Wyrestorm SP-0102-H2 Quick Start Manual

1x2 4K HDMI Splitter with HDCP 2.2 Encryption
SP-0102-H2
Pure HDMI 1x2 splitter switch with support for full 4K resolutions and HDCP 2.2.
WyreStorm recommends reading through this document in its entirety to become familiar with the product's features prior to starting the installation
process.
In the Box
1x SP-0102-H2 Splitter
1x 12V DC 0.5A Power Supply
2x Mounting Brackets
1x Quickstart Guide (This Document)
Basic Wiring Diagram
12V DC 0.5A
Power Supply
HDMI to
display
UHD Display
IMPORTANT!
Disconnecting and connecting (hot plugging) HDMI or HDBaseT while devices
are powered on may cause damage. WyreStorm recommends powering off
devices before disconnecting these connections.
Copyright © 2016 WyreStorm Technologies |
SP-0102-H2 Quickstart Guide | 170117
UHD Source
KEY
HDMI
Power
HDMI to
display
UHD Display
wyrestorm.com
Additional Information
This Quickstart Guide provides the basic steps for the common uses of this
product. Refer to the Installation Guide and other documentation on the
product page for additional information.
Before Beginning
• WyreStorm recommends visiting the product page before installing this
product for updates to this Quickstart Guide as well as other information
about the product.
• Verify that all items are included in the packaging per the
Installation
1. Connect an HDMI source to the HDMI In on the splitter using an HDMI
cable from a high quality brand such as
2. Connect HDTV displays to Output 1 using an HDMI cable from a high
quality brand such as
3. Repeat step 2 for additional displays or additional splitters.
4. Connect the included 12V DC 0.5A power supply to the DC 12V jack.
North America: 518-289-1294 | EMEA/ROW: 44 (0) 1793 230 343
1 of 4
Quickstart Guide
WyreStorm Express.
WyreStorm Express.
support@wyrestorm.com
In the Box list.
