Summary of Contents for protech ProX-1710

  • Page 1 USER’S MANUAL ProX-1710 Pentium 4 [mPGA 478] Full-sized CPU Card W/ VGA / LAN...
  • Page 2 Copyright Notice ProX-1710 Pentium® 4 mPGA 478 Full-sized CPU Card With VGA/Dual LAN OPERATION MANUAL COPYRIGHT NOTICE This operation manual is meant to assist both Embedded Computer manufacturers and end users in installing and setting up the system. The information contained in this document is subject to change without any notice.

  • Page 3: Table Of Contents

    Contents TABLE OF CONTENTS CHAPTER 1 INTRODUCTION About This Manual ............System Specification ............1-3 Safety Precautions ............CHAPTER 2 HARDWARE CONFIGURATION Jumper & Connector Quick Reference Table ....Component Locations ............ How to Set the Jumpers ..........COM Port Connector ……..…………………………... RS232/422/485 (COM2) Selection .......
  • Page 4 Contents 2-29 ATX Power Signal Connector ………….…………….. 2-24 2-30 ATX +12V Power Connector ........2-24 2-31 Reset / NMI / Clear Watchdog Selection …………….. 2-25 2-32 Panel VDD Selection …………………………………. 2-26 2-33 LVDS Power Connector ……………..……………….. 2-26 2-34 PPCI Connector ………………………………………. 2-27 2-35 Panel Type Selection ………………………………….
  • Page 5 Contents APPENDIX A EXPANSION BUS ISA Bus Pin Assignment ............PCI Bus Pin Assignment ............APPENDIX B TECHNICAL SUMMARY Block Diagram ................Interrupt Map ................RTC & CMOS RAM Map ............Timer & DMA Channels Map ..........I/O & Memory Map ..............APPENDIX C TROUBLE SHOOTING Trouble Shooting for Error Messages ........

  • Page 6: Chapter 1 Introduction

    CHAPTER INTRODUCTION This chapter gives you the information for Prox-1710. It also outlines the System specification. Section includes: About This Manual System Specifications Safety precautions Experienced users can skip to chapter 2 on page 2-1 for Quick Start. Page:1-1...

  • Page 7: About This Manual

    1-1. ABOUT THIS MANUAL Thank you for purchasing our Prox-1710 Socket 478 Embedded Card enhanced with VGA / LAN, which is fully PC / AT compatible. Prox-1710 provides faster processing speed, greater expandability and can handle more task than before. This manual is designed to assist you how to install and set up the system.

  • Page 8: System Specification

    One additional 5-pin External keyboard connector. UNIVERSAL SERIAL BUS : Universal Serial Bus Connector on board Supports up to 2 USB ports. DISK-ON-CHIPS SOCKET : One 32-pin socket, supports up to 144MB disk-on-chip. ′ Page: 1-3 Prox-1710 USER S MANUAL...
  • Page 9 Support up to two Floppy Disk Drives, 3.5" and 5.25" (360K / 720K / 1.2M / 1.44M / 2.88M ). LAN INTERFACE : Intel® 82562ET PHY PCI Fast Ethernet. One RJ-45 Jack onboard. Support for 10BaseT/100 BaseTx PCI Ethernet. Support Wake-On-LAN function. ′ Page: 1-4 Prox-1710 USER S MANUAL...
  • Page 10 Hard Disk access. LAN LED indicator. BUS SPEED : ISA Bus 8MHz PCI Bus 33MHz PPCI Bus 33MHz 12Mbit/sec DMA CONTROLLER : 82C37 x 2 DMA CHANNELS : INTERRUPT CONTROLLERS : 82C59 x 2 ′ Page: 1-5 Prox-1710 USER S MANUAL...

  • Page 11: Safety Precautions

    3. Disconnect power when you change any hardware devices. For instance, when you connect a jumper or install any cards, a surge of power may damage the electronic components or the whole system. ′ Page: 1-6 Prox-1710 USER S MANUAL...

