HPA D1000 Owner's Manual

D1000/D1500/D2000/D2500/D4500/D6000
Professional Power Amplifier
Features
• Controls
– Volume Control by 21 detent potentiometer for each channel
– LCD Screen: Back-lit LCD allows for crossover configuration, AMP mode configuration and compressor configuartion
– Menu/Prev/Next: Three buttons located near the LCD screen that are used to configure and access the integrated processing
• Connectors
– Input: XLR and 1/4" Phone Jack Balanced & Phono Jack Unbalanced
– Output: 5 way Binding Post & Speakon Jack for each Channel
• Indicator: Signal,-20dB, -10dB, Clip,Protect LED and LCD display
• Protection: Output current limiting, thermal protection, DC offset protection & circuit breaker
• Cooling: Variable speed fan forced cooling
Specifications
Rate Power
(1kHz, THD 1%)
Input Sensitivity ( 4Ω 1kHz )
Input impedance
Input CMRR ( 1kHz )
Frequency Response ( ±0.5dB )
Amplifier
Power Supply
T.H.D
Signal to Noise Ratio
Damping Factor ( 8Ω 400Hz )
Channel Separation ( 8Ω 1kHz )
Integrated DSP Processing
Power Source
Weught (Net)
Dimensions (W x H x D)
D1000
8 Ω Stereo 215 W
4 Ω Stereo 350 W
2 Ω Stereo 500 W
8 Ω Bridge
700 W
4 Ω Bridge
1000 W
4.9 kg
D1500 D2000 D2500
300 W 375 W 440 W
500 W 650 W 750 W
750 W 1050 W 1200 W
1000 W 1300 W 1500 W
1500 W 2100 W 2400 W
4 dBu
30 kΩ Balanced/15 kΩ Unbalanced
> 50 dB
20Hz~20 kHz
CLASS D
Switching mode power supply
< 0.03%
> 100 dB
> 200
> 700 dB
Crossover : Frequency Range ; 50Hz~3kHz, 24dB/oct
Filters : LowPass & HighPass ( both channels )
Limiter ( Channel independent clip limiter )
PEQ & Time Alignment
AC 100~240V,50/60Hz
4.9 kg 5.2 kg 5.2 kg
482 x 88 x 280
D4500 D6000
850 W 1100 W
1500 W 2000 W
2250 W 3000 W
N/A N/A
N/A N/A
5.9 kg 5.9 kg
