protech ProX-1690 User Manual

Dual socket 370 processor embedded card with vga/dual lan
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER'S
MANUAL
ProX-1690
Dual Socket 370 Processor
Embedded Card
W/ VGA / Dual LAN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ProX-1690 and is the answer not in the manual?

Questions and answers

Related Manuals for protech ProX-1690

Summary of Contents for protech ProX-1690

  • Page 1 USER’S MANUAL ProX-1690 Dual Socket 370 Processor Embedded Card W/ VGA / Dual LAN...
  • Page 2 Copyright Notice ProX-1690 Dual Socket 370 processor Embedded Card With VGA/Dual LAN OPERATION MANUAL COPYRIGHT NOTICE This operation manual is meant to assist both Embedded Computer manufacturers and end users in installing and setting up the system. The information contained in this document is subject to change without any notice.

  • Page 3: Table Of Contents

    Contents TABLE OF CONTENTS CHAPTER 1 INTRODUCTION About This Manual ............System Specification ............1-3 Safety Precautions ............CHAPTER 2 HARDWARE CONFIGURATION Jumper & Connector Quick Reference Table ....Component Locations ............ How to Set the Jumpers ..........COM Port Connector ...…........RS232/422/485 (COM2) Selection .......
  • Page 4 Contents CHAPTER 3 SOFTWARE UTILITIES Introduction …………........... VGA Driver Utility …………………………………… Flash BIOS Update ............LAN Driver Utility …........... Watchdog Timer Configuration ........CHAPTER 4 GREEN PC FUNCTION Power Saving Block Diagram ........CPU Doze Mode ............System Standby Mode ........... System Suspend Mode ..........
  • Page 5 Contents Interrupt Map ................RTC & CMOS RAM Map ............Timer & DMA Channels Map ..........I/O & Memory Map ..............APPENDIX C TROUBLE SHOOTING Trouble Shooting for Error Messages ........Trouble Shooting for POST Codes ...........

  • Page 6: Chapter 1 Introduction

    CHAPTER INTRODUCTION This chapter gives you the information for Prox-1690. It also outlines the System specification. Section includes: About This Manual System Specifications Safety precautions Experienced users can skip to chapter 2 on page 2-1 for Quick Start. Page:1-1...

  • Page 7: About This Manual

    1-1. ABOUT THIS MANUAL Thank you for purchasing our Prox-1690 Socket 370 Embedded Card with VGA / Dual LAN, which is fully PC / AT compatible. Prox-1690 provides faster processing speed, greater expandability and can handle more task than before. This manual is designed to assist you how to install and set up the system.

  • Page 8: System Specification

    UNIVERSAL SERIAL BUS : Universal Serial Bus Connector on board, supports up to 2 USB ports. BUS SUPPORT : External ISA/PCI BUS; PICMG Spec. Internal PCI Bus for VGA, IDE, PPCI, & LAN. Prox-1690 USER ′ S MANUAL Page: 1-3...
  • Page 9 Two RJ-45 Jack on board. SERIAL PORT : Two high speed 16550 Compatible UARTs with Send / Receive 16 Byte FIFOs. COM1 for RS232; COM2 for RS232/422/485. MIDI Compatible. Programmable Baud Rate Generator. Prox-1690 USER ′ S MANUAL Page: 1-4...
  • Page 10 ISA Bus 8MHz PCI Bus 33MHz PPCI Bus 33MHz 12Mbit/sec DMA CONTROLLER : 82C37 x 2 DMA CHANNELS : INTERRUPT CONTROLLERS : 82C59 x 2 INTERRUPT LEVELS : OPERATING TEMPERATURE : 0 to 60°C. Prox-1690 USER ′ S MANUAL Page: 1-5...

  • Page 11: Safety Precautions

    3. Disconnect power when you change any hardware devices. For instance, when you connect a jumper or install any cards, a surge of power may damage the electronic components or the whole system. Prox-1690 USER ′ S MANUAL Page: 1-6...