  • Page 12: Chapter 2 Hardware Configuration

    CHAPTER HARDWARE CONFIGURATION ** QUICK START ** Helpful information describes the jumper & connector settings, and component locations. Section includes: Jumper & Connector Quick Reference Table Component Locations Configuration and Jumper settings Connector’s Pin Assignments Page 2-1...
  • Page 13 ATX +12V Power Connector …………………………. Reset/NMI/Clear Watchdog Selection .………….…….. Panel VDD Selection ………………………………….. LVDS Power Connector ……………………………... Wake-On-LAN Connector …………………………….. WOL1 Panel Type Selection ………………………………….. PPCI Connector ……………..………………….……… PPCI Memory Installation ........…..……… DIMM1, DIMM2 …………………………………… DIMM3 ’ Page: 2-2 Prox-1710 USER S MANUAL...

  • Page 14: Component Locations

    Chapter 2 Hardware Configuration 2-2. COMPONENT LOCATIONS COM1 LAN1 Prox-1710 Connector, Jumper and Component locations ’ Page: 2-3 Prox-1710 USER S MANUAL...

  • Page 15: How To Set The Jumpers

    You can connect PIN1 & PIN2 to create one setting and shorting. You can either connect PIN2 & PIN3 to create another setting. The same jumper diagrams are applied all through this manual. The figure below shows what the manual diagrams look and what they represent. ’ Page: 2-4 Prox-1710 USER S MANUAL...
  • Page 16 Jumper Block looks like this JUMPER SETTINGS 2 pin Jumper close(enabled) Looks like this 3 pin Jumper 2-3 pin close(enabled) Looks like this Jumper Block 1-2 pin close(enabled) Looks like this ’ Page: 2-5 Prox-1710 USER S MANUAL...

  • Page 17: Com Port Connector

    The pin assignment is as follows : ASSIGNMENT COM1 COM2 : COM2 Connector COM2 is selectable as RS-232/422/485. The pin assignment is as follows : ASSIGNMENT RS-232 RS-422 RS-485 RTS- RTS+ CTS+ CTS- ’ Page: 2-6 Prox-1710 USER S MANUAL...

  • Page 18: Rs232/422/485 (Com2) Selection

    The jumper settings are as follows : COM 2 RS-232 RS-422 RS-485 Function Open Jumper Settings 9-10 9-10 (pin closed) 11-12 11-12 13-14 13-14 15-16 15-16 17-18 17-18 19-20 19-20 Jumper Illustrations *** Manufactory default --- RS-232. ’ Page: 2-7 Prox-1710 USER S MANUAL...

  • Page 19: Solid-State Disk Socket

    Chapter 2 Hardware Configuration 2-6. SOLID-STATE DISK SOCKET SSD: 32pin Disk-on-chip Socket The pin assignments are as follows: ASSIGNMENT ASSIGNMENT SA12 SA10 SA11 SA13 SA14 ’ Page: 2-8 Prox-1710 USER S MANUAL...

  • Page 20: Ssd Memory Mapping Selection

    Flash ROM SSD can be install as one of user’s hard disk drive. The SSD Memory Mapping Selections are as follows: JUMPER SETTING JUMPER SSD Memory Map (pin closed) ILLUSTRATION D0000h-D1FFFh 9-10 D4000h-D5FFFh 11-12 D8000h-D9FFFh 9-10 DC000h-DDFFFh 11-12 *** Manufactory default --- D0000h-D1FFFh. ’ Page: 2-9 Prox-1710 USER S MANUAL...

  • Page 21: Keyboard Or Ps/2 Mouse Connector

    For Y-Cable user, please set the jumper same as AT keyboard. The jumper settings are as follows: DEVICE JUMPER SETTING JUMPER TYPE (pin closed) ILLUSTRATION KEYBOARD PS/2 MOUSE *** Manufactory default -- AT Keyboard ’ Page: 2-10 Prox-1710 USER S MANUAL...

  • Page 22: External Keyboard Connector

    EXKB : External Keyboard Connector The pin assignment is as follows : ASSIGNMENT KBCLK KBDATA 2-11. RESET CONNECTOR FPANEL(18,20) : Reset Connector. The pin assignment is as follows : FPANEL ASSIGNMENT HW RESET GROUND ’ Page: 2-11 Prox-1710 USER S MANUAL...

  • Page 23: Hard Disk Drive Led Connector

    The pin assignment is as follows : FPANEL HDD_LED ASSIGNMENT HDD_LED 2-13. ATX POWER BUTTON FPANEL (13,15) : ATX Power Button The pin assignment is as follows : ATX_BTN FPANEL ASSIGNMENT PWR_BN1 PWR_BN2 ’ Page: 2-12 Prox-1710 USER S MANUAL...

