  • Page 1 Colour TV set 29CTF05BS Service manual...

  • Page 2: Table Of Contents

    Edition 29CTF05BS AKAI SERVICE MANUAL S461629LFG5RU COLOUR TELEVISION Chassis No. GB-5 29CTF05BS MODEL In the interests of user safety (Required by safety regulations in some countries) the set should be restored to its original condition and only parts indentical to those speci ed should be used.

  • Page 3: Chapter 1. Specifications

    29CTF05BS CHAPTER 1. 29L-FG5RU Service Manual 29L-FG5RU Market SPECIFICATIONS [1] SPECIFICATIONS SPECIFICATIONS Convergence ................Self Convergence System Focus ..............Bi-Potential, Uni-Potential Electrostatic Sweep De ection ....................Magnetic Intermediate Frequencies Picture IF Carrier ....................38.9 MHz Sound IF Carrier 6.5MHz ......................

  • Page 4: Chapter 2. Important Service Notes

    29CTF05BS CHAPTER 2. 29L-FG5RU Service Manual 29L-FG5RU Market IMPORTANT SERVICE NOTES [1] IMPORTANT SERVICE NOTES IMPORTANT SERVICE NOTES Maintenance and repairing of this receiver should be done by quali ed service personnel only. SERVICE OF HIGH VOLTAGE SYSTEM AND PICTURE TUBE...

