  • Page 1 USER’S MANUAL ProX-1640 P-III Socket 370 Full-size CPU Card With VGA / Sound / 2LAN Prox-1640 M0...
  • Page 2 Copyright Notice ProX-1640 Socket 370 Full-size CPU Card With VGA/Sound/2LAN OPERATION MANUAL COPYRIGHT NOTICE This operation manual is meant to assist both Embedded Computer manufacturers and end users in installing and setting up the system. The information contained in this document is subject to change without any prior notice.

  • Page 3: Table Of Contents

    Contents TABLE OF CONTENTS CHAPTER 1 INTRODUCTION About This Manual ............System Specification ............Safety Precautions ............CHAPTER 2 HARDWARE CONFIGURATION Jumper & Connector Quick Reference Table ....Component Locations ............ How to Set the Jumpers ..........COM Port Connector ………..………………………... COM Port RI &...
  • Page 4 Contents 2-31 Power Connector ............2-26 2-32 ATX Power Signal Connector ………………………... 2-26 2-33 ATX/AT Power Selection ……………………………. 2-27 2-34 ATX Power Button …………………………………… 2-27 2-35 PPCI Connector ………………………………………. 2-28 2-36 Memory Installation ………………………………….. 2-29 CHAPTER 3 SOFTWARE UTILITIES Introduction …………........... VGA Driver Utility …………………………………..
  • Page 5 Contents APPENDIX B EXPANSION BUS ISA Bus Pin Assignment ............PCI Bus Pin Assignment ............APPENDIX C TECHNICAL SUMMARY Block Diagram ................Interrupt Map ................RTC & CMOS RAM Map ............Timer & DMA Channels Map ..........I/O & Memory Map ..............APPENDIX D TROUBLE SHOOTING Trouble Shooting for Error Messages ........

  • Page 6: Chapter 1 Introduction

    CHAPTER INTRODUCTION This chapter gives you the information for Prox-1640. It also outlines the System specification. Section includes: About This Manual System Specifications Safety precautions Experienced users can skip to chapter 2 on page 2-1 for Quick Start. Page:1-1...

  • Page 7: About This Manual

    Chapter 1 Introduction 1-1. ABOUT THIS MANUAL Thank you for purchasing our Prox-1640 Socket 370 Embedded Card equipped with VGA / Sound / Dual LAN, which is fully PC / AT compatible. Prox-1640 provides faster processing speed, greater expandability and can handle more task than before.

  • Page 8: System Specification

    Universal Serial Bus Connector on board. Supports up to 2 USB ports. BUS SUPPORT : External ISA/PCI BUS (PICMG Spec.) Internal AGP Bus for VGA. Internal PCI Bus for PPCI, LAN & Sound. ′ Page: 1-3 Prox-1640 USER S MANUAL...
  • Page 9 Dual RJ-45 port, support for 10/100 BaseTx PCI Ethernet. Support Wake-On-LAN function. SERIAL PORT : Two high speed 16550 Compatible UARTs with Send / Receive 16 Byte FIFOs. COM1 for RS232. COM2 for RS232/422/485. ′ Page: 1-4 Prox-1640 USER S MANUAL...
  • Page 10 LED INDICATOR : System power. Hard Disk access. LAN LED indicator. BUS SPEED : ISA Bus 8MHz PCI Bus 33MHz PPCI Bus 33MHz 12Mbit/sec DMA CONTROLLER : 82C37 x 2 DMA CHANNELS : ′ Page: 1-5 Prox-1640 USER S MANUAL...

  • Page 11: Safety Precautions

    3. Disconnect power when you change any hardware devices. For instance, when you connect a jumper or install any cards, a surge of power may damage the electronic components or the whole system. ′ Page: 1-6 Prox-1640 USER S MANUAL...

  • Page 12: Chapter 2 Hardware Configuration

    CHAPTER HARDWARE CONFIGURATION ** QUICK START ** Helpful information describes the jumper & connector settings, and component locations. Section includes: Jumper & Connector Quick Reference Table Component Locations Configuration and Jumper settings Connector’s Pin Assignments Page 2-1...

  • Page 13: Jumper & Connector Quick Reference Table

    LAN Enable/Disable Selection ………………………… Power Connector ………………………………………. PWR1 ATX Power Signal Connector …..…………………….. ATX / AT Power Selection ……..………………………. JP6 ATX Power Button …………………………………….. PPCI Connector ……………..………………….……… PPCI Memory Installation ........…..……… DIMM1, DIMM2 ′ Page: 2-2 Prox-1640 USER S MANUAL...