  • Page 24: External Speaker Connector

    FPANEL(2,4,6,8) : External Speaker Connector The pin assignment is as follows : FPANEL ASSIGNMENT SPEAKER SIGNAL 2-15. POWER LED CONNECTOR FPANEL(1,3,5) : Power LED Connector The pin assignment is as follows: PWR_LED FPANEL ASSIGNMENT ’ Page: 2-13 Prox-1710 USER S MANUAL...

  • Page 25: Keylock Connector

    Note: To clear CMOS data, user must power-off the computer and set the jumper to “Clear CMOS” as illustrated above. After five to six seconds, set the jumper back to “Normal” and power-on the computer. ’ Page: 2-14 Prox-1710 USER S MANUAL...

  • Page 26: Cpufan Connector

    The pin assignment is as follows: ASSIGNMENT +12V FAN2 2-19. VGA CRT CONNECTOR VGA : VGA CRT Connector The pin assignments are as follows: ASSIGNMENT GREEN BLUE MONID0 MONID1 VGA DDCDATA HSYNC VSYNC VGA DDC CLK ’ Page: 2-15 Prox-1710 USER S MANUAL...

  • Page 27: Panellink Connector

    DDC2B electrical interface that can be shared with the standard 15-pin DDC2B compliant VGA connector (if present). The pin assignments are as follows : TMDS ASSIGNMENT ASSIGNMENT TX OUT1+ TXOUT2+ TXOUT1- TXOUT2- TXCLKOUT+ TXOUT0+ TXCLKOUT- TXOUT0- CHARGE DVI DATA DVI CLK ’ Page: 2-16 Prox-1710 USER S MANUAL...

  • Page 28: Lvds Connector

    ASSIGNMENT ASSIGNMENT TXU1+ LVDS2 TXU1- TXU3+ TXU3- TXU0+ TXU0- TXCLKU+ TXCLKU- PANEL VDD TXU2+ PANEL VDD TXU2- CHARGE 24bit and below panel used LVDS1, for 36/48bit panel used both LVDS1 and LVDS2 connector. ’ Page: 2-17 Prox-1710 USER S MANUAL...

  • Page 29: Hard Disk Drive Connector

    Chapter 2 Hardware Configuration 2-22. HARD DISK DRIVE CONNECTOR IDE1: Hard Disk Drive Connector The Prox-1710 possesses two HDD connectors, IDE1 and IDE2. The pin assignments are as follows: IDE1 ASSIGNMENT ASSIGNMENT IDERST PDD7 PDD8 PDD6 PDD9 PDD5 PDD10 PDD4...
  • Page 30 IDERST SDD7 SDD8 SDD6 SDD9 SDD5 SDD10 SDD4 SDD11 SDD3 SDD12 SDD2 SDD13 SDD1 SDD14 SDD0 SDD15 SDREQ SDIOW# SDIOR# SIORDY PULL LOW SDDACK# IRQ15 SDA1 S66 DETECT SDA0 SDA2 SDCS#1 SDCS#3 IDEACTS# ’ Page: 2-19 Prox-1710 USER S MANUAL...

  • Page 31: Floppy Disk Drive Connector

    34-pin flat cable to attach the FDD on the board, and the other side is attaches two FDDs. The pin assignments are as follows : FDC1 ASSIGNMENT ASSIGNMENT RWC# DS1# INDEX MOA# DSB# DSA# MOB# DIR# STEP# TRK0# RDATA# HEAD# DSKCHG ’ Page: 2-20 Prox-1710 USER S MANUAL...

  • Page 32: Printer Connector

    As to link the Printer to the card, you need a cable to connect both DB25 connector and parallel port. The pin assignments are as follows : ASSIGNMENT ASSIGNMENT AFD# PDR0 ERROR# PDR1 PAR_INIT# PDR2 SLIN# PDR3 PDR4 PDR5 PDR6 PDR7 ACK# BUSY SLCT ’ Page: 2-21 Prox-1710 USER S MANUAL...

  • Page 33: Universal Serial Bus Connector

    This connector can connect up to two USB port. The pin assignments are as follows: ASSIGNMENT DATA0− DATA0+ USB1 DATA1− DATA1+ 2-26. IRDA CONNECTOR IRDA1: IrDA (Infrared) Connector The pin assignments are as follows: ASSIGNMENT IRRX IRDA1 IRTX ’ Page: 2-22 Prox-1710 USER S MANUAL...