  • Page 5: Chapter 3. Adjustment Precautions

    CHAPTER 3. 29L-FG5RU Service Manual 29L-FG5RU Market ADJUSTMENT PRECAUTIONS [1] ADJUSTMENT PRECAUTIONS ADJUSTMENT PRECAUTIONS This model's setting are adjusted in two di erent ways: through the I2C bus control and in the conventional analog manner. The adjustments via the I2C bus control include preset-only items and variable data.
  • Page 6 1) In the Service Mode, key is use to select the mode in the following order. ADJUSTMENT MODE 50Hz/60Hz RF AGC MENU button GEOMETRIC ADJ SETTING MODE 1 of R/C Picture Setting PICTURE CUT OFF/ SUB ADJ WHITE BALANCE ADJ MENU button of R/C MENU button...
  • Page 7 ADJUSTMENT MODE ITEMS SEQUENCE GEOMETRIC WHITE POINT PICTURE SUB ADJ ADJ MODE ADJ MODE MODE V SLOPE DRI-RS SUB-BRI VER-SHI-F50 DRI-GS SUB-BRI-DVD VER-AMP-F50 DRI-BS SUB-COL HOR-SHI-F50 CUT-RS SUB-CON EW-W-F50 CUT-GS SUB-CON-DVD E/W-PAR-F50 DRI-RC SUB-TINT-DVD H-PAR DRI-GC SUB-TINT H-BOW DRI-BC SUB-SHARP UPCOR-PAR CUT-RC LOCOR-PAR...
  • Page 8 OPTION MODE MENU ITEM SERVICE MODE EEPROM ITEM DATA INITIAL DATA SETTING DATA o i t o i t n i l z i l . . 0 . . 0 d l i n i l a l i a i r 3 –...
  • Page 9 ADJUSTMENT MODE ITEMS Note: SETTING DATA: for all model 29CTF05BS - only. ITEM EEPROM SETTING DATA RANGE INITIAL DATA SETTING DATA A001 RF-AGC 0…63 UOC-TV RF-AGC A002 V SLOPE 0…63 UOC-TV V SLOPE A003 VER-SHI-F50 0…63 UOC-TV VER-SHI-F50 A004 VER-AMP-F50 0…63...
  • Page 10 29CTF05BS ITEM EEPROM SETTING DATA RANGE INITIAL DATA SETTING DATA A034 SUB-TINT-DVD 0…63 UOC-TV SUB-TINT-DVD A035 DRI-RC 0…63 UOC-TV DRI-RC A036 DRI-GC 0…63 UOC-TV DRI-GC A037 DRI-BC 0…63 UOC-TV DRI-BC A038 CUT-RC 0…63 UOC-TV CUT-RC A039 CUT-GC 0…63 UOC-TV CUT-GC...
  • Page 11 29CTF05BS ITEM EEPROM SETTING DATA RANGE INITIAL DATA SETTING DATA A071 E/W-PAR-C50 0…63 UOC-TV E/W-PAR-C50 A072 SUB-SCROLL-C 0…63 UOC-TV SUB-SCROLL-C A073 SUB-VX-C50 0…63 UOC-TV SUB-VX-C50 A074 VER-SHI-P50 0…63 UOC-TV VER-SHI-P50 A075 VER-AMP-P50 0…63 UOC-TV VER-AMP-P50 A076 HOR-SHI-P50 0…63 UOC-TV HOR-SHI-P50...
  • Page 12 29CTF05BS ITEM EEPROM SETTING DATA RANGE INITIAL DATA SETTING DATA A108 UOC-TV A109 CUT OFF 0…63 UOC-TV CUT OFF A110 UOC-TV A111 DCXO 0…127 UOC-SSD DCXO A112 DCXO-AUTO UOC-SSD DCXO-AUTO 3 – 8...
  • Page 13 29CTF05BS SETTING MODE 1 ITEM EEPROM SETTING DATA RANGE INITIAL DATA SETTING DATA S001 V-LINCTRL 0…2 UOC-TV V-LINCTRL S002 IFPLL 0…63 UOC-TV IFPLL S003 SOC1-0 0…3 UOC-TV SOC1-0 S004 WHITE LMT 0…15 UOC-TV WHITE LMT S005 UOC-TV S006 AGC0-1 0…3...
  • Page 14 29CTF05BS ITEM EEPROM SETTING DATA RANGE INITIAL DATA SETTING DATA S035 CL3-0 0…15 UOC-TV CL3-0 S036 UOC-TV S037 UOC-TV S038 UOC-TV S039 UOC-TV S040 UOC-TV S041 AAS1-0 0…3 UOC-TV AAS1-0 S042 DSK-NOT-PAL-AV UOC-TV DSK-NOT-PAL-AV S043 UOC-TV S044 UOC-TV S045 UOC-TV...
  • Page 15 29CTF05BS ITEM EEPROM SETTING DATA RANGE INITIAL DATA SETTING DATA S073 OF-SHP-N3 0…31…62 UOC-TV OF-SHP-N3 S074 OF-TINT-TV 0…31…62 UOC-TV OF-TINT-TV S075 OF-TINT-AV 0…31…62 UOC-TV OF-TINT-AV S076 OF-TINT-DVD 0…31…62 UOC-TV OF-TINT-DVD S077 OF-TINT-ADJ 0…31…62 UOC-TV OF-TINT-ADJ S078 BB-TINT 0…63 UOC-TV BB-TINT...