  • Page 12: Chapter 2 Hardware Configuration

    CHAPTER HARDWARE CONFIGURATION ** QUICK START ** Helpful information describes the jumper & connector settings, and component locations. Section includes: Jumper & Connector Quick Reference Table Component Locations Configuration and Jumper settings Connector’s Pin Assignments Page 2-1...

  • Page 13: Jumper & Connector Quick Reference Table

    Reset/NMI/Clear Watchdog ……………………... LAN Connector ........…..LAN1, LAN2 Memory Installation ........…..DIMM1, DIMM2 DIMM3 ……………………………… PPCI Connector ……………..…………………... PPCI CPU Type Selection ……………………………... JP14, JP15 Reserved Pin ……………………………………... JP2, JP3, JP5 …………………………………….. JP13 ’ Page: 2-2 Prox-1690 USER S MANUAL...

  • Page 14: Component Locations

    Chapter 2 Hardware Configuration 2-2. COMPONENT LOCATIONS LAN1 LAN2 EXKB 9 10 12887 Prox-1690 Connector, Jumper and Component locations ’ Page: 2-3 Prox-1690 USER S MANUAL...

  • Page 15: How To Set The Jumpers

    PIN1 & PIN2 to create one setting and shorting. You can either connect PIN2 & PIN3 to create another setting. The same jumper diagrams are applied all through this manual. The figure below shows what the manual diagrams look and what they represent. ’ Page: 2-4 Prox-1690 USER S MANUAL...
  • Page 16 Jumper Block looks like this JUMPER SETTINGS 2 pin Jumper close(enabled) Looks like this 3 pin Jumper 2-3 pin close(enabled) Looks like this Jumper Block 1-2 pin close(enabled) Looks like this ’ Page: 2-5 Prox-1690 USER S MANUAL...

  • Page 17: Com Port Connector

    Chapter 2 Hardware Configuration 2-4. COM PORT CONNECTOR Prox-1690 possesses two Communication Port namely the COM1 and COM2. The difference between the two is that COM1 is fixed for RS-232, while COM2 is selectable for RS-232/422/485. COM1 : COM1 Connector...

  • Page 18: Rs232/422/485 (Com2) Selection

    The jumper settings are as follows : COM 2 RS-232 RS-422 RS-485 Function Open Jumper 9-10 9-10 setting 11-12 11-12 (pin closed) 13-14 13-14 15-16 15-16 17-18 17-18 19-20 19-20 Jumper illustration *** Manufactory default --- RS-232. ’ Page: 2-7 Prox-1690 USER S MANUAL...

  • Page 19: Solid-State Disk Socket

    Chapter 2 Hardware Configuration 2-6. SOLID-STATE DISK SOCKET SSD : 32pin Disk-on-chip Socket The pin assignments are as follows: ASSIGNMENT ASSIGNMENT SA12 SA10 SA11 ’ Page: 2-8 Prox-1690 USER S MANUAL...

  • Page 20: Ssd Memory Mapping Selection

    ROM SSD can be install as one of user’s hard disk drive. The SSD Memory Mapping Selections are as follows: JUMPER SETTING SSD Memory Map JUMPER (pin closed) ILLUSTRATION CC000h-CDFFFh D0000h-D1FFFh D4000h-D5FFFh D8000h-D9FFFh DC000h-DDFFFh E0000h-E1FFFh *** Manufactory default --- CC000h-CDFFFh ’ Page: 2-9 Prox-1690 USER S MANUAL...

  • Page 21: Keyboard Or Ps/2 Mouse Connector

    If User select to use Y-Cable, please set the jumper same as AT Keyboard. The jumper settings are as follows: JUMPER SETTING DEVICE JUMPER (pin closed) TYPE ILLUSTRATION AT KEYBOARD PS/2 MOUSE *** Manufactory default -- AT Keyboard ’ Page: 2-10 Prox-1690 USER S MANUAL...