  • Page 34: Lan Connector

    The green LED detect power link, and the Yellow LED is used to detect data active transfer signal. 2-28. SYSTEM FAN CONNECTOR FAN1 : System Fan connector The pin assignment is as follows: ASSIGNMENT +12V FAN1 FAN1 ’ Page: 2-23 Prox-1710 USER S MANUAL...
  • Page 35 CN3 : ATX Power Signal Connector The pin assignments are as follows: ASSIGNMENT +5V SB PS_ON 2-30. ATX +12V POWER CONNECTOR CN3 : ATX +12V Power Connector The pin assignments are as follows: ASSIGNMENT +12V +12V ’ Page: 2-24 Prox-1710 USER S MANUAL...
  • Page 36 Non-Maskable Interrupt, is used for serious conditions that demand the processor’s immediate attention, it cannot be ignored by the system unless it is shut off specifically. To clear NMI command, user should short the “Clear Watchdog” pin via push button. ’ Page: 2-25 Prox-1710 USER S MANUAL...
  • Page 37 The selections are as follow: SELECTION JUMPER SETTING JUMPER (pin closed) ILLUSTRATION VDD +3.3V VDD +5V 2-33. LVDS POWER CONNECTOR CN2 : LVDS Power Connector The pin assignments are as follows: ASSIGNMENT Safe +12V Safe +5V ’ Page: 2-26 Prox-1710 USER S MANUAL...
  • Page 38 Chapter 2 Hardware Configuration 2-34. PPCI CONNECTOR You will find a PPCI connector in our Prox-1710. This connector is used to connect our SCSI daughter boards. The pin assignments are as follows: ASSIGNMENT ASSIGNMENT AD10 AD11 AD12 AD13 AD14 AD15...
  • Page 39 800x600 pixel LVDS 1024x768 pixel LVDS 1280x1024 pixel ***Manufacturing Default – PanelLink™. When user intends to use both PanelLink™ and LVDS, the jumper setting should be set in accordance of the LVDS setting. ’ Page: 2-28 Prox-1710 USER S MANUAL...
  • Page 40 WOL1 : Wake-On-LAN Connector The pin assignments are as follows: ASSIGNMENT V5_SB WOL1 PME# 2-37. MEMORY INSTALLATION Prox-1710 CPU Card can support up to 3GB in three DIMM socket. DRAM BANK CONFIGURATION DIMM 1 DIMM 2 DIMM3 TOTAL MEMORY 32MB...
  • Page 41 Chapter 2 Hardware Configuration ’ Page: 2-30 Prox-1710 USER S MANUAL...
  • Page 42 CHAPTER SOFTWARE UTILITIES This chapter comprises the detailed information of VGA driver, LAN driver, and Flash BIOS update. It also describes how to install the watchdog timer configuration. Section includes: VGA Driver Utility Flash BIOS Update LAN Driver Utility Intel® Chipset Software Installation Utility Watchdog Timer Configuration Page: 3-1...
  • Page 43 Chapter 3 Software Configuration 3-1. INTRODUCTION Enclosed with our Prox-1710 package is our driver utility, which may comes in a form of a CD ROM disc or floppy diskettes. For CD ROM disc user, you will only need some of the files contained in the CD ROM disc, please...
  • Page 44 Utility Disk for system BIOS and VGA BIOS update. 3-3-2. To update VGA BIOS for LCD Flat Panel Display: As Prox-1710 user, you have to update the VGA BIOS for your specific LCD flat panel you are going to use. For doing this, you need two files.
  • Page 45 Select "Y", and the BIOS will be renewed. When you are refreshing the BIOS, do not turn off or reset the system, or you will damage the BIOS. After you have completed all the programming, the screen displays the table below: ′ Page:3-4 Prox-1710 USER S MANUAL...
  • Page 46 File Name to Program: C10xxxxx.bin Checksum: XXXXX Reset System or Power off to accomplish update process! F1: Reset F10: Exit Please reset or power off the system, and then the Flash BIOS is fully implemented. ′ Page:3-5 Prox-1710 USER S MANUAL...
  • Page 47 Chapter 3 Software Configuration 3-4. LAN DRIVER UTILITY 3-4-1. Introduction Prox-1710 Embedded Card is enhanced with LAN function that can support various network adapters. Installation programs for LAN drivers are listed as follows: 1. Win 95/98 program 2. Win NT program 3.