  • Page 14: Component Locations

    Chapter 2 Hardware Configuration 2-2. COMPONENT LOCATIONS LAN1 LAN2 IRDA1 SPK1 HDL1 Prox-1640 Connector, Jumper and Component locations ′ Page: 2-3 Prox-1640 USER S MANUAL...

  • Page 15: How To Set The Jumpers

    PIN1 & PIN2 to create one setting and shorting. You can either connect PIN2 & PIN3 to create another setting. The same jumper diagrams are applied all through this manual. The figure below shows what the manual diagrams look and what they represent. ′ Page: 2-4 Prox-1640 USER S MANUAL...
  • Page 16 Jumper Block looks like this JUMPER SETTINGS 2 pin Jumper close(enabled) Looks like this 3 pin Jumper 2-3 pin close(enabled) Looks like this Jumper Block 1-2 pin close(enabled) Looks like this ′ Page: 2-5 Prox-1640 USER S MANUAL...

  • Page 17: Com Port Connector

    NDSR2 RTS- NRTS2 RTS+ NCTS2 CTS+ RI2/+12/+5V CTS- All COM port’s pin 9 is selectable for RI, +5V and +12V. For more information, please refer to our “COM Port RI & Voltage Selection”. ′ Page: 2-6 Prox-1640 USER S MANUAL...

  • Page 18: Com Port Ri & Voltage Selection

    2-5. COM PORT RI & VOLTAGE SELECTION JP2 : COM Port RI & Voltage Selection The selection are as follows : Selection Jumper Settings Jumper (pin closed) Illustrations COM1 +12V COM2 +12V 8-10 ***Manufacturing Default --- RI function. ′ Page: 2-7 Prox-1640 USER S MANUAL...

  • Page 19: Rs232/422/485 (Com2) Selection

    The COM2 Function selections are as follows : COM 2 RS-232 RS-422 RS-422 Function Open Jumper Settings 9-10 9-10 11-12 11-12 (pin closed) 13-14 13-14 15-16 15-16 17-18 17-18 19-20 19-20 Jumper Illustrations *** Manufactory default --- RS-232. ′ Page: 2-8 Prox-1640 USER S MANUAL...

  • Page 20: Solid-State Disk Socket

    Chapter 2 Hardware Configuration 2-7. SOLID-STATE DISK SOCKET SSD: 32pin Disk-on-chip Socket The pin assignments are as follows: ASSIGNMENT ASSIGNMENT SA12 SA10 SA11 ′ Page: 2-9 Prox-1640 USER S MANUAL...

  • Page 21: Ssd Memory Mapping Selection

    ROM SSD can be install as one of user’s hard disk drive. The SSD Memory Mapping Selections are as follows: JUMPER SETTING JUMPER SELECTION (pin closed) ILLUSTRATION CC000h-CDFFFh 11-12 D0000h-D1FFFh 9-10 D4000h-D5FFFh 11-12 D8000h-D9FFFh 9-10 DC000h-DDFFFh 11-12 *** Manufactory default --- CC000h-CDFFFh. ′ Page: 2-10 Prox-1640 USER S MANUAL...

  • Page 22: Keyboard Or Ps/2 Mouse Connector

    For Y-Cable user, please set the jumper same as AT keyboard. The jumper settings are as follows: DEVICE JUMPER SETTING JUMPER TYPE (pin closed) ILLUSTRATION KEYBOARD PS/2 MOUSE *** Manufactory default -- AT Keyboard ′ Page: 2-11 Prox-1640 USER S MANUAL...

  • Page 23: External Keyboard Connector

    ASSIGNMENT RESET SW RST1 GROUND 2-13. HARD DISK DRIVE LED CONNECTOR HDL1 : Hard Disk Drive LED Connector The pin assignment is as follows : ASSIGNMENT IDE LED IDE LED HDL1 IDE LED ′ Page: 2-12 Prox-1640 USER S MANUAL...

  • Page 24: External Speaker Connector

    The pin assignment is as follows : ASSIGNMENT SPEAKER SPEAKER SPK1 SPEAKER 2-15. POWER LED & KEYLOCK CONNECTOR KBL1 : Power LED & Keylock Connector The pin assignment is as follows : ASSIGNMENT KLOCK KBL1 ′ Page: 2-13 Prox-1640 USER S MANUAL...

  • Page 25: Clear Cmos Data Selection

    “Clear CMOS” as illustrated above. After five to six seconds, set the jumper back to “Normal” and power-on the computer. 2-17. CPU FAN CONNECTOR FAN1 : CPU Fan connector The pin assignment is as follows: ASSIGNMENT +12V FAN1 FAN1 ′ Page: 2-14 Prox-1640 USER S MANUAL...