  • Page 22: External Keyboard Connector

    The pin assignment is as follows : ASSIGNMENT RESET GROUND 2-12. HARD DISK DRIVE LED CONNECTOR HDL : Hard Disk Drive LED Connector The pin assignment is as follows : ASSIGNMENT HDD Active Signal ’ Page: 2-11 Prox-1690 USER S MANUAL...

  • Page 23: Cpu Fan Connector

    CPUFAN2 : CPU Fan2 connector The pin assignment is as follows: ASSIGNMENT +12V CPUFAN2 2-14. EXTERNAL SPEAKER CONNECTOR SPK : External Speaker Connector The pin assignment is as follows : ASSIGNMENT Speaker Signal Speaker Signal Speaker Signal ’ Page: 2-12 Prox-1690 USER S MANUAL...

  • Page 24: Vga Crt Connector

    Chapter 2 Hardware Configuration 2-15. VGA CRT CONNECTOR VGA : VGA CRT Connector The pin assignments are as follows: ASSIGNMENT GREEN BLUE HSYNC VSYNC ’ Page: 2-13 Prox-1690 USER S MANUAL...

  • Page 25: Hard Disk Drive Connector

    Chapter 2 Hardware Configuration 2-16. HARD DISK DRIVE CONNECTOR IDE1: Hard Disk Drive Connector The Prox-1690 possesses two HDD connectors, IDE1 and IDE2. The pin assignments are as follows: ASSIGNMENT ASSIGNMENT IDERST IDEREQ0 IDED7 IDEIOW IDED8 IDED6 IDEIOR IDED9 IDED5...
  • Page 26 ASSIGNMENT IDERST IDEREQ1 IDED7 IDEIOW IDED8 IDED6 IDEIOR IDED9 IDED5 IDERDY IDED10 PULL LOW IDED4 IDEDACK- IDED11 IDED3 IRQ14 IDED12 IDED2 IDEA1 IDED13 IDED1 IDEA0 IDED14 IDEA2 IDED0 IDECS1S IDED15 IDECS3S IDELEDS N.C. ’ Page: 2-15 Prox-1690 USER S MANUAL...

  • Page 27: Floppy Disk Drive Connector

    34-pin flat cable to attach the FDD on the board, and the other side is attaches two FDDs. The pin assignments are as follows : ASSIGNMENT ASSIGNMENT RWC- INDEX MOA- STEP TRK0 WRPRT RDATA HEAD DSKCHG ’ Page: 2-16 Prox-1690 USER S MANUAL...

  • Page 28: Lcd Panel Connector

    LCD : LCD Panel Connector The connector LCD is a 51-pin, dual-in-line header used for Flat Panel displays. The pin assignments are as follows : ASSIGNMENT ASSIGNMENT LCD VDD LCDVDD VDDSAFE VDDSAFE ENABKL SHFCLK ENVEE 12VSAFE 12VSAFE ’ Page: 2-17 Prox-1690 USER S MANUAL...

  • Page 29: Printer Connector

    AUTFE ERROR INIT SLCTIN BUSY SLCT 2-20. POWER LED & KEYLOCK CONNECTOR KBL : Power LED & Keylock Connector The pin assignments are as follows : ASSIGNMENT Power LED Ground Keyboard INT Ground ’ Page: 2-18 Prox-1690 USER S MANUAL...

  • Page 30: Green Function Connector

    GRN: Green Function Connector The pin assignments are as follows: ASSIGNMENT EXTSMI- 2-22. UNIVERSAL SERIAL BUS CONNECTOR USB: Universal Serial Bus Connector The pin assignments are as follows: ASSIGNMENT USBP∅− USBP∅+ USBP1− USBP1+ ’ Page: 2-19 Prox-1690 USER S MANUAL...