  • Page 48 Click Setup.exe file for utility installation. Follow the instructions on the screen to complete the installation. Once installation is completed, shut down the system and restart in order for the changes to take effect. ′ Page:3-7 Prox-1710 USER S MANUAL...
  • Page 49 I/O port 441H, the system will run the command to stop the Watchdog function. In Prox-1710 watchdog function, you must write your program so when it writes I/O port address 443 for enable watchdog and write I/O port address 441 for disable watchdog.
  • Page 50 CHAPTER AWARD BIOS SETUP This chapter shows how to set up the Award BIOS. Section includes: Introduction Entering Setup The Standard CMOS Features The Advanced BIOS Features The Advanced Chipset Features Integrated Peripherals Power Management Setup PNP/PCI Configuration PC Health Status Frequency/Voltage Control Load Fail-Safe Defaults Load Optimized Defaults...
  • Page 51 4-1. INTRODUCTION This chapter will show you the function of the BIOS in managing the features of your system. The Prox-1710 Pentium® 4 Full-sized CPU Card is equipped with the BIOS for system chipset from Award Software Inc. This page briefly explains the function of the BIOS in managing the special features of your system.
  • Page 52 You may use the cursor the up/down keys to highlight the individual menu items. As you highlight each item, a brief description of the highlighted selection will appear at the bottom of the screen. ′ Page: 4-3 Prox-1710 USER S MANUAL...
  • Page 53 < Hour >, < Minute >, and < Second >. Use 24 hour clock format, i.e., for PM numbers, add 12 to the hour. For example: 4: 30 P.M. You should enter the time as 16:30:00. ′ Page: 4-4 Prox-1710 USER S MANUAL...
  • Page 54 Head – Set the number of read/write heads. c. Precomp - ***Warning! Setting a value of 65535 means no HDD. d. Landing Zone e. Sector – Set the number of sector per track ′ Page: 4-5 Prox-1710 USER S MANUAL...
  • Page 55 BASE MEMORY: Displays the amount of conventional memory detected during boot up. EXTENDED MEMORY: Displays the amount of extended memory detected during boot up. TOTAL MEMORY: Displays the total memory available in the system. ′ Page: 4-6 Prox-1710 USER S MANUAL...
  • Page 56 1024 65535 1023 1024 65535 1023 1024 65535 1023 1024 65535 1023 1024 65535 1023 65535 1023 65535 1024 65535 1023 1024 65535 1023 65535 65535 65335 AUTO Award Hard Disk Type Table ′ Page: 4-7 Prox-1710 USER S MANUAL...
  • Page 57 This item allows you to choose the Virus Warning feature for IDE Hard Disk boot sector protection. If this function is enabled and someone attempt to write data into this area, BIOS will show a warning message on screen and alarm beep. ′ Page: 4-8 Prox-1710 USER S MANUAL...
  • Page 58 For example, if you press and hold down the "A" key, the letter "a" will repeatedly appear on your screen on your screen until you release the key. When enabled, the typematic rate and typematic delay can be selected. ′ Page: 4-9 Prox-1710 USER S MANUAL...
  • Page 59 Setup freely. OS SELECT FOR DRAM >64MB : Select the operating system that is running with greater than 64MB or RAM on the system. You may choose OS2 or Non-OS2. ′ Page: 4-10 Prox-1710 USER S MANUAL...
  • Page 60 The default settings have been chosen because they provide the best opera- ting conditions for the system. The only time you might consider making any changes would be if you discovered that data was being lost while using your system. ′ Page: 4-11 Prox-1710 USER S MANUAL...
  • Page 61 VIDEO BIOS CACHEABLE: Select Enabled allows caching of the video BIOS, resulting in better system performance. However, if any program writes to this memory area, a system error may result. ′ Page: 4-12 Prox-1710 USER S MANUAL...
