29CTF05BS
CHAPTER 1.
E
Market
29L-FG5RU
Service Manual
29L-FG5RU
TV
SPECIFICATIONS
[1] SPECIFICATIONS
Convergence ...............................................................................
Focus .....................................................................
Sweep De ection ...................................................................................................
Intermediate Frequencies
Picture IF Carrier ................................................................................................
Sound IF Carrier
6.5MHz ............................................................................................................
6.0MHz ............................................................................................................
5.5MHz ............................................................................................................
Colour Sub-Carrier
PAL ................................................................................................................
SECAM ..............................................................................................
Power Input
Power Consumption .....................................................................................................
Audio Power Output Rating
Speaker
Size ...........................................................................................................
Aerial Input Impedance
VHF/UHF .........................................................................................
Receiving Channels
PAL-B/G, SECAM-B/G
VHF ................................................................................................................
UHF ..............................................................................................................
CATV .........................................................................................
PAL-D/K, SECAM-D/K
VHF ..........................................................................................
UHF ..........................................................................................
PAL-I, SECAM-I
VHF ..................................................................................
UHF ..................................................................................
Receiving Frequency
Dimensions .....................................................................................................
Cabinet material ..................................................................................................
Speci cations are subject to change without prior notice.
SPECIFICATIONS
...................................................................................
......................................................................
................................................................
Self Convergence System
Bi-Potential, Uni-Potential Electrostatic
110 ~ 240 V AC 50/60 Hz
75 ohms Unbalanced
X thru Z + 2, S1 thru S41
R1 thru R12, C1 thru C12
21 thru 69, C21 thru C57
(IRELAND):
(U.K., H.K.):
44.25 MHz thru 863.25 MHz
Weight(approx): 41 kg
1 – 1
Magnetic
38.9 MHz
32.4 MHz
32.9 MHz
33.4 MHz
34.47 MHz
34.494/34.65 MHz
138 W
7.5 W x 2 (at Max.)
8 cm round x 2
E2 thru E12
E21 thru E69
B thru J
21 thru 69
Width: 810 mm
Height: 618 mm
Depth: 516.5 mm
All Plastics