  • Page 16 29CTF05BS ITEM EEPROM SETTING DATA RANGE INITIAL DATA SETTING DATA S111 SVM-OSD-PW 0…3 UOC-TV SVM-OSD-PW S112 SMD-OSD-TM 0…7 UOC-TV SMD-OSD-TM S113 UOC-TV S114 WBF-50-F-C-P 0…15 UOC-TV WBF-50-F-C-P S115 WBR-50-F-C-P 0…15 UOC-TV WBR-50-F-C-P S116 WBF-50SUBTITLE 0…15 UOC-TV WBF-50SUBTITLE S117 WBR-50-SUBTITLE 0…15...
  • Page 17 29CTF05BS SETTING MODE 3 ITEM EEPROM SETTING DATA RANGE INITIAL DATA SETTING DATA S301 S302 S303 BPB2 BPB2 S304 FILTBW-M 0…3 FILTBW-M S305 ID-BYBPF ID-BYBPF S306 ID-PGAIN ID-PGAIN S307 MPX-P-BW MPX-P-BW S308 FMSUB-BW FMSUB-BW S309 EIAJ-DEL 0…3 EIAJ-DEL S310 NDETPB...
  • Page 18 29CTF05BS ITEM EEPROM SETTING DATA RANGE INITIAL DATA SETTING DATA S334 DUBADR 0…255 DUBADR S335 DUBCOEF-LSB 0…255 DUBCOEF-LBS S336 DUBCOEF-MSB 0…15 DUBCOEF-MBS S337 BAMAMO 0…3 BAMAMO S338 BAMASUB BAMASUB S339 BAMAFC 0…15 BAMAFC S340 BASS-MV 0...31 BASS-MV S341 TREB-MV 0...31...
  • Page 19 29CTF05BS INITIAL SETTING (1) Execute MCL 1 or 2 key to set the following data in EEPROM. 48.25 AU-0 46.25 E-4/B-3 62.25 AU-2 64.25 OIR-3 77.25 AU-3 86.25 175.25 AU-4 95.25 E-6/B-5 182.25 AU-5A 138.25 OIR-7 183.25 AU-6 175.25 OIR-8 191.25...
  • Page 20 29CTF05BS *Remark: In MCL2 at position no. 1 (46.25MHz), current model are not able to set, this is because the minimum frequency for Tuner is 48.25MHz. 3 – 16...
  • Page 21 29CTF05BS MCL 1 (SREC/SRAC/SYI/STTM) MCL 2 (SREC-SCA) SKIP-OFF, FREQ-FREE AU-37 590.25 48.25 AU-0 *46.25 E-4/B-3 62.25 AU-2 64.25 OIR-3 77.25 AU-3 86.25 175.25 AU-4 95.25 E-6/B-5 182.25 AU-5A 138.25 OIR-7 183.25 AU-6 175.25 OIR-8 191.25 AU-7 182.25 E-8/B-7 196.25 AU-8 189.25...
  • Page 22 29CTF05BS MCL 1 (SREC/SRAC/SYI/STTM) MCL 2 (SREC-SCA) SKIP-OFF, FREQ-FREE E-64 815.25 SKIP-OFF, FREQ-FREE I-69 855.25 SKIP-OFF, FREQ-FREE JA-1 91.25 SKIP-OFF, FREQ-FREE JA-6 183.25 SKIP-OFF, FREQ-FREE JA-8 193.25 SKIP-OFF, FREQ-FREE JA-12 217.25 SKIP-OFF, FREQ-FREE US-14 471.25 SKIP-OFF, FREQ-FREE JA-50 693.25 SKIP-OFF, FREQ-FREE 112.25...
  • Page 23 29CTF05BS INITIAL 8 (CODE Edh) CH-No. Fv(MHz) S-SYS OI-42 639.25 OI-58 767.25 CHN/CA-53 831.25 JA-11 211.25 JA-12 217.25 JA-14 477.25 JA-50 693.25 WE-25 503.25 WE-28 527.25 WE-37 599.25 JPN-38 621.25 WE-64 815.25 3 – 19...
  • Page 24 29CTF05BS INITIAL 8 (CODE Edh) CH-No. Fv(MHz) S-SYS 3 – 20...
  • Page 25 29CTF05BS INITIAL SETTING (1) Execute the MCL 5 key to set the following data in EEPROM. 3 – 21...
  • Page 26 29CTF05BS SHIPPING SETTING & CHECKING (1) The following default data has been factory-setting for the EEPROM. Model-Set: The data in table below (1.1), Model set overview is updated to the respective EEPROM location base on RC key input Model Set 1~10.
  • Page 27 29CTF05BS (1) Refer to below table (2.1) for setting of each destination. MAGNETIC FIELD (V,H)nT BACKGROUND FACTORY SET 17000K SET 2 12300K SET 3 18000K SET 4 12300K SET 8 7500K SET 5 Table 2.1 (2) Refer to below table (2.2) for Normal setting of each AV mode.