  • Page 62 This field allows you to enable or disable IO channel check NMI. Before selecting this function, the user should check first that NMI function is enabled as described in chapter 2 (Reset/NMI/Clear Watchdog Selection). ′ Page: 4-13 Prox-1710 USER S MANUAL...
  • Page 63 F6:Fail-Safe Defaults F7:Optimized Defaults Integrated Peripherals Setup Screen By moving the cursor to the desired selection and by pressing the <F1> key, the all options for the desired selection will be displayed for choice. ′ Page: 4-14 Prox-1710 USER S MANUAL...
  • Page 64 USB Mouse. INIT DISPLAY FIRST: This item allows you to decide to active whether PCI Slot or on-chip VGA first. BIOS FLASH FUNCTION: This item allows you to enable the BIOS Flash function. ′ Page: 4-15 Prox-1710 USER S MANUAL...
  • Page 65 This item allows you to select IR transmission routes, one is RxD2m, TxD2 (COM Port) and the other is IR-Rx2Tx2. ONBOARD PARALLEL PORT: This item allows you to determine access onboard parallel port controller with which I/O address. ′ Page: 4-16 Prox-1710 USER S MANUAL...
  • Page 66 Select a DMA channel for the parallel port for use during ECP mode. PWRON AFTER PWR-FAIL: This item allows you to select if you want to power on the system after power failure. ′ Page: 4-17 Prox-1710 USER S MANUAL...
  • Page 67 ACPI SUSPEND TYPE: This item allows the user to set the ACPI suspend type to be used. POWER MANAGEMENT: This item allows you to select the Power Management mode. ′ Page: 4-18 Prox-1710 USER S MANUAL...
  • Page 68 Enabled, even when the system is in a power down mode. (1) Primary IDE 0 (2) Primary IDE 1 (3) Secondary IDE 0 (4) Secondary IDE 1 (5) FDD, COM, LPT Port ′ Page: 4-19 Prox-1710 USER S MANUAL...
  • Page 69 This section covers technical items, which is strongly recommended for experienced users only. PNP OS INSTALLED: This item allows you to determine install PnP OS or not. ′ Page: 4-20 Prox-1710 USER S MANUAL...
  • Page 70 DMA RESOURCES: When resources are controlled manually, assign each system DMA channel a type, depending on the type of device using the DM channel. PCI/VGA PALETTE SNOOP: Leave this field at disabled. ′ Page: 4-21 Prox-1710 USER S MANUAL...
  • Page 71 CURRENT CPUFAN1/2 SPEED: This item shows you the current CPUFAN speed. VCORE: This item shows you the current system voltage. 3.3V / +5V / +12V / -12V / -5V: Show you the voltage of 3.3V/+5V/+12V/-12V/-5V. ′ Page: 4-22 Prox-1710 USER S MANUAL...
  • Page 72 EMI. Enabling pulse spectrum spread modulation changes the extreme values from spikes to flat curves, thus reducing EMI. This benefit may in some cases be outweighed by problems with timing-critical devices such as a clock-sensitive SCSI device. ′ Page: 4-23 Prox-1710 USER S MANUAL...
  • Page 73 When you press <Enter> on this category, you get a confirmation dialog box with a message similar to the following: Load Optimized Defaults ( Y/N ) ? N Pressing "Y" loads the default values that are factory setting for optimal performance system operations. ′ Page: 4-24 Prox-1710 USER S MANUAL...
  • Page 74 PASSWORD DISABLED!!! Press any key to continue... Press the < Enter > key again and the password will be disabled. Once the password is disabled, you can enter Setup freely. ′ Page: 4-25 Prox-1710 USER S MANUAL...
  • Page 75 You may always call up the setup program at any time to adjust any of the individual items by pressing the <Del> key during boot up. ′ Page: 4-26 Prox-1710 USER S MANUAL...
  • Page 76 Set Supervisor Password ►Power Management word Quit Without Saving (Y/N)? N ►PnP/PCI Configura etup ►PC Health Status Saving Esc : Quit : Select Item ↑↓→← F10 : Save & Exit Setup Abandon all Datas ′ Page: 4-27 Prox-1710 USER S MANUAL...
  • Page 77 Chapter 4 Award BIOS Setup ′ Page: 4-28 Prox-1710 USER S MANUAL...

