29CTF05BS
SETTING MODE 3
ITEM EEPROM SETTING
S301 FMI
S302 BPB
S303 BPB2
S304 FILTBW-M
S305 ID-BYBPF
S306 ID-PGAIN
S307 MPX-P-BW
S308 FMSUB-BW
S309 EIAJ-DEL
S310 NDETPB
S311 NICDEEM
S312 NLOERLIM
S313 NUPERLIM
S314 FILTBW
S315 OVMTHR
S316 DECLEV
S317 MONOLEV
S318 NICLEV
S319 SAPLEV
S320 ADCLEV
S321 IISLEV
S322 MAINLOUD
S323 MAINLONA
S324 MAINLOCH
S325 INSOEF
S326 AVLMOD
S327 AVLWGT
S328 AVLLE
S329 CLIPMANAGE
S330 VDSMIXLEV
S331 DBEADR
S332 DBECOEF-LBS
S333 DBECOEF-MBS
DATA RANGE IC
0/1 DSP
0/1 DSP
0/1 DSP
0...3 DSP
0/1 DSP
0/1 DSP
0/1 DSP
0/1 DSP
0...3 DSP
0/1 DSP
0/1 DSP
0...255 DSP
0...255 DSP
0...3 DSP
0...3 DSP
0...31 DSP
0...31 DSP
0...31 DSP
0...31 DSP
0...31 DSP
0...31 DSP
0/1 DSP
0...7 DSP
0...3 DSP
0...7 DSP
0...7 DSP
0/1 DSP
0...15 DSP
0...4 DSP
0...5 DSP
0...63 DSP
0...255 DSP
0...15 DSP
3 – 13
OSD INITIAL DATA
FMI 0
BPB 0
BPB2 1
FILTBW-M 0
ID-BYBPF 0
ID-PGAIN 0
MPX-P-BW 0
FMSUB-BW 0
EIAJ-DEL 0
NDETPB 0
NICDEEM 0
NLOERLIM 100
NUPERLIM 200
FILTBW 0
OVMTHR 1
DECLEV 16
MONOLEV 16
NICLEV 16
SAPLEV 16
ADCLEV 16
IISLEV 16
MAINLOUD 0
MAINLONA 0
MAINLOCH 0
INSOEF 3
AVLMOD 0
AVLWGT 1
AVLLE 7
CLIPMANAGE 0
VDSMIXLEV 3
DBEADR 0
DBECOEF-LBS 0
DBECOEF-MBS 0
SETTING DATA
0
0
1
0
0
0
0
0
0
0
0
100
200
0
1
13
12
18
16
15
16
0
0
0
3
5
1
8
3
3
0
0
0
