- Page 1 INbed012V01_GL 84C-145V01 Assembly video please scan the QR code . READ AND SAVE THIS INSTRUCTION FOR FUTURE USE ASSEMBLY INSTRUCTION...
- Page 4 <1> M5x12 <2> M6x15...
- Page 5 M6x10...
- Page 6 EN:Firstly, Install the screws on the beam, but do not tighten them. After the uprights are tightened, then tighten the screws all. If the hole position is not aligned, move the uprights to adjust the position. DE:Installieren Sie zunächst die Schrauben am Träger, ziehen Sie sie jedoch nicht fest.
- Page 9 <7> M6x15...
- Page 11 <9> EN:Do not tighten this screws now, and tighten them after 15 steps are completed. DE:Ziehen Sie diese Schrauben jetzt nicht fest und ziehen Sie sie erst nach 15 Schritten fest. ES:No apriete esto tornillos ahora, después de completar el Paso 15, ya puede apretarlos.
- Page 15 M6x15...
- Page 18 EN:1.S and T are divided into left and right directions, identification method: take apart the four zippers, and install S/T in a single piece. The iron hook on S passes through the hole on T and hooks on the small hole of the upright.