  • Page 78: Appendix A Expansion Bus

    APPENDIX EXPANSION BUS This appendix indicates the pin assignments. Section includes: ISA BUS Pin Assignment PCI BUS Pin Assignment Page: A-1...

  • Page 79: Isa Bus Pin Assignment

    SA16 DRQ7 SD12 -DRQ3 SA15 SD13 -DACK1 SA14 -MASTER SD14 -DRQ1 SA13 SD15 -REFRESH SA12 BCLK SA11 IRQ7 SA10 SA09 IRQ5 SA08 IRQ4 SA07 IRQ3 SA06 SA05 SA04 BALE SA03 SA02 SA01 SA00 ′ Page: A-2 Prox-1710 USER S MANUAL...

  • Page 80: Pci Bus Pin Assignment

    AD10 +5V(I/O) REQ2# AD09 AD31 AD30 AD08 C/BE0# AD29 AD07 AD28 AD06 AD27 AD26 AD05 AD04 AD25 AD03 AD24 AD02 C/BE3# GNT2# AD01 AD00 AD23 +5V(I/O) +5V(I/O) AD22 ACK64# REQ64# AD21 AD20 AD19 ′ Page: A-3 Prox-1710 USER S MANUAL...
  • Page 81 Appendix A Expansion Bus ′ Page: A-4 Prox-1710 USER S MANUAL...
  • Page 82 APPENDIX TECHNICAL SUMMARY This section introduce you the maps concisely. Section includes: Block Diagram Interrupt Map RTC & CMOS RAM Map Timer & DMA Channels Map I / O & Memory Map Page: B-1...

  • Page 83: Appendix B Technical Summary Block Diagram

    VGA CHIP PC133 SDRAM BROOKDALE 4X AGP 3 DIMM MODULES LAN 82562 ICH2 USB 1/2 RJ-45 Jack PCI BUS BRIDGE Floppy IT8888TF LPC SIO W83627HF KB/MS IrDA ISA BUS PRN1 COM 1/2 (DOC) ′ Page: B-2 Prox-1710 USER S MANUAL...

  • Page 84: Interrupt Map

    Appendix B Technical Summary INTERRUPT MAP ASSIGNMENT System TIMER Keyboard Cascade Serial port 2 Serial port 1 Available Floppy Parallel port 1 RTC clock Available Available Available PS/2 Mouse Math coprocessor IDE1 IDE2 ′ Page: B-3 Prox-1710 USER S MANUAL...

  • Page 85: Rtc & Cmos Ram Map

    Extension memory low byte Extension memory high byte Reserved for extension memory low byte Reserved for extension memory high byte Date Century byte Information Flag 34-3F Reserve 40-7f Reserved for Chipset Setting Data ′ Page: B-4 Prox-1710 USER S MANUAL...

  • Page 86: Timer & Dma Channels Map

    TIMER & DMA CHANNELS MAP Timer Channel Map : Timer Channel Assignment System timer interrupt DRAM Refresh request Speaker tone generator DMA Channel Map : DMA Channel Assignment Available Available Floppy Available Cascade Available Available Available ′ Page: B-5 Prox-1710 USER S MANUAL...

  • Page 87: I/O & Memory Map

    Parallel port-2 2B0-2DF Graphics adapter controller 2F8-2FF Serial port-2 360-36F Net work ports 378-37F Parallel port-1 3B0-3BF Monochrome & Printer adapter 3C0-3CF EGA adapter 3D0-3DF CGA adapter 3F0-3F7 Floppy disk controller 3F8-3FF Serial port-1 ′ Page: B-6 Prox-1710 USER S MANUAL...

  • Page 88: Appendix C Trouble Shooting

    APPENDIX TROUBLE SHOOTING This section outlines the errors may occur when you operate the system. It also gives you the suggestions on solving the problems. Section includes: Trouble Shooting for Error Messages Trouble Shooting for POST Code Page: C-1...

