4K60 1:8 HDMI Splitter
SP-0108-SCL
WyreStorm recommends reading through this document in its entirety to become familiar with the product's features prior to starting the
installation process.
IMPORTANT! Installation
• Read through the
Wiring and Connections
wiring guidelines before creating or choosing premade cables.
• While this product supports CEC, WyreStorm cannot guarantee
compatibility with all forms of CEC communication.
• Visit the product page to download the latest firmware, document
version, additional documentation, and configuration tools.
Basic Wiring Diagram
KEY
HDMI
Power
Digital Audio
1080p Display
UHD Display
Troubleshooting
No or Poor Quality Picture (snow or noisy image)
• Verify that power is being supplied to the device.
• Verify that all HDMI connections are not loose and are functioning properly.
• Verify that the output resolution of the source and display is supported by
this device.
• Configure EDID Settings to a lower resolution.
• If transmitting 4K, verify that the HDMI cables used are 4K rated.
Warranty Information
WyreStorm Technologies ProAV Corporation warrants that its products to be free from defects in material and workmanship under normal use
for a period of five (5) years from the date of purchase. Refer to the Product Warranty page on
product warranty.
Copyright © 2022 WyreStorm
SP-0108-SCL Quickstart Guide | 220518
section for important
UHD Source
Power Supply
UHD Display
1080p Display
Pro AV Corporation
|
wyrestorm.com
In the Box
1x SP-0108-SCL Splitter
1x DC 12V PSU (US/UK/EU/AU)
2x 3-Pin Terminal Block
2x Wall Mounting Brackets (with Screws)
1x Quickstart Guide (This Document)
UHD Display
UHD Display
No or Intermittent 3rd party Device Control
• Verify that the RS-232 cables are properly terminated.
Troubleshooting Tips
• WyreStorm recommends using a cable tester or connecting the cable to
other devices to verify functionality.
wyrestorm.com
INT: +44 (0) 1793 230 343 | US: 844.280.WYRE (9973)
1 of 2
Quickstart Guide
Amplifier
UHD Display
1080p Display
for more details on our limited