  • Page 31: Irda Connector

    The pin assignments are as follows: Panel LCD VDD JUMPER SETTING JUMPER Selection (pin closed) ILLUSTRATION LCD VDD 5V LCD VDD 3.3V 2-24. IRDA CONNECTOR IR : IrDA (Infrared) Connector The pin assignments are as follows: ASSIGNMENT ’ Page: 2-20 Prox-1690 USER S MANUAL...

  • Page 32: Lan Connector

    Master, which means one of the PCI Bus Masters is occupied. The LAN Bus Master is same as 1st PCI Slot on the backplane. When the LAN chipset is on-board, the 1st PCI slot on backplane would fail even if LAN function is disabled. ’ Page: 2-21 Prox-1690 USER S MANUAL...

  • Page 33: Reset/Nmi/Clear Watchdog

    2-26. RESET / NMI / CLEAR WATCHDOG JP6 (1-2) : For Reset JP6 (3-4) : For NMI JP6 (5-6) : For Clear Watchdog The pin assignments are as follows: ASSIGNMENT WDGRST WDGRSTJ WDGNMI IOCHKJ CLRWDG ’ Page: 2-22 Prox-1690 USER S MANUAL...

  • Page 34: Memory Installation

    Chapter 2 Hardware Configuration 2-27. MEMORY INSTALLATION Prox-1690 Socket 370 Embedded Card support up to 768MB in 3 SDRAM banks. DRAM BANK CONFIGURATION DIMM 1 DIMM 2 DIMM3 TOTAL MEMORY 128M 160M 128M 128M 160M 192M 128M 128M 128M 160M...

  • Page 35: Ppci Connector

    Chapter 2 Hardware Configuration 2-28. PPCI CONNECTOR You will find a PPCI connector in our Prox-1690. This connector is used to connect our SCSI daughter boards. The pin assignments are as follows: ASSIGNMENT ASSIGNMENT AD10 AD11 AD12 AD13 AD14 AD15...

  • Page 36: Cpu Type Selection

    The CPU type selections are shown as follows: JUMPER SETTING JUMPER CPU TYPE ILLUSTRATION (pin closed) JP14 JP15 Pentium III JP14 JP15 Celeron™ JP14 JP15 *** Manufacturing Default is set as Pentium III. ’ Page: 2-25 Prox-1690 USER S MANUAL...
  • Page 37 Chapter 2 Hardware Configuration ’ Page: 2-26 Prox-1690 USER S MANUAL...

  • Page 38: Chapter 3 Software Utilities

    CHAPTER SOFTWARE UTILITIES This chapter comprises the detailed information of VGA driver, LAN driver and Flash BIOS update. It also describes how to install the watchdog timer configuration. Section includes: VGA Driver Utility Flash BIOS Update LAN Driver Utility Watchdog Timer Configuration Page: 3-1...

  • Page 39: Introduction

    Chapter 3 Software Configuration 3-1. INTRODUCTION Enclosed with our Prox-1690 package is our driver utility, which may comes in a form of a CD ROM disc or floppy diskettes. For CD ROM disc user, you will only need some of the files contained in the CD ROM disc, please...

  • Page 40: Flash Bios Update

    Utility Disk for system BIOS and VGA BIOS update. 3-3-2. To update VGA BIOS for LCD Flat Panel Display: As Prox-1690 user, you have to update the VGA BIOS for your specific LCD flat panel you are going to use. For doing this, you need two files.
  • Page 41 File Name to Program: B9xxxxxx.bin Checksum: XXXXX Reset System or Power off to accomplish update process! F1: Reset F10: Exit Please reset or power off the system, and then the Flash BIOS is fully implemented. Prox-1690 USER ′ S MANUAL Page:3-4...

  • Page 42: Lan Driver Utility

    Chapter 3 Software Configuration 3-4. LAN DRIVER UTILITY 3-4-1. Introduction Prox-1690 Embedded Card is enhanced with dual LAN function that can support various network adapters. Installation programs for LAN drivers are listed as follows: For more details on Installation procedure, please refer to INFO directory found on LAN DRIVER UTILITY.

