VERSION # 19-11-11
1 / 13
MODEL #
NFA-1963C2
NFA-1963C16
Questions?
GIVE US A CALL: 1-888-980-5122
MON – FRI 8:30AM – 5:30PM (PST)
TOOLS REQUIRED
Hammer
(Not Included)
Philips
Screwdriver
(Not Included)
2 - People
Recommended
ASSEMBLY RATING
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Related Manuals for Furniture of America NFA-1963C2
Summary of Contents for Furniture of America NFA-1963C2
- Page 1 MODEL # NFA-1963C2 NFA-1963C16 Questions? GIVE US A CALL: 1-888-980-5122 MON – FRI 8:30AM – 5:30PM (PST) TOOLS REQUIRED Hammer (Not Included) Philips Screwdriver (Not Included) 2 - People Recommended ASSEMBLY RATING EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 ASSEMBLY CARE ADVICE FAILURE TO FOLLOW THE GUIDELINES BELOW MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. Position each part correctly Turn clockwise to tighten and and insert screws or bolts into only tighten when step is their respective holes. completed or when instructed to do so.
- Page 5 NFA-1963C2 NFA-1963C16 Please keep instructions for future reference. Check the quantity and irregularity of parts and hardware before you start. PARTS 2 PCS 2 PCS 1 PC 1 PC 2 PCS 1 PC 1 PC 2 PCS 1 PC HARDWARE...
- Page 6 Part x 1 PC Part x 1 PC Part x 1 PC Hardware x 2 PCS Hardware x 2 PCS Align bolts (#3) with half moon Hardware x 2 PCS washer (#8) to the designated holes as shown in the diagram, Hardware x 2 PCS then secure.
- Page 7 Hardware x 8 PCS Hardware x 2 PCS Hardware x 4 PCS Front Align bracket (#12) to the headboard (#A), then secure by using screws (#7) and bolts (#4). Make sure bolts (#4) is half way secured while screws (#7) is fully tightening. 7 / 13...
- Page 8 Part x1 PC Hardware 7 x 8 PCS Hardware x 2 PCS Hardware 4 x 4 PCS Front Align bracket (#12) to the footboard (#B), then secure by using screws (#7) and bolts (#4). Make sure bolts (#4) is half way secured while screws (#7) is fully tightening.
- Page 9 Part x 2 PCS Part x 2 PCS Hardware 7 x 36 PCS Hardware x 2 PCS Align side rails (#C,D) to each other, then secure brackets (#11,13,14) to the side Hardware x 2 PCS rails (#C,D) by using screws (#7). Hardware x 2 PCS Front...
- Page 10 Part x 1 PC Part x 2 PCS Hardware x 4 PCS Hardware x 4 PCS Hardware x 4 PCS Hardware x 1 PC Front 10 / 13...
- Page 11 Align and hook the side rails (#C,D) to the bolts (#4), then secure and fully tighten bolts (#4). Front 11/ 13...
- Page 12 Part x 2 PCS Hardware x 20 PCS Align slats (#H) to the side rails, then secure by using screws (#6). Front 12 / 13...
- Page 13 ASSEMBLY COMPLETED Please ensure the furniture rests on an even and flat surface. If the product wobbles or feels loose, double-check all bolts and/or screws are properly tightened and secured. Keep this handy! Please retain this instruction manual and any order-related information for future reference.