  • Page 26: System Fan Connector

    +12V FAN2 FAN2 2-19. UNIVERSAL SERIAL BUS CONNECTOR USB: Universal Serial Bus Connector This connector can connect up to two USB port. The pin assignments are as follows: ASSIGNMENT USBP0− USBP0+ USBP1− USBP1+ ′ Page: 2-15 Prox-1640 USER S MANUAL...

  • Page 27: Irda Connector

    Maskable Interrupt, is used for serious conditions that demand the processor’s immediate attention, it cannot be ignored by the system unless it is shut off specifically. To clear NMI command, user should short the “Clear Watchdog” pin via push button. ′ Page: 2-16 Prox-1640 USER S MANUAL...

  • Page 28: Vga Crt Connector

    Chapter 2 Hardware Configuration 2-22. VGA CRT CONNECTOR VGA : VGA CRT Connector The pin assignments are as follows: ASSIGNMENT GREEN BLUE 5VDDCDA HSYNC VSYNC 5VDDCCL ′ Page: 2-17 Prox-1640 USER S MANUAL...

  • Page 29: Dvo Connector

    The pin assignments are as follows: DVO1 ASSIGNMENT ASSIGNMENT VCC12 VCC5 VCC5 VCC3.3 FTD0 VCC3.3 FTD1 VCC1.8 FTD2 5VFTSDA FTD3 5VFTSCL FTD4 FTBLNK# FTD5 SL_STALL FTD6 FTCLK0 FTD7 FTCLK1 FTD8 FTVSYNC FTD9 FTHSYNC FTD10 3VFTSCL FTD11 3VFTSDA ′ Page: 2-18 Prox-1640 USER S MANUAL...

  • Page 30: Sound Connector

    This connector is to be connected to W-Sound Adapter Card, for more information, please refer to Appendix A. 2-25. CD-IN CONNECTOR CN4 : CD-In Connector The pin assignments are as follows: ASSIGNMENT AUX L AUX R ′ Page: 2-19 Prox-1640 USER S MANUAL...

  • Page 31: Hard Disk Drive Connector

    Chapter 2 Hardware Configuration 2-26. HARD DISK DRIVE CONNECTOR IDE1: Hard Disk Drive Connector The Prox-1640 possesses two HDD connectors, which support ATA-100. The pin assignments are as follows: IDE1 ASSIGNMENT ASSIGNMENT IDERST PDD7 PDD8 PDD6 PDD9 PDD5 PDD10 PDD4...
  • Page 32 IDERST SDD7 SDD8 SDD6 SDD9 SDD5 SDD10 SDD4 SDD11 SDD3 SDD12 SDD2 SDD13 SDD1 SDD14 SDD0 SDD15 SDREQ SDIOW# SDIOR# SIORDY PULL LOW SDDACK# IRQ15 SDA1 S66 DETECT SDA0 SDA2 SDCS#1 SDCS#3 IDEACTS# ′ Page: 2-21 Prox-1640 USER S MANUAL...

  • Page 33: Floppy Disk Drive Connector

    34-pin flat cable to attach the FDD on the board, and the other side is attaches two FDDs. The pin assignments are as follows : FDD1 ASSIGNMENT ASSIGNMENT DENSEL# INDEX# MOTEA DRVB DRVA MOTEB STEP WDATA WGATE TK00 RDATA# SIDE1 DSKCHG ′ Page: 2-22 Prox-1640 USER S MANUAL...

  • Page 34: Printer Connector

    As to link the Printer to the card, you need a cable to connect both DB25 connector and parallel port. The pin assignments are as follows : ASSIGNMENT ASSIGNMENT AUTFE ERROR INIT SLCTIN BUSY SLCT ′ Page: 2-23 Prox-1640 USER S MANUAL...

  • Page 35: Lan Connector

    Master, which means one of the PCI Bus Masters is occupied. The When the LAN Bus Master is same as 1st PCI Slot on the backplane. LAN chipset is on-board, the 1st PCI slot on backplane would fail even if LAN function is disabled. ′ Page: 2-24 Prox-1640 USER S MANUAL...

  • Page 36: Lan Enable/Disable Selection

    LI LED ACTIVE LED 2-30. LAN ENABLE / DISABLE SELECTION JP5: LAN Enable / Disable Selection The selections are as follows: SELECTION JUMPER SETTING JUMPER (pin closed) ILLUSTRATION ENABLE DISABLE ***Manufacturing Default – Enable. ′ Page: 2-25 Prox-1640 USER S MANUAL...

