ENSIM SENSORS ELP Series Operating Manual page 6

2.7. Mechanical dimensions :
ELP 11
z
f
x
Closed
c
a
MODEL
Dimension
a
b
c
d
e
f
x
y
z
y
ELP 02a / 02b
z
f
x
Closed
ELP 02a ELP 03a
ELP 02b ELP 03b
Cylinder Cylinder
Ø18 Ø19 / Ø24
6 16
7 7
20 31
30 43
7 7
12 Hex 13 Hex
13 Hex 13 Hex
M8x1,55 M8x1,25
All dimensions are given in mm.
ELP 03a / 03b / 04a / 04b / 08a / 08b
Closed
y
c
a
ELP 04a ELP 08a
ELP 04b ELP 08b
Cylinder Cylinder
Ø24 Ø24
16 22
7 8,4
41 85
54 104
7 8
13 Hex 16 Hex
13 Hex 16 Hex
M10x1,25 M10x1,25
6
z
y
f
x
c
a
ELP 11
Cylinder
20
26
8.5
44
55
6
17 Hex
17 Hex
1/8" BSP