  • Page 28: Adjustment

    29CTF05BS [2] ADJUSTMENT PIF ADJUSTMENT CHECKING RF-AGC (1) Receive "PAL COLOR BAR" signal. : h t ± µ o i t r i f a t l ± ADJUSTMENT Monitor point : TP53 Auto Adjustment Manual Adjustment (I2C BUS CONTROL) (2) Select "RF-AGC"...
  • Page 29 29CTF05BS UNIFORMITY Before adjustment begin,Horizontal magnetic eld = 0G ADJUSTMENT Vertical magnetic eld = Each destination's adjustment magnetic eld (To perform after the Make sure to degauss it. purity and convergence (North direction red uniformity) adjustment) (1) Horizontal mf = Set to monocolor screen red and adjust to +0.25G.
  • Page 30 29CTF05BS FOCUS ADJUSTMENT FOCUS 1. Receive E-5CH (Monoscop pattern). ADJUSTMENT 2. With the remote controller, make the image normal. 3. Adjust the focus VR to make the character "575" on left bottom of monoscope as ne as possible. CUT OFF, BKGD, SUB-CONT ADJUSTMENT...
  • Page 31 29CTF05BS CUT OFF, BKGD, SUB-CONT ADJUSTMENT CONTINUED WHITE BALANCE (1) Receive the internal RF monoscope pattern. BACKGROUND (2) Make the picture normal with the remote controller. ADJUSTMENT (4) Coarsely con rm the beam current to approx. 1.7mA. 18000K X : 0.255 Y : 0.255 .
  • Page 32 29CTF05BS HORIZONTAL, VERTICAL, DEFLECTION LOOP AND ADJUSTMENT MAIN SCREEN ADJUSTMENT . l o Refer to Fig 1-1. VER-AMP-F50 Adjust the ove Fig 1-1 g i l c i r A = Out of spec B = OK g i l...
  • Page 33 29CTF05BS PAL CHROMA ADJUSTMENT SUB COLOUR 1. Receive the "PAL Color Bar" signal. (I2C BUS CONTROL) 2. Make the image normal with the remote controller. 3. Connect the oscilloscope to TP47R (IC851 #9). ( Use Probe 10:1) Range : 2V / Div Sweep time: 20m sec / Div 4.
  • Page 34 29CTF05BS FUNCTION OPERATION CHECKING (1) (VIDEO & AUDIO) CONTRAST Key (1) Receive "Monoscope Pattern" signal. (2) Press to Menu mode, then select Picture Mode and set to select CONTRAST. (3) Press Volume Up/Down key to check whether the CONTRAST e ect is OK or not.
  • Page 35 29CTF05BS CHECKING FUNCTION OPERATION (2) (VIDEO & AUDIO) CONTINUED WAVEFORM OR REMARKS SOUND SYSTEM (1) Receive "PAL-D/K" signal, press the "SOUND SYSTEM" to select B/G, I. Check the sound output is not working properly. Select D/K and check the sound output to make sure it is working properly.

  • Page 36: Trouble Shooting Flowchart

    29CTF05BS CHAPTER 4. 29L-FG5RU Service Manual 29L-FG5RU Market TROUBLE SHOOTING FLOWCHART [1] TROUBLE SHOO TING FLOWCHART NO RASTER GREEN Check CRT connector LED COLOUR ? (KY), (H) bias. (14V,120 V, 210 V line) Power on by R/C Abnormal Normal Check R,G,B...
  • Page 37 29CTF05BS NO LED LIGHT Check F4701 Normal Blown out Replace the fuse Is the fuse again blown out ? Does STBY+5V appear at pin 4 Check the power circuit IC752 main unit ? consisting of IC701, IC702, T701 and its related parts.
  • Page 38 29CTF05BS NO NORMAL SOUND No sound No sound from the comes out at speaker. AV-out J905. Set volume to maximum. Is there any sound output signal at pin 11 & Check sound output 9 of IC301 ? signal from pin 92 &...
  • Page 39 29CTF05BS NO PICTURE Does the snow noise appear on the screen at Snow noise maximum contrast and increase brightness ? Does 5V appear Check the PC+5V line. at pin 7 of TU 51 ? Does 31V appear Check +120V line and at pin 9 of TU 51 ? its related circuit.
  • Page 40 29CTF05BS No snow noise Check pin 104 & 105 of IC 2100. Abnormal Normal Noise or signal Check TU 51 (Tuner), appear. SF 202 and its related circuit. Does AV input at Check IC 2100 and AV1 & AV2 normal ? its related circuits.
  • Page 41 29CTF05BS NO SPECIFIC COLOUR Is only RF signal's colour abnormal ? NO COLOUR COLOUR PRODUCED Check tuner TU 51, SF 202 and its related circuit. Adjust the colour Set the control at the user appropriate MENU. Does colour colour level.
  • Page 42 29CTF05BS Is some colours produced in the B/W broadcast reception ? Is the white balance Check IC 2100 properly adjusted ? & IC 851 and its related circuit including the RGB input & output line. Readjust the white balance. The picture...

  • Page 43: Chapter 5. Solid State Device Base Diagram

    29CTF05BS CHAPTER 5. 29L-FG5RU Service Manual 29L-FG5RU Market SOLID STATE DEVICE BASE DIAGRAM [1] SOLID STATE DEVICE BASE DIAGRAM S OLID STATE DEVICE BASE DIAGRAM TOP VIEW 00K5W BC0W BR24L16 FXA003W D33KA5W D00K5WP A50B0W COLLECTOR COLLECTOR COLLECTOR BASE EMITTER BASE...

  • Page 44: Chapter 6. Chassis Layout

    29CTF05BS CHAPTER 6. 29L-FG5RU Service Manual 29L-FG5RU Market CHASSIS LAYOUT [1] CHASSIS LAYOUT 6 – 1...