  • Page 37: Power Connector

    The pin assignments are as follows: ASSIGNMENT PWR1 +12V +5V SBY PS_ON -12V 2-32. ATX POWER SIGNAL CONNECTOR CN2 : ATX Power Signal Connector The pin assignments are as follows: ASSIGNMENT +5V SB PWR_ON ′ Page: 2-26 Prox-1640 USER S MANUAL...

  • Page 38: Atx/At Power Selection

    “Power Supply Type” in Advanced Chipset Features. And also you must disable the ACPI Function in the Power Management found in BIOS. 2-34. ATX POWER BUTTON CN3 : ATX Power Button The pin assignment is as follows : ASSIGNMENT PANSWH ′ Page: 2-27 Prox-1640 USER S MANUAL...

  • Page 39: Ppci Connector

    Chapter 2 Hardware Configuration 2-35. PPCI CONNECTOR You will find a PPCI connector in our Prox-1640. This connector is used to connect our daughter boards. The pin assignments are as follows: PPCI ASSIGNMENT ASSIGNMENT AD10 AD11 AD12 AD13 AD14 AD15...

  • Page 40: Memory Installation

    Chapter 2 Hardware Configuration 2-36. MEMORY INSTALLATION Prox-1640 CPU Card is enhanced with two DIMM socket. DIMM 2 DIMM 1 DRAM BANK CONFIGURATION DIMM 1 DIMM 2 TOTAL MEMORY 32MB 32MB 32MB 32MB 64MB 64MB 64MB 64MB 32MB 96MB 64MB...
  • Page 41 Chapter 2 Hardware Configuration ′ Page: 2-30 Prox-1640 USER S MANUAL...

  • Page 42: Chapter 3 Software Utilities

    CHAPTER SOFTWARE UTILITIES This chapter comprises the detailed information of VGA driver, LAN driver, and Flash BIOS update. It also describes how to install the watchdog timer configuration. Section includes: VGA Driver Utility Flash BIOS Update LAN Driver Utility Intel Service Pack 6 Watchdog Timer Configuration Page: 3-1...

  • Page 43: Introduction

    Chapter 3 Software Configuration 3-1. INTRODUCTION Enclosed with our Prox-1640 package is our driver utility, which may comes in a form of a CD ROM disc or floppy diskettes. For CD ROM disc user, you will only need some of the files contained in the CD ROM disc, please...

  • Page 44: Flash Bios Update

    Utility Disk for system BIOS and VGA BIOS update. 3-3-2. To update VGA BIOS for LCD Flat Panel Display: As Prox-1640 user, you have to update the VGA BIOS for your specific LCD flat panel you are going to use. For doing this, you need two files.
  • Page 45 Select "Y", and the BIOS will be renewed. When you are refreshing the BIOS, do not turn off or reset the system, or you will damage the BIOS. After you have completed all the programming, the screen displays the table below: ′ Page:3-4 Prox-1640 USER S MANUAL...
  • Page 46 File Name to Program: B40xxxxx.bin Checksum: XXXXX Reset System or Power off to accomplish update process! F1: Reset F10: Exit Please reset or power off the system, and then the Flash BIOS is fully implemented. ′ Page:3-5 Prox-1640 USER S MANUAL...

  • Page 47: Lan Driver Utility

    Chapter 3 Software Configuration 3-4. LAN DRIVER UTILITY 3-4-1. Introduction Prox-1640 Embedded Card is enhanced with dual LAN function that can support various network adapters. Installation programs for LAN drivers are listed as follows: 1. Win 9x/ME program 2. Win NT4.0 program 3.

  • Page 48: Sound Driver Utility

    “D:\Sound\pathname” refers to the full path to the source files. 3. Click on the OK button or press the ENTER key. 4. Click on the “Next” and OK prompts as they appear. 5. Reboot the system to complete the driver installation. ′ Page:3-7 Prox-1640 USER S MANUAL...

  • Page 49: Intel Chipset Software Installation Utility

    Core PCI and ISAPNP Services AGP Support IDE/ATA33/ATA66 Storage Support USB Support Identification of Intel® Chipset Components in Device Manager 1. Win 9X/ME program 2. Win 2000 program 3. Win XP program ′ Page:3-8 Prox-1640 USER S MANUAL...
  • Page 50 3. Click Infinst_auto1.exe file for utility installation. 4. Follow the instructions on the screen to complete the installation. 5. Once installation is completed, shut down the system and restart in order for the changes to take effect. ′ Page:3-9 Prox-1640 USER S MANUAL...

  • Page 51: Watchdog Timer Configuration

    I/O port 441H, the system will run the command to stop the Watchdog function. In Prox-1640 watchdog function, you must write your program so when it writes I/O port address 443 for enable watchdog and write I/O port address 441 for disable watchdog.

