Wyrestorm CAB-HAOC-FRL-10 Quick Start Manual

48Gbps 8K/60 HDR 4:4:4 Active Optical HDMI Cable |
eARC, CEC, ALLM & VRR | ISF Certified (10m/33ft | 15m/49ft)
CAB-HAOC-FRL-10 | CAB-HAOC-FRL-15
WyreStorm recommends reading through this document in its entirety to become familiar with the product's features prior to starting the installation
process.
48GBPS

IMPORTANT! Installation Requirements

Cable is uni-directional. Follow the connector labeling and color coding to
ensure proper operation of the cable.

Cable Distances

CAB-HAOC-FRL-10

Wiring and Connections

IMPORTANT! Installation Requirements
The WyreStorm Active Optical cables are designed to transmit HDMI signals from the source to a display.
• Follow the labeling and the diagrams for connection to ensure proper operation.
• Due to the core of the HAOC being fiber optic the cable cannot have a bend radius greater than 2cm/0.78in.
Keep this mind when routing cables around objects and inside of walls.
• The cables have a max pull tension of 15kg/33lbs. Keep this in mind when routing the cable within cabinets
or walls to avoid damaging the cable.

Basic Wiring Diagram

Source Connection Label: TX SOURCE
Personal Computer
Media Player

Warranty Information

WyreStorm Technologies LLC warrants that its products to be free from defects in material and workmanship under normal use for a
period of five (5) years from the date of purchase. Refer to the
product warranty.
Copyright © 2020 WyreStorm Technologies |
CAB-HAOC-FRL-xx Quickstart Guide | 200330
Color: Gray
CAB-HAOC-FRL-10: 10m
CAB-HAOC-FRL-15: 15m
Product Warranty
wyrestorm.com

In The Box

1x CAB-HAOC-FRL-10 or CAB-HAOC-FRL-15 Active Optical HDMI Cable
2x Reusable Cable Ties
1x Quickstart Guide (This Document)
CAB-HAOC-FRL-15
Display Connection Label: TX DISPLAY
48GBPS
CAB-HAOC-FRL-15
page on wyrestorm.com
1 of 2
Quickstart Guide
Color: Gray
for more details on our limited
UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973)
support@wyrestorm.com
2.0 cm.
0.78 in.