  • Page 45: Chapter 7. Block Diagram

    29CTF05BS CHAPTER 7. 29L-FG5RU Service Manual 29L-FG5RU Market BLOCK DIAGRAM [1] BLOCK DIAGRA M : MAIN UNIT 7 – 1...
  • Page 46 29CTF05BS 7 – 2...

  • Page 47: Chapter 8. Description Of Schematic Diagram

    29CTF05BS CHAPTER 8. 29L-FG5RU Service Manual 29L-FG5RU Market DESCRIPTION OF SCHEMATIC DIAGRAM [1] DESCRIPTION OF SCHEMATIC DIAGRAM NOTES: SAFETY NOTES: 1. The unit of resistance "ohm" is omitted. DISCONNECT THE AC PLUG FROM THE AC OUTLET BEFORE REPLACING PARTS. (K = 1000 ohms, M = Meg ohm).
  • Page 48 29CTF05BS CHAPTER 9. 29L-FG5RU Service Manual 29L-FG5RU Market WAVEFORM [1] WAVEFORM WAVEFORMS Horizontal Rate Horizontal Rate Vertical Rate Vertical Rate Vp - p = 2.02 V Vp - p = 1.30 V Vp - p = 2.26 V Vp - p = 2.40 V...

  • Page 49: Chapter 10. Schematic Diagram

    29CTF05BS CHAPTER 10. 29L-FG5RU Service Manual 29L-FG5RU Market SCHEMATIC DIAGRAM [1] SCHEMATIC DIAGRAM : MAIN UNIT 10 – 1...
  • Page 50 29CTF05BS 10 – 2...

  • Page 51: Schematic Diagram : Crt Unit

    29CTF05BS [2] SCHEMATIC DIAGRAM : CRT UNIT 29CTF05BS 10 – 3...

  • Page 52: Chapter 11. Printed Wiring Board Assemblies

    29CTF05BS CHAPTER 11. 29L-FG5RU Service Manual 29L-FG5RU Market PRINTED WIRING BOARD ASSEMBLIES [1] PWB-B : CRT UNIT 11 – 1...

  • Page 53: Pwb-A : Main Unit

    29CTF05BS [2] PWB-A : MAIN UNIT 1. MAIN UNIT (COMPONENT SIDE) 11 – 2...
  • Page 54 29CTF05BS 11 – 3...
  • Page 55 29CTF05BS 2. MAIN UNIT (CHIP PARTS SIDE) 11 – 4...
  • Page 56 29CTF05BS 11 – 5...