  • Page 52: Chapter 4 Award Bios Setup

    CHAPTER AWARD BIOS SETUP This chapter shows how to set up the Award BIOS. Section includes: Introduction Entering Setup The Standard CMOS Features The Advanced BIOS Features The Advanced Chipset Features Integrated Peripherals Power Management Setup PNP/PCI Configuration PC Health Status Frequency/Voltage Control Load Fail-Safe Defaults Load Optimized Defaults...

  • Page 53: Introduction

    4-1. INTRODUCTION This chapter will show you the function of the BIOS in managing the features of your system. The Prox-1640 Socket 370 CPU Card is equipped with the BIOS for system chipset from Award Software Inc. This page briefly explains the function of the BIOS in managing the special features of your system.

  • Page 54: Entering Setup

    You may use the cursor the up/down keys to highlight the individual menu items. As you highlight each item, a brief description of the highlighted selection will appear at the bottom of the screen. ′ Page: 4-3 Prox-1640 USER S MANUAL...
  • Page 55 < Hour >, < Minute >, and < Second >. Use 24 hour clock format, i.e., for PM numbers, add 12 to the hour. For example: 4: 30 P.M. You should enter the time as 16:30:00. ′ Page: 4-4 Prox-1640 USER S MANUAL...
  • Page 56 Head – Set the number of read/write heads. c. Precomp - ***Warning! Setting a value of 65535 means no HDD. d. Landing Zone e. Sector – Set the number of sector per track ′ Page: 4-5 Prox-1640 USER S MANUAL...
  • Page 57 BASE MEMORY: Displays the amount of conventional memory detected during boot up. EXTENDED MEMORY: Displays the amount of extended memory detected during boot up. TOTAL MEMORY: Displays the total memory available in the system. ′ Page: 4-6 Prox-1640 USER S MANUAL...
  • Page 58 1024 65535 1023 1024 65535 1023 1024 65535 1023 1024 65535 1023 1024 65535 1023 65535 1023 65535 1024 65535 1023 1024 65535 1023 65535 65535 65335 AUTO Award Hard Disk Type Table ′ Page: 4-7 Prox-1640 USER S MANUAL...

  • Page 59: The Advanced Bios Features

    The user can select the system’s default speed, boot-up sequence, keyboard operation, shadowing and security. A brief introduction of each setting in the BIOS FEATURES SETUP program is given on the next few pages. ′ Page: 4-8 Prox-1640 USER S MANUAL...
  • Page 60 BOOT UP FLOPPY SEEK: You may enable / disable this item to define whether the system will look for a floppy disk drive to boot at power-on, or proceed directly to the hard disk drive. ′ Page: 4-9 Prox-1640 USER S MANUAL...
  • Page 61 Do not type anything and just press <Enter>, it will disable security. Once the security is disabled, the system will boot and you can enter Setup freely. ′ Page: 4-10 Prox-1640 USER S MANUAL...

  • Page 62: Advanced Chipset Features

    [by CAS# LT] RAS# Timing [Fast] RAS# Precharge Timing [Fast] IO Channel Check NMI [Disabled] ↑↓→←:Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help F5: Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults Chipset Features Setup Screen ′ Page: 4-11 Prox-1640 USER S MANUAL...
  • Page 63 VIDEO BIOS CACHEABLE: Select Enabled allows caching of the video BIOS ROM at C0000h-F7FFFh, resulting in better video performance. However, if any program writes to this memory area, a system error may result. ′ Page: 4-12 Prox-1640 USER S MANUAL...
  • Page 64 This allows you to select the power supply type. ON-CHIP VIDEO WINDOW SIZE: Select the on-chip video window size for VGA drive use. CAS# LATENCY: Select the local memory clock periods. PAGING MODE CONTROL: Select the paging mode control. ′ Page: 4-13 Prox-1640 USER S MANUAL...
  • Page 65 IO CHANNEL CHECK NMI: This field enables or disables IO channel check NMI. Before selecting this function, the user should check first that NMI function is enabled as described in chapter 2 (Reset/NMI/Clear Watchdog Selection) ′ Page: 4-14 Prox-1640 USER S MANUAL...

  • Page 66: Integrated Peripherals

    F6:Fail-Safe Defaults F7:Optimized Defaults Integrated Peripherals Setup Screen By moving the cursor to the desired selection and by pressing the <F1> key, the all options for the desired selection will be displayed for choice. ′ Page: 4-15 Prox-1640 USER S MANUAL...
  • Page 67 This item allows you to decide to active whether PCI Slot or on-chip VGA first. The choices are PCI Slot and Onboard. AC97 AUDIO: This item allows you to enable or disable to support AC97 Audio. ′ Page: 4-16 Prox-1640 USER S MANUAL...
  • Page 68 Select a DMA channel for the parallel port for use during ECP mode. PWRON AFTER PWR-FAIL: This item allows you to select if you want to power on the system after power failure. ′ Page: 4-17 Prox-1640 USER S MANUAL...