  • Page 43: Watchdog Timer Configuration

    Likewise, when you want to disable the function, write I/O port 441H , the system will run the command to stop the Watchdog function. In Prox-1690 watchdog function, you must write your program so when it writes I/O port address 443 for enable watchdog and write I/O port address 441 for disable watchdog.

  • Page 44: Chapter 4 Green Pc Function

    CHAPTER GREEN PC FUNCTION This chapter gives you the concise information for Green PC Function. Section includes: ! Power Saving Block Diagram ! CPU Doze Mode ! System STANDBY Mode ! System SUSPEND Mode Page: 4-1...

  • Page 45: Power Saving Block Diagram

    4. Level 1 cache are disabled. 5. VGA monitor displays blank screen. 6. Fixed disk driver motor will be spin off. 7. Any activity occurs, system will exit from Standby mode to On mode. Prox-1690 USER ′ S MANUAL Page: 4-2...

  • Page 46: System Suspend Mode

    6. Fixed disk driver motor will be spin off. 7. Monitor activity according to the setting of Advanced Setup. 8. When system in Suspend mode, only Keyboard / Mouse / Alarm resume can wakeup system. Prox-1690 USER ′ S MANUAL Page: 4-3...
  • Page 47 Chapter 4 Green PC Function Prox-1690 USER ′ S MANUAL Page: 4-4...

  • Page 48: Chapter 5 Award Bios Setup

    CHAPTER AWARD BIOS SETUP This chapter states out how to set up the Award BIOS. Section includes: Introduction Entering Setup The Standard CMOS Setup The BIOS Features Setup The Chipset Features Setup Power Management Setup PNP/PCI Configuration Load BIOS defaults Integrated Peripherals IDE HDD Auto Detection Save and Exit Setup...

  • Page 49: Introduction

    5-1. INTRODUCTION This chapter will show you the function of a BIOS in managing the features of your system. The Prox-1690 Socket 370 Embedded Card is equipped with the BIOS for system chipset from Award Software Inc. This page briefly explains the function of a BIOS in managing the special features of your system.

  • Page 50: Entering Setup

    As you highlight each item, a brief description of that item's function will appear in the lower window. If you have a color monitor you can use the Shift F2 keys to scroll through the various color combinations available. Prox-1690 USER ′ S MANUAL Page: 5-3...

  • Page 51: The Standard Cmos Setup

    Information on each category is as follows: Date: < Month >, < Date > and <Year >. Ranges for each value are in the CMOS Setup Screen, and the week-day will skip automatically. Prox-1690 USER ′ S MANUAL Page: 5-4...
  • Page 52 This is the number designation for a drive with certain identification parameters. CYLS.: This is the number of cylinders found in the specified drive type. HEADS: This is the number of heads found in the specified drive type. Prox-1690 USER ′ S MANUAL Page: 5-5...
  • Page 53 This item determines whether the computer will stop when error is detected during power up. The available options are No errors, All errors, All, But Keyboard, All, but Diskette, and All, But Disk/Key. Prox-1690 USER ′ S MANUAL Page: 5-6...
  • Page 54 1024 65535 1023 1024 65535 1023 1024 65535 1023 1024 65535 1023 1024 65535 1023 65535 1023 65535 1024 65535 1023 1024 65535 1023 65535 65535 65335 AUTO Award Hard Disk Type Table Prox-1690 USER ′ S MANUAL Page: 5-7...