  • Page 57: Parts Guide

    29CTF05BS PartsGuide AKAI PARTS GUIDE No. XXXXXXXXXXXX XXXXXXXX 29CTF05BS 29L- MODEL MODEL CONTENTS PICTURE TUBE NICAM/A2 PRINTED WIRING BOARD MISCELLANEOUS PARTS ASSEMBLIES SUPPLIED ACCESSORIES MAIN UNIT CABINET PARTS CRT UNIT [10] PACKING PARTS HEADPHONE UNIT INDEX Parts marked with "...
  • Page 58 29CTF05BS PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [1] PICTURE TUBE RCILGA095WJZZ Degaussing Coil QEARCA012WJZZ Ground Part PMAGF3046CEZZ Purity Magnet [2] PRINTED WIRING BOARD ASSEMBLIES DUNTKD138WEA4 MAIN Unit DUNTKC519WEC6 CRT Unit DUNTKD144WEA4 HEADPHONE Unit DUNTKD600WEA1 NICAM/A2 [3] MAIN UNIT...
  • Page 59 29CTF05BS PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [3] MAIN UNIT D1803 RH-EX0253TAZZY Zener Diode , 3.53V D3501 RH-EX0612GEZZY Zener Diode , 5.1V D3502 RH-EX0612GEZZY Zener Diode , 5.1V VA701 RH-VX0073CEZZ Varistor PR701 RMPTP0085CEZZ Packaged Circuit X801 RCRSAA019WJZZ Crystal...
  • Page 60 29CTF05BS PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [3] MAIN UNIT C784 RC-KZ1018CEZZ+ 1000p 2kV Ceramic C802 VCEA0A1AW107M+ 100 10V Electrolytic C803 VCKYCY1HB103KY 0.01 50V Ceramic C804 VCEACA1HC474M+ 0.47 50V Electrolytic C805 VCKYCY1HB153KY 0.15 50V Ceramic C806 VCEA9M1CW476M+ 47 16V Electrolytic...
  • Page 61 29CTF05BS PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [3] MAIN UNIT C3521 VCEA0A1HW105M+ 1 50V Electrolytic C3522 VCEA0A1HW105M+ 1 50V Electrolytic C3523 VCKYCY1HB104KY 0.1 50V Ceramic C3524 VCEA0A1CW108M+ 1000 16V Electrolytic C3525 VCKYCY1HF103ZY 0.01 50V Ceramic C3526 VCKYCY1HF103ZY 0.01 50V Ceramic...
  • Page 62 29CTF05BS PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [3] MAIN UNIT R618 VRS-CY1JF103JY 10k 1/16W Metal Oxide R621 VRN-RL2HC1R0J+ 1 1/2W Metal Film R622 VRS-VV3DB682J 6.8k 2W Metal Oxide R625 VRD-RM2HD184JY 180k 1/2W Carbon R626 VRS-CY1JF472JY 4.7k 1/16W Metal Oxide...
  • Page 63 29CTF05BS PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [3] MAIN UNIT R1024 VRS-CY1JF101JY 100 1/16W Metal Oxide R1025 VRD-RA2BE103JY 10k 1/8W Carbon R1026 VRS-CY1JF183JY 18k 1/16W Metal Oxide R1027 VRS-CY1JF104JY 100k 1/16W Metal Oxide R1028 VRD-RA2BE181JY 180 1/8W Carbon...
  • Page 64 29CTF05BS PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [4] CRT UNIT R865 VRD-RA2BE102JY 1k 1/8W Carbon RDA851 PRDAR0248PEFW HEAT SINK , IC851 FB852 RBLN-A034WJZZY Balun P855 QPLGN0761CEZZ Socket , 7 Pin P860 QPLGN0878GEZZ Socket , 8 Pin [5] HEADPHONE UNIT...
  • Page 65 29CTF05BS PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [6] NICAM/A2 R2309 VRS-CY1JF822JY 8.2k 1/16W Metal Oxide R2311 VRS-CY1JF102JY 1k 1/16W Metal Oxide R2313 VRD-RA2BE101JY 100 1/8W Carbon R2314 VRD-RA2BE101JY 100 1/8W Carbon R2316 VRS-CY1JF222JY 2.2k 1/16W Metal Oxide R2317...
  • Page 66 29CTF05BS [9] CABINET PARTS 29CTF05BS PRICE PART PARTS CODE DESCRIPTION RANK MARK RANK [9] CABINET PARTS Not Available Front Cabinet HBDGB3155CESA SHARP Badge GCOVAB341WJSA LED , R/C Cover CBTN-A484WEV0 Power Button Ass'y MSPRCA067WJFW Power Button Spring GDORFA166WJSA Door HINDPB380WJZZ Indication Plate CCABBA631WEV0 Rear Cabinet Ass"y...
  • Page 67 29CTF05BS [10] PACKING PARTS PACKING OF THE SHEET SSAKA0001PEZZ *Polyethylene Bag SPAKXA971WJZZ Operation Manual *Batteries *Bu er Material Top Infra Red R/C Unit SSAKHA023WJZZ SPAKXA973WJZZ *Wrapping Sack *Bu er Material Rear SPAKXA972WJZZ *Bu er Material Bottom SPAKCC644WJZZ *Packing Case USE 22 STAPLES...
  • Page 68 29CTF05BS INDEX PRICE PART RANK MARK RANK [ C ] [ D ] [ G ] [ H ] [ M ] [ N ] a l i [ P ] " " [ Q ] " " " "...
  • Page 69 29CTF05BS PRICE PART RANK MARK RANK " " " " " " " " " " " " " " " " " " " [ S ] [ T ] [ V ] "...
  • Page 70 29CTF05BS PRICE PART RANK MARK RANK PRICE PART PRICE PART RANK MARK RANK RANK MARK RANK " " " " " " " " " " " " " " " " " " " " " " " "...
  • Page 71 29CTF05BS PRICE PART PRICE PART RANK MARK RANK RANK MARK RANK " " " " " " " " " " " " " " " " " " " " " " " " " " " " "...
  • Page 72 29CTF05BS PRICE PART PRICE PART RANK MARK RANK RANK MARK RANK " " " " " " " " " " " " " " " " " " " " " " " " " " " " "...
  • Page 73 29CTF05BS PRICE PART RANK MARK RANK "...