  • Page 69: Power Management Setup

    Power Management Setup Screen The “Power Management Setup” allows the user to configure the system to the most effectively save energy while operating in a manner consistent with your own style of computer use. ′ Page: 4-18 Prox-1640 USER S MANUAL...
  • Page 70 CPU will be shut off. HDD POWER DOWN: When enabled and after the set time of system inactivity, the hard disk drive will be powered down while all other devices remain active. ′ Page: 4-19 Prox-1640 USER S MANUAL...
  • Page 71 Enabled, even when the system is in a power down mode. (1) Primary IDE 0 (2) Primary IDE 1 (3) Secondary IDE 0 (4) Secondary IDE 1 (5) FDD, COM, LPT Port (6) PCI PIRQ[A-D]# ′ Page: 4-20 Prox-1640 USER S MANUAL...

  • Page 72: Pnp/Pci Configuration

    Normally, you leave this field Disabled. Select Enabled to reset Extended System Configuration Data (ESCD) when you exit Setup if you have installed a new add-on and the system configuration has caused such a serious conflict that the operating system cannot boot. ′ Page: 4-21 Prox-1640 USER S MANUAL...
  • Page 73 DMA RESOURCES: When resources are controlled manually, assign each system DMA channel a type, depending on the type of device using the DM channel. PCI/VGA PALETTE SNOOP: Leave this field at disabled. ′ Page: 4-22 Prox-1640 USER S MANUAL...

  • Page 74: Pc Health Status

    This item allows you to set the CPU shutdown Temperature. This function is only effective under Window 98 ACPI mode. +3.3V/+5V/+12V/-12V/-5V/5VSB: This item shows you the voltage of +3.3V/+5V/+12V/-12V/-5V/5VSB. VCORE: This item shows you the current system voltage. ′ Page: 4-23 Prox-1640 USER S MANUAL...

  • Page 75: Frequency/Voltage Control

    This setup menu allows you to specify your settings for frequency/voltage control. AUTO DETECT DIMM/PCI CLK: This item allows you to enable or disable auto detect DIMM/PCI Clock. SPREAD SPECTRUM MODULATED: This item allows you to enable or disable the spread spectrum modulate. ′ Page: 4-24 Prox-1640 USER S MANUAL...

  • Page 76: Load Fail-Safe Defaults

    When you press <Enter> on this category, you get a confirmation dialog box with a message similar to the following: Load Optimized Defaults ( Y/N ) ? N Pressing "Y" loads the default values that are factory setting for optimal performance system operations. ′ Page: 4-25 Prox-1640 USER S MANUAL...

  • Page 77: Password Setting

    PASSWORD DISABLED!!! Press any key to continue... Press the < Enter > key again and the password will be disabled. Once the password is disabled, you can enter Setup freely. ′ Page: 4-26 Prox-1640 USER S MANUAL...

  • Page 78: Save & Exit Setup

    You may always call up the setup program at any time to adjust any of the individual items by pressing the <Del> key during boot up. ′ Page: 4-27 Prox-1640 USER S MANUAL...

  • Page 79: Exit Without Saving

    Quit Without Saving (Y/N)? N ►PnP/PCI Configura etup ►PC Health Status Saving ↑↓→← Esc : Quit F9 : Menu in BIOS : Select Item F10 : Save & Exit Setup Abandon all Datas ′ Page: 4-28 Prox-1640 USER S MANUAL...

  • Page 80: Appendix A Adapter Card

    APPENDIX ADAPTER CARD This appendix explains the adapter card. Section includes: W-Sound Adapter Card Page: A-1...

  • Page 81: Wsound Adapter Card

    You will also find W-Sound Adapter Card in our package. This card is designed as a converter of sound connector found in our system board. Below, you will find an illustration of our W-Sound Adapter Card: AUDIO-OUT (SPK) LINE-IN ′ Page: A-2 Prox-1640 USER S MANUAL...
  • Page 82 Audio-Out (SPK) : Speaker Connector The pin assignments are as follows : AUDIO-OUT (SPK) ASSIGNMENT SPK-L SPK-R LINE-IN : Line Input Connector The pin assignments are as follows : LINE-IN ASSIGNMENT LINE-R LINE-L ′ Page: A-3 Prox-1640 USER S MANUAL...
  • Page 83 (1) Turn-off the computer system (2) Check the Sound cable enclosed with the package. (3) Connect one end of the cable to the Sound connector (CN1 found in Prox-1640 board), and the other end to the JP1 of the W-sound Adapter Card. ′...

