Audio Alarm; Ftp Upload - Direct IP IDIS DC-T4537HRXA Operation Manual

Audio Alarm

Select Audio Alarm to generate audio.
• List: Displays a list of audio files to playback. Click Add
or Remove to add/remove audio files. Select an audio
file from the list and then click Play to listen to the file.
The total audio file upload capacity is 8MB.
Please upload a file that a supported format. (.wav) The
.wav file supports the formats of 8/16/24bits and 8/11.
025/12/16/22.05/24/32/44.1/48/64/96KHz.

FTP Upload

Select FTP Upload to upload .jpg image of the event
detected to an FTP server.
• FTP Server: Click Add to register a new FTP server.
Click Remove to remove a registered FTP server.
When an event is detected, a .jpg image of the event
detected image is uploaded to the Primary Server.
If the upload to the Primary Server fails, the file will
be uploaded to the Secondary Server. Upload to the
Secondary Server will continue to be attempted until
successful. Fill out the fields below and click Test to
test the FTP server connection settings. Once the test
is complete, click OK.
- FTP Server: Enter the FTP server's IP address (or
domain name).
- Upload Path: Designate the file upload path.
- Port: Enter the FTP server's port number.
- User ID, Password: Enter the user ID and password
needed for connecting to the FTP server.
• Settings: Configure image and upload settings.
- Upload Type: Choose an upload type. Select
Always to upload images using the settings below,
irrespective of event detection. Select Event to
upload images using the settings below when an
event is detected.
Part 1 - Remote Setup
25
