0
8900007682 CAB OPC-741A-1(P0.5,N40,L55)
<TJM>
6910018460 S.BEA MMZ1005Y102C-T
6910018460 S.BEA MMZ1005Y102C-T
6910018460 S.BEA MMZ1005Y102C-T
6910018460 S.BEA MMZ1005Y102C-T
6910018460 S.BEA MMZ1005Y102C-T
6910018460 S.BEA MMZ1005Y102C-T
6910018460 S.BEA MMZ1005Y102C-T
6910018460 S.BEA MMZ1005Y102C-T
6910018460 S.BEA MMZ1005Y102C-T
6910018460 S.BEA MMZ1005Y102C-T
6910018460 S.BEA MMZ1005Y102C-T
6910018460 S.BEA MMZ1005Y102C-T
6910018460 S.BEA MMZ1005Y102C-T
6910018460 S.BEA MMZ1005Y102C-T
6910018460 S.BEA MMZ1005Y102C-T
6910018460 S.BEA MMZ1005Y102C-T
6910018460 S.BEA MMZ1005Y102C-T
8510017840 S.PLA OG-321610G
8510017840 S.PLA OG-321610G
H/V
M.
LOCATION
B 63/41.1
B 63.5/43.8
B 62.1/37.6
B 63.3/39.9
B 63.6/37
B 50.9/50
B 45.4/46.9
B 52.6/44.6
B 75.8/10.1
B 77.1/13.6
B 80.7/11
B 80.7/14.5
B 78.9/13.6
B 80.5/17.3
B 75.7/18.4
B 71.7/18.4
B 70.1/18.4
B 62.5/20.6
B 62.2/34.4
B 68.7/36.5
B 78.2/35.3
B 77/35.5
B 78.2/34.4
B 79.6/26.2
B 49.1/26
B 47.1/26
B 46/26.4
B 50.8/29.3
T 66.3/38.6
T 63.8/39.1
T 63.8/38.2
T 65.9/35.1
T 66.9/30.6
T 66/30.5
T 66.8/36.5
T 67.8/34.5
B 41.5/51.1
B 19.4/39.7
B 17.1/41.6
B 18/41.6
B 18.9/41.6
B 16.2/41.6
B 71.2/15.2
B 6.8/27
B 21.6/53.3
B 22.7/9.4
T 36.5/5.1
T 54.1/11.1
T 69.1/13.1
T 77.5/22.7
T 77.3/39.9
T 84.3/14.1
T 84.8/31.3
T 83.8/48.5
T 42.6/5.1
T 5.6/39.5
T 5.6/26.7
T 5.6/14
T 11.2/41
T 23.9/48.5
T 18.8/48.7
T 23.5/51.7
T 37.6/27.6
T 46.9/45.7
B 88.2/29.4
B 72.4/11.7
B 66.5/15.6
B 45.6/32.6
B 42.8/30.5
B 76.9/43.7
B 77.8/42
B 62.7/42.5
B 49.7/50.1
B 74.1/11.7
T 64.8/30.5
B 68.1/48.7
B 68.1/5.3
S.=Surface mount