  • Page 84: Appendix B Expansion Bus

    APPENDIX EXPANSION BUS This appendix indicates the pin assignments. Section includes: ISA BUS Pin Assignment PCI BUS Pin Assignment Page: B-1...

  • Page 85: Isa Bus Pin Assignment

    SA16 DRQ7 SD12 -DRQ3 SA15 SD13 -DACK1 SA14 -MASTER SD14 -DRQ1 SA13 SD15 -REFRESH SA12 BCLK SA11 IRQ7 SA10 SA09 IRQ5 SA08 IRQ4 SA07 IRQ3 SA06 SA05 SA04 BALE SA03 SA02 SA01 SA00 ′ Page: B-2 Prox-1640 USER S MANUAL...

  • Page 86: Pci Bus Pin Assignment

    AD10 +5V(I/O) REQ2# AD09 AD31 AD30 AD08 C/BE0# AD29 AD07 AD28 AD06 AD27 AD26 AD05 AD04 AD25 AD03 AD24 AD02 C/BE3# GNT2# AD01 AD00 AD23 +5V(I/O) +5V(I/O) AD22 ACK64# REQ64# AD21 AD20 AD19 ′ Page: B-3 Prox-1640 USER S MANUAL...
  • Page 87 Appendix B Expansion Bus ′ Page: B-4 Prox-1640 USER S MANUAL...
  • Page 88 APPENDIX TECHNICAL SUMMARY This section introduce you the maps concisely. Section includes: Block Diagram Interrupt Map RTC & CMOS RAM Map Timer & DMA Channels Map I / O & Memory Map Page: C-1...

  • Page 89: Appendix C Technical Summary Block Diagram

    Socket 370 Processors Clock Termination SOLANO MEMORY GMCH 2 DIMM MODULE BRIDGE IT 8888F ICH2 LAN1 82562 SOUND AD 1881 PCI BUS PCI Slot LPC I/O Monitor LAN2 82559 KB/MS IrDA Parallel Serial ′ Page: C-2 Prox-1640 USER S MANUAL...

  • Page 90: Interrupt Map

    Appendix C Technical Summary INTERRUPT MAP ASSIGNMENT System TIMER Keyboard Cascade Serial port 2 Serial port 1 Available Floppy Parallel port 1 RTC clock Available Available Available PS/2 Mouse Math coprocessor IDE1 IDE2 ′ Page: C-3 Prox-1640 USER S MANUAL...

  • Page 91: Rtc & Cmos Ram Map

    Extension memory low byte Extension memory high byte Reserved for extension memory low byte Reserved for extension memory high byte Date Century byte Information Flag 34-3F Reserve 40-7f Reserved for Chipset Setting Data ′ Page: C-4 Prox-1640 USER S MANUAL...

  • Page 92: Timer & Dma Channels Map

    Timer Channel Map : Timer Channel Assignment System timer interrupt DRAM Refresh request Speaker tone generator DMA Channel Map : DMA Channel Assignment Available ECP / Available Floppy ECP / Available Cascade Available Available Available ′ Page: C-5 Prox-1640 USER S MANUAL...

  • Page 93: I/O & Memory Map

    Parallel port-2 2B0-2DF Graphics adapter controller 2F8-2FF Serial port-2 360-36F Net work ports 378-37F Parallel port-1 3B0-3BF Monochrome & Printer adapter 3C0-3CF EGA adapter 3D0-3DF CGA adapter 3F0-3F7 Floppy disk controller 3F8-3FF Serial port-1 ′ Page: C-6 Prox-1640 USER S MANUAL...

  • Page 94: Appendix D Trouble Shooting

    APPENDIX TROUBLE SHOOTING This section outlines the errors may occur when you operate the system. It also gives you the suggestions on solving the problems. Section includes: Trouble Shooting for Error Messages Trouble Shooting for POST Code Page: D-1...

