Cat. No.
L
L1 L2
M485N241LED...
M485V241LED...
245
M485SN241LED...
M485SV241LED...
M485N481LED...
M485V481LED...
485
-
M485SN481LED...
M485SV481LED...
M485N962LED...
M485V962LED...
965
M485SN962LED...
M485SV962LED...
GDMRC-18
110
30
-
GDMRC-19
260
180
The number of luminaire for looping and positioning without distances in RGB models:
Length
Number
24 CM
13
48 CM
10
96 CM
5
Optional extruded aluminum shader in 24, 48 and 96 cm
M485...+ G485SH24-S
M485...+ G485SH48-S
M485...+ G485SH96-S
M485...
L1
50
(10* 6) mm
(2x)
L2
GDMRC...
Instruction for Installation and Utilization of
EN
1- For proper utilization of this product and safety, it is mandatory to closely
comply with the directions and notes in this instruction and guide.
2- Earth connection as provided is mandatory.
3- Do not stare at LED light source.
No. Minutes:
CM-94-452
Doc. No.
W-CM011/01
LEDiLINE
Wall Washer Luminaire
Cat. Code
Max Temp.
Min Temp.
(C.)
(C.)
M485...
50
-20
0
0
Execution Date:
05/09/2015
Tracking Code: 1401-443
