Summary of Contents for Outsunny 84C-298
- Page 1 INbrb016_US_DE INbrb016_GL_84C-298 IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY ASSEMBLY & INSTRUCTION MANUAL...
- Page 3 EN_Charging Indicator DE_Ladeanzeige EN_Charging Port DC5V-1A EN_Connecting Wire DE_Ladeanschluss DC5V-1A DE_Anschlusskabel EN_Solar Energy, Remote Control Inside Please charge with USB before use.When The green light is on, it is fully charged DE_Solarenergie, Fernbedienung im Inneren Bitte vor Gebrauch mit USB aufladen. Wenn das grüne Licht leuchtet, ist es vollständig aufgeladen...
- Page 4 EN_Open the Canopy frame (A) into six directions until partially extended, then put the big top (B) into its correct position. Insert the wire into the solar receiver (DD), align and rotate it gently. DE_Öffnen Sie den Canopy-Rahmen (A) in sechs Richtungen, bis er teilweise ausgefahren ist, und bringen Sie dann das Big Top (B) in die richtige Position.
- Page 5 EN_Put on the big sun shelter (A), so each leg is covered by fabric. DE_Setzen Sie den großen Sonnenschutz (A) auf, sodass jedes Bein mit Stoff bedeckt ist. 1)There are removable inside poles under the eaves, pull them out slightly and fit them into the pocket of each corner at the top of the fabric.
- Page 6 1)Step on the plastic base of the leg. Adjust the canopy height by lifting the leg until it locks into place (Fig. 1). Repeat for the remaining five legs. 2)Hook the fabric of the legs to the bottom hole on the inside pole (Fig. 2). DE_1) Treten Sie auf die Kunststoffbasis des Beins.
- Page 7 1)Insert one steel stake (AA) into a hole on the plastic base of the leg (Fig. 1). Secure the canopy to the ground, repeat for the other five bases. 2)Tie the rope (CC) to the plastic ring on the corner of the canopy fabric (Fig. 2). Tie the other end to the ground stake (Fig.
- Page 8 STOWED AWAY EN_Remove the mosquito netting if EN_Pull up all stakes from the attached. ground. DE_Entfernen Sie das Moskitonetz, falls DE_Ziehen Sie alle Pfähle aus dem es angebracht ist. Boden. EN_Press the push pin on each EN_Push the push button on each leg and retract the legs to their slider to unlock the frame.