  • Page 95: Trouble Shooting For Error Messages

    Then reboot the system. DISKETTE DRIVES OR TYPES MISMATCH ERROR - RUN SETUP : Type of diskette drive installed in the system is different from the CMOS definition. Run Setup to reconfigure the drive type correctly. ′ Page: D-2 Prox-1640 USER S MANUAL...
  • Page 96 Cannot initialize controller. Make sure the cord is correctly and firmly installed in the bus. Be sure the correct hard drive is selected in Setup. Also check to see if any jumper needs to be set correctly on the hard drive. ′ Page: D-3 Prox-1640 USER S MANUAL...
  • Page 97 Memory has been added or removed since the last boot. In EISA mode use Configuration Utility to reconfigure the memory configuration. In ISA mode enter Setup and enter the new memory size in the memory fields. ′ Page: D-4 Prox-1640 USER S MANUAL...
  • Page 98 The board installed is not responding to the ID request, or no board ID has been found in the indicated slot. Note: When this error appears, the system will boot in ISA mode, which allows you to run the EISA Configuration Utility. ′ Page: D-5 Prox-1640 USER S MANUAL...
  • Page 99 Unable to recalibrate fixed disk. Hard Disk(S) Fail (08) : Sector Verify failed. Keyboard is locked out – Unlock the key : BIOS detect the keyboard is locked. P17 of keyboard controller is pulled low. ′ Page: D-6 Prox-1640 USER S MANUAL...
  • Page 100 BIOS ROM checksum error – System halted : The checksum of ROM address F0000H-FFFFFH is bad. Memory test fail : BIOS reports the memory test fail if the onboard memory is tested error. ′ Page: D-7 Prox-1640 USER S MANUAL...

  • Page 101: Trouble Shooting For Post Codes

    Reserved. 03h : Initial Superio_Early_Init switch. Reserved. 04h : 05h : 1. Blank out screen 2. Clear CMOS error flag Reserved 06h : 07h : 1. Clear 8042 interface 2. Initialize 8042 self-test ′ Page: D-8 Prox-1640 USER S MANUAL...
  • Page 102 Also set real-time clock power status, and then check for override. Reserved 13h : 14h : Program chipset default values into chipset. Chipset default values are MODBINable by OEM customers. Reserved 15h : 16h : Initial Early_Init_Onboard_Generator switch. ′ Page: D-9 Prox-1640 USER S MANUAL...
  • Page 103 PCI & DIMM slots. 5. Early PCI initialization: -Enumerate PCI bus number -Assign memory & I/O resource -Search for a valid VGA device & VGA BIOS, and put it into C000:0. ′ Page: D-10 Prox-1640 USER S MANUAL...
  • Page 104 2Dh : 2. Put information on screen display, including Award title, CPU type, CPU speed … Reserved 2Eh : 2Fh : Reserved Reserved Reserved Reserved Reset keyboard except Winbond 977 series Super I/O chips. ′ Page: D-11 Prox-1640 USER S MANUAL...
  • Page 105 3Dh : 3Eh : Test 8259 interrupt mask bits for channel 1. Reserved 3Fh : Test 8259 interrupt mask bits for channel 2. Reserved Reserved Test 8259 functionality. Reserved Reserved Reserved Initialize EISA slot ′ Page: D-12 Prox-1640 USER S MANUAL...
  • Page 106 53h : 54h : Reserved 55h : Display number of processors (multi-processor platform) Reserved 56h : 57h : 1. Display PnP logo 2. Early ISA PnP initialization -Assign CSN to every PnP device. ′ Page: D-13 Prox-1640 USER S MANUAL...
  • Page 107 Reserved 64h : Reserved Initialize PS/2 Mouse 65h : 66h : Reserved 67h : Prepare memory size information for function call: INT 15h ax=E820h 68h : Reserved 69h : Turn on L2 cache. ′ Page: D-14 Prox-1640 USER S MANUAL...
  • Page 108 Detect & install all IDE devices: HDD, LS120, ZIP, CDROM….. 76h : Reserved Detect serial ports and parallel ports 77h : 78h : Reserved 79h : Reserved Detect and install co-processor 7Ah : ′ Page: D-15 Prox-1640 USER S MANUAL...
  • Page 109 4. Setup ACPI table at top of memory. 5. Invoke ISA adapter ROMs. 6. Assign IRQs to PCI devices. 7. Initialize APM. 8. Clear noise of IRQs. 86h : Reserved Reserved 87h : ′ Page: D-16 Prox-1640 USER S MANUAL...
  • Page 110 96h : 2. Build and update ESCD. 3. Set CMOS century to 20h or 19h. 4. Load CMOS time into DOS timer tick. 5. Build MSIRQ routing table. FFh : Boot attempt (INT 19h) ′ Page: D-17 Prox-1640 USER S MANUAL...
  • Page 111 Appendix D Trouble Shooting ′ Page: D-18 Prox-1640 USER S MANUAL...
  • Page 112 Appendix D Trouble Shooting ′ Page: D-19 Prox-1640 USER S MANUAL...
  • Page 113 Appendix D Trouble Shooting PRINTED IN TAIWAN ′ Page: D-20 Prox-1640 USER S MANUAL...
