ENSIM SENSORS ELP Series Operating Manual page 4

Level switch

Advertisement

Float Material
Wetted Parts Material
Float Type
Working Temperature
Max. Pressure (Bar)
Min. Density (g/cm 3 )
Electrical Connection
Number of Float
Number of Contact
Contact Current
Max. Contact Power
Max.Switching Voltage
Optional
LEVEL CONTROL DEVICE
Power Supply
Output
Working Temperature
Dimensions
Input
Isolation
1.5. Target Group
1.6. Security Notes
1.7. Content of Package
ELP 026
PP
PP
P10
(-)20/+80°C
Atm
7
Cable
1 Std.
SPST-NO
0,7 A
10 W / VA
180 VDC / 130 VAC
Liquid Level Relay
2 pcs.5A/250 VAC Relay (Start/Stop)
Contact Information , coming from ELP
Input and output are isolated
Float Material
Wetted Parts Material
Pipe Material
Float Type
Working Temperature
Mechanical Connection
Max. Pressure (Bar)
Min. Density (g/cm 3 )
Electrical Connection
Number of Float
Number of Contact
Contact Current
Max. Contact Power
Max.Switching Voltage
Optional
SK-P2
220 VAC, 2.8 VA
-20 + 70
o
C
72 x 72 mm
4
ELP 81p
PP
PP
PP
P81
(-)20/+80C
3/4" BSP
10
0.75
DIN43650C Socket
1 Std.
SPSTxNO
1 A
10 W / VA
200 VDC / 140 VAC
Liquid Level Relay
SK-P2
72 x 72 mm
