ASSEMBLY INSTRUCTION FOR EXC-750 H2
TOP of UNIT
When attaching unit to wall put safety bracket in
middle of unit with 16mm pan head screw then
25mm pan head screw into wall.
For plasterboard without a stud it is recommended
to use a plug with screw (not provided).
2 x TOP GABLES
2 x BOTTOM
GABLES
2 x BACKING
BOARDS
1 x 717mm H MOULD
NO MODEL
DESCRIPTION
1
CONFIRMAT SCREWS 50mm x 5mm
2
WHITE CAPS
3
DOWELS
4
BACKING NAILS
5
16mm WOOD SCREWS
PARTS IDENTIFICATION LIST
FOLD LINE
1 x CAM SHELF
2 x FIXED SHELF
1 x BOTTOM KICK
2 x 30mm FLANGES
1 x 30mm HANGING RAIL
1 x SAFETY BRACKET
QTY
NO
MODEL
14
6
7
14
4
8
9
75
2
10
EXC– 750H2
DESCRIPTION
CAMS
CAM PINS
16mm PAN HEAD SCREWS
25mm PAN HEAD SCREWS
"L" SAFETY BRACKET
QTY
4
4
1
1
1
Advertisement
Related Manuals for Multistore EXC-750H2
Summary of Contents for Multistore EXC-750H2
- Page 1 ASSEMBLY INSTRUCTION FOR EXC-750 H2 EXC– 750H2 TOP of UNIT When attaching unit to wall put safety bracket in middle of unit with 16mm pan head screw then 25mm pan head screw into wall. For plasterboard without a stud it is recommended to use a plug with screw (not provided).
- Page 2 TAKE YOUR GABLES AND LAY THEM OUT FLAT, YOU SHOULD HAVE 2 X TOP & FIXED SHELF RAIL SUPPORT KICK DOWELS 2 X BOTTOM GABLES. USING A LITTLE BRACKETS WOOD GLUE (NOT SUPPLIED) IN YOUR PRE-DRILLED HOLES, INSERT YOUR WOOD DOWELS INTO 2 OF THE HOLES AND PUSH YOUR TOP INTO YOUR NEXT STEP: BOTTOM GABLE.
- Page 3 10 Year Warranty • If the purchaser has a fault or defect with this product, the purchaser needs to contact Multistore Industries (Aust) directly on (07) 3208 6799 and state date of purchase, place of purchase and proof of purchase.
