ASSEMBLY INSTRUCTION FOR EXC-750-SHELF
TOP of UNIT
When attaching unit to wall put safety bracket in
middle of unit with 5/8 pan screw then 25mm pan
head screw into wall. For plasterboard without a
stud it is recommended to use a plug with screw
(not provided).
2 x TOP GABLES
2 x BOTTOM
GABLES
2 x BACKING BOARDS
975mm x 744 x 3
FOLD LINE
TOP
NO
MODEL
DESCRIPTION
1
CONFIRMAT SCREWS
2
CAPS
3
DOWELS
4
BACKING NAILS
PARTS IDENTIFICATION LIST
966mm x 445m x 16mm
1035mm x 445m x 16mm
962mm x 744 x 3
FOLD LINE
BOTTOM
QTY
20
20
4
75
4 x ADJUSTABLE SHELVES
3 x FIXED SHELF
1 x BOTTOM KICK
NO MODEL
DESCRIPTION
5
SHELF PINS
6
5/8 PANHEAD UNIT SCREWS
7
25mm PANHEAD WALLSCREWS 1
8
"L" SAFETY BRACKET
716mm x 445mm x 16mm
718mm x 445mm x 16mm
718mm x 61 x 16mm
QTY
16
1
1