  • Page 89: Trouble Shooting For Error Messages

    Then reboot the system. DISKETTE DRIVES OR TYPES MISMATCH ERROR - RUN SETUP : Type of diskette drive installed in the system is different from the CMOS definition. Run Setup to reconfigure the drive type correctly. ′ Page: C-2 Prox-1710 USER S MANUAL...
  • Page 90 Cannot initialize controller. Make sure the cord is correctly and firmly installed in the bus. Be sure the correct hard drive is selected in Setup. Also check to see if any jumper needs to be set correctly on the hard drive. ′ Page: C-3 Prox-1710 USER S MANUAL...
  • Page 91 Memory has been added or removed since the last boot. In EISA mode use Configuration Utility to reconfigure the memory configuration. In ISA mode enter Setup and enter the new memory size in the memory fields. ′ Page: C-4 Prox-1710 USER S MANUAL...
  • Page 92 The board installed is not responding to the ID request, or no board ID has been found in the indicated slot. Note: When this error appears, the system will boot in ISA mode, which allows you to run the EISA Configuration Utility. ′ Page: C-5 Prox-1710 USER S MANUAL...
  • Page 93 Unable to recalibrate fixed disk. Hard Disk(S) Fail (08) : Sector Verify failed. Keyboard is locked out – Unlock the key : BIOS detect the keyboard is locked. P17 of keyboard controller is pulled low. ′ Page: C-6 Prox-1710 USER S MANUAL...
  • Page 94 BIOS ROM checksum error – System halted : The checksum of ROM address F0000H-FFFFFH is bad. Memory test fail : BIOS reports the memory test fail if the onboard memory is tested error. ′ Page: C-7 Prox-1710 USER S MANUAL...

  • Page 95: Trouble Shooting For Post Codes

    02h : 03h : Initial Superio_Early_Init switch. 04h : Reserved. 1. Blank out screen 05h : 2. Clear CMOS error flag 06h : Reserved 1. Clear 8042 interface 07h : 2. Initialize 8042 self-test ′ Page: C-8 Prox-1710 USER S MANUAL...
  • Page 96 Also set real-time clock power status, and then check for override. 13h : Reserved Program chipset default values into chipset. Chipset default 14h : values are MODBINable by OEM customers. 15h : Reserved Initial Early_Init_Onboard_Generator switch. 16h : ′ Page: C-9 Prox-1710 USER S MANUAL...
  • Page 97 PCI & DIMM slots. 5. Early PCI initialization: -Enumerate PCI bus number -Assign memory & I/O resource -Search for a valid VGA device & VGA BIOS, and put it into C000:0. ′ Page: C-10 Prox-1710 USER S MANUAL...
  • Page 98 1. Initialize multi-language 2. Put information on screen display, including Award title, CPU type, CPU speed … 2Eh : Reserved 2Fh : Reserved Reserved Reserved Reserved Reset keyboard except Winbond 977 series Super I/O chips. ′ Page: C-11 Prox-1710 USER S MANUAL...
  • Page 99 Reserved 3Eh : Test 8259 interrupt mask bits for channel 1. 3Fh : Reserved Test 8259 interrupt mask bits for channel 2. Reserved Reserved Test 8259 functionality. Reserved Reserved Reserved Initialize EISA slot ′ Page: C-12 Prox-1710 USER S MANUAL...
  • Page 100 53h : Reserved 54h : Reserved Display number of processors (multi-processor platform) 55h : 56h : Reserved 57h : 1. Display PnP logo 2. Early ISA PnP initialization -Assign CSN to every PnP device. ′ Page: C-13 Prox-1710 USER S MANUAL...
  • Page 101 Reserved 64h : Reserved 65h : Initialize PS/2 Mouse 66h : Reserved 67h : Prepare memory size information for function call: INT 15h ax=E820h 68h : Reserved Turn on L2 cache. 69h : ′ Page: C-14 Prox-1710 USER S MANUAL...
  • Page 102 Detect & install all IDE devices: HDD, LS120, ZIP, CDROM….. 76h : Reserved Detect serial ports and parallel ports 77h : 78h : Reserved 79h : Reserved Detect and install co-processor 7Ah : ′ Page: C-15 Prox-1710 USER S MANUAL...
  • Page 103 4. Setup ACPI table at top of memory. 5. Invoke ISA adapter ROMs. 6. Assign IRQs to PCI devices. 7. Initialize APM. 8. Clear noise of IRQs. 86h : Reserved 87h : Reserved ′ Page: C-16 Prox-1710 USER S MANUAL...
  • Page 104 1. Build MP table. 2. Build and update ESCD. 3. Set CMOS century to 20h or 19h. 4. Load CMOS time into DOS timer tick. 5. Build MSIRQ routing table. FFh : Boot attempt (INT 19h) ′ Page: C-17 Prox-1710 USER S MANUAL...
  • Page 105 Appendix C Trouble Shooting PRINTED IN TAIWAN ′ Page: C-18 Prox-1710 USER S MANUAL...