  • Page 55: The Bios Features Setup

    A brief introduction of each setting is given below. VIRUS WARNING: When enabled, the BIOS will supervise the boot sector and partition table of the hard disk drive for any attempt for modification. Prox-1690 USER ′ S MANUAL Page: 5-8...
  • Page 56 1Mbytes. Initially the gate A20 was handled via a pin on the keyboard. Today, while keyboards still provide this support, it is more common and much faster for the sytem chipset to provide support for gate A20. Prox-1690 USER ′ S MANUAL Page: 5-9...
  • Page 57 PCI/VGA or not. MPS VERSION CONTROL FOR OS: The BIOS supports versions 1.1 and 1.4 of the Intel® multiprocessor specification. Select the version supported by the operating system running on this computer. Prox-1690 USER ′ S MANUAL Page: 5-10...
  • Page 58 Video Shadow will increase the video speed. C8000-CBFFF SHADOW ~ DC000-DFFFF SHADOW: These categories determine whether option ROMs will be copied to RAM. An example of such option ROM would be support of on-board SCSI. Prox-1690 USER ′ S MANUAL Page: 5-11...

  • Page 59: Chipset Features Setup

    Auto Configuration selects predetermined optimal values of chipset parameters. When disabled, chipset parameters revert to setup information stored in CMOS. Many fields in this screen are not available when Auto Configuration is Enabled. Prox-1690 USER ′ S MANUAL Page: 5-12...
  • Page 60 When Enabled, all CPU cycles to SDRAM result in an All Banks Precharge Command on the SDRAM interface. DRAM DATA INTEGRITY MODE: Select parity or ECC (error-correcting code), according to the type of installed DRAM. Prox-1690 USER ′ S MANUAL Page: 5-13...
  • Page 61 ISA cards. This memory must be mapped into the memory space below 16MB. PASSIVE RELEASE: When Enabled, CPU to PCI bus accesses is allowed during passive release. Otherwise, the arbiter only accepts another PCI master access to local DRAM. Prox-1690 USER ′ S MANUAL Page: 5-14...
  • Page 62 This item displays the current CPU temperature, if your computer contains a monitoring system. CURRENT CPUFAN1/CPUFAN2 SPEED: This item displays the current system speed of the CPU fans, if your computer contains a monitoring system. Prox-1690 USER ′ S MANUAL Page: 5-15...

  • Page 63: Power Management Setup

    Power Saving, and User Define. PM CONTROL BY APM: When set to “Yes”, an Advanced Power Management device will be activated to enhance the Max. Power Saving mode and stop the CPU internal clock. Prox-1690 USER ′ S MANUAL Page: 5-16...
  • Page 64 SUSPEND MODE: When enabled and after the set time of system inactivity, all device except the CPU will be shut off. Prox-1690 USER ′ S MANUAL Page: 5-17...
  • Page 65 When enabled, an event occurring on each device listed below restarts the global time for standby mode: IRQ[3-7,9-15], NMI Primary IDE 0 Primary IDE 1 Secondary IDE 0 Secondary IDE 2 Floppy Disk Serial Port Parallel Port Prox-1690 USER ′ S MANUAL Page: 5-18...

  • Page 66: Pnp/Pci Configuration

    You can manually configure the PnP/PCI Device‘s IRQ. Highlight the selected item and pressing <F1> key, the all options for the desired selection will be displayed for choice. Prox-1690 USER ′ S MANUAL Page: 5-19...
  • Page 67 PCI/ISA PnP Devices It complaint with the Plug and Play standard, whether designed for PCI or ISA bus architecture. USED MEM BASE ADDR: Select a base address for the memory area used by any peripheral that requires high memory. Prox-1690 USER ′ S MANUAL Page: 5-20...

  • Page 68: Load Bios Defaults

    Load BIOS Default ( Y / N ) ? Y To use the BIOS defaults, change the prompt to "Y" and press < Enter >, the CMOS is load automatically when you power on the Prox-1690. 5-9. LOAD SETUP DEFAULTS AUTO CONFIGURATION WITH SETUP DEFAULTS This Main Menu item uses the default SETUP values.

  • Page 69: Integrated Peripherals

    User has to use select the desired option. Having made all the setting according to your selections. Press <Esc> to return to the Main Menu. Prox-1690 USER ′ S MANUAL Page: 5-22...

