Summary of Contents for Outsunny 84C-242V01
- Page 1 INbac002_US_CA 84C-242V01 READ AND SAVE THIS INSTRUCTIONS FOR FUTURE USE ASSEMBLY & INSTRUCTION MANUAL...
- Page 2 WARNING: 1. A 3 person assembly is required for this tent. 2. Please take appropriate actions as heavy rain, wind and snow can damage the tent. If necessary please disassemble and store for later use. 3. In snowy conditions please do not allow the thickness of the snow to be more than 5cm on the roof, this should be cleared as soon as possible for your safety.
- Page 3 PART /Dessin /QtÉ /Description /Mât A1 /Mât A2 /Poutre transversale B1 /Poutre transversale B2 /Poutre transversale C1 /Poutre transversale C2 /Tube de toit /Barre de traction E1 /Barre de traction E2 /Tube de guidage /Équerre /Support d'angle H1 /Support d'angle H2 /Connecteur J /Connecteur K /Ferrure M...
- Page 4 PART /Dessin /QtÉ /Description Boulon/ Boulon/ Boulon/ Boulon/ /Clé Allen /Ancrage...