  • Page 70: Password Setting

    Features Setup Menu and its Security Option. If the Security Option is set to “System”, the password will be required both at boot and at entry to Setup. If set to “Setup”, prompting will only occurs when trying to enter Setup. Prox-1690 USER ′ S MANUAL Page: 5-23...
  • Page 71 〝PASSWORD SETTING〞a message will appear at the center. Password Disabled!!! Press any key to continue... Press < Enter > and the password will be disabled. Once the password is disabled, you can enter Setup freely. Prox-1690 USER ′ S MANUAL Page: 5-24...

  • Page 72: Ide Hdd Auto Detection

    3. Enter Y or N to confirm the acceptance of the parameter reported by BIOS, then press the <ENTER> key. The process will repeat again form Primary Slave, Secondary Master and Secondary Slave Hard Disks. Prox-1690 USER ′ S MANUAL Page: 5-25...

  • Page 73: Save & Exit Setup

    You may call up the setup program at any time to adjust any of the individual items by pressing the <Del> key during boot up. Prox-1690 USER ′ S MANUAL Page: 5-26...
  • Page 74 Quit Without Saving (Y/N) ? Y LOAD BIOS DE SAVING LOAD SETUP DEFAULTS ↑↓→← Esc : Quit :SELECT ITEM F10 : Save & Exit Setup (Shift)F2 : Change Color Abandon all Datas & Exit SETUP Prox-1690 USER ′ S MANUAL Page: 5-27...
  • Page 75 Chapter 5 Award BIOS Setup Prox-1690 USER ′ S MANUAL Page: 5-28...

  • Page 76: Appendix A Expansion Bus

    APPENDIX EXPANSION BUS This appendix indicates the pin assignments. Section includes: ! ISA BUS Pin Assignment ! PCI BUS Pin Assignment Page: A-1...
  • Page 77 SD12 -DRQ3 SA15 SD13 -DACK1 SA14 -MASTER SD14 -DRQ1 SA13 SD15 -REFRESH SA12 BCLK SA11 IRQ7 SA10 IRQ6 SA09 IRQ5 SA08 IRQ4 SA07 IRQ3 SA06 -DACK2 SA05 SA04 BALE SA03 SA02 SA01 SA00 Prox-1690 USER ′ S MANUAL Page: A-2...

  • Page 78: Pci Bus Pin Assignment

    AD30 AD08 C/BE0# AD29 +3.3V AD07 +3.3V AD28 +3.3V AD06 AD27 AD26 AD05 AD04 AD25 AD03 +3.3V AD24 AD02 C/BE3# GNT2# AD01 AD00 AD23 +3.3V +5V(I/O) +5V(I/O) AD22 ACK64# REQ64# AD21 AD20 AD19 Prox-1690 USER ′ S MANUAL Page: A-3...
  • Page 79 Appendix A EXPANSION BUS Prox-1690 USER ′ S MANUAL Page: A-4...

  • Page 80: Interrupt Map

    APPENDIX TECHNICAL SUMMARY This section introduce you the maps concisely. Section includes: ! Block Diagram ! Interrupt Map ! RTC & CMOS RAM Map ! Timer & DMA Channels Map ! I / O & Memory Map Page: B-1...

  • Page 81: Appendix B Technical Summary

    ADD / DATA DATA CNTL CNTL ADDR ADD / DATA CNTL CNTL DATA ADD / DATA ADDR DATA DATA CNTL ADDR ADDR SM BUS CNTL DATA DATA RESET/NMI ADD / DATA ADDR CNTL/DATA/ADDR ADDR ADDR Prox-1690 USER ′ S MANUAL Page: B-2...
  • Page 82 Keyboard output buffer full Cascade for IRQ 8-15 Serial port 2 Serial port 1 Parallel port 2 Floppy Disk adapter Parallel port 1 RTC clock Available Available Available Available Math coprocessor Hard Disk adapter Available Prox-1690 USER ′ S MANUAL Page: B-3...

  • Page 83: Rtc & Cmos Ram Map

    Extension memory low byte Extension memory high byte Reserved for extension memory low byte Reserved for extension memory high byte Date Century byte Information Flag 34-3F Reserve 40-7f Reserved for Chipset Setting Data Prox-1690 USER ′ S MANUAL Page: B-4...

  • Page 84: Timer & Dma Channels Map

    Assignment System timer interrupt DRAM Refresh request Speaker tone generator DMA Channel Map : DMA Channel Assignment Available IBM SDLC Floppy Disk adapter Channel-3 Available Cascade for DMA controller 1 Available Available Available Prox-1690 USER ′ S MANUAL Page: B-5...

  • Page 85: I/O & Memory Map

    Parallel port-2 2B0-2DF Graphics adapter controller 2F8-2FF Serial port-2 360-36F Net work ports 378-37F Parallel port-1 3B0-3BF Monochrome & Printer adapter 3C0-3CF EGA adapter 3D0-3DF CGA adapter 3F0-3F7 Floppy disk controller 3F8-3FF Serial port-1 Prox-1690 USER ′ S MANUAL Page: B-6...

  • Page 86: Appendix C Trouble Shooting

    APPENDIX TROUBLE SHOOTING This section outlines the errors may occur when you operate the system. It also gives you the suggestions on solving the problems. Section includes: ! Trouble Shooting for Error Messages ! Trouble Shooting for POST Code Page: C-1...

  • Page 87: Trouble Shooting For Error Messages

    When you can‘t find the boot device, insert a system disk into Drive A and press < Enter >. Make sure both the controller and cables are all in proper positions, also make sure the disk is formatted correct device. Then reboot the system. Prox-1690 USER ′ S MANUAL Page: C-2...
  • Page 88 Memory has been added or removed since the last boot. In EISA mode use Configuration Utility to re-configure the memory configuration. In ISA mode enter Setup and enter the new memory size in the memory fields. Prox-1690 USER ′ S MANUAL Page: C-3...

  • Page 89: Trouble Shooting For Post Codes

    03 : Initialize all the standard devices with default values Standard devices includes : DMA controller (8237). Programmable Interrupt Controller (8259). Programmable Interval Timer (8254). RTC chip. 05 : 1.Keyboard Controller Self-Test. 2.Enable Keyboard Interface. Prox-1690 USER ′ S MANUAL Page: C-4...
  • Page 90 0D : 1. Program some of the Chipset‘s value according to Setup. (Early Setup Value Program). 2. Measure CPU speed for display & decide the system clock speed. 3. Video initialization including Monochrome ,CGA, EGA/VGA. If no display device found, the speaker will beep. Prox-1690 USER ′ S MANUAL Page: C-5...
  • Page 91 2.Program all onboard super I/O chips (if any) including COM ports, LPT ports, FDD port..according to setup value. 3C : Set flag to allow users to enter CMOS Setup Utility. 3D : 1 Initialize Keyboard. 2 Install PS2 mouse. Prox-1690 USER ′ S MANUAL Page: C-6...
  • Page 92 -assign I/O, Memory, IRQ & DMA TO PnP ISA devices. -initialize all PnP ISA ROMs. 4. Program shadows RAM according to Setup settings. 5. Program parity according to Setup setting. 6. Power Management Initialization. -Enable/Disable global PM. -APM interface initialization. Prox-1690 USER ′ S MANUAL Page: C-7...
  • Page 93 (PnP BIOS only). 2. Clear memory that have been used. 3. Boot system via INT 19H. FF : System Booting. This means that the BIOS already pass the control right to the operating system. Prox-1690 USER ′ S MANUAL Page: C-8...
  • Page 94 Appendix C Trouble Shooting Prox-1690 USER ′ S MANUAL Page: C-9...
  • Page 95 Appendix C Trouble Shooting PRINTED IN TAIWAN Prox-1690 USER ′ S MANUAL Page: C-10...
