Summary of Contents for MegaLite AXIS 250
- Page 3 Check that the unit has not been damaged during transport Protection Against Fire 1. Maintain a minimum of 1 foot distance from any type of flame. 3. Replace fuse only with the specified type and rating. 4. Do Not install the unit to close to a heat source. 5.
-
Page 4: Part Numbers
Specifications Part Numbers Fixture Lamp Flight Case 1030 - AXIS 250 LNSK250/2 9051-Dual Flight Case Mechanical Specifications 16.75 ” 8 ” Pan: 530° Tilt: 280° DMX Connectors: 3-pin XLR connectors 3 ” Reflector: Glass reflector with cold mirror coating Thermal: Maximum ambient temperature 40°... -
Page 5: Dmx Channels
Color 1: Open 2: Red 3: Yellow 4: Purple 5: Light Green 6: Orange 7: Blue 8: Magenta 9: Dark Blue 10: Light Blue Gobo 1: Open 2: Magenta Swirl 3: Daisy 4: Swivel 5: Stars 6: Diffusion 7: Circular Stars Dichroic Glass Gobo: Diameter 27 mm Image 24 mm... -
Page 6: Main Power Connection
Main Power Connection Caution! Do not connect fixture to a dimmer system. This unit must be earthed. (electronically grounded) Replace fuse only with the specified type and rating. 110V 50/60hz Connection The occupation of the connection-cable is as follows: Cable (USA) Cable (EU) International Brown... -
Page 7: Lamp Replacement
Lamp Replacement Caution! 1. Disconnect power before you begging. 2. Allow 15min for the unit and lamp to cool. 3. Do not touch lamps glass envelope with your fingers. If this happens clean with alco- hol / to remove oils. Lamp Placement To insert the lamp MSD 250/2, HSD250. - Page 8 Axis 250 DMX Profile DMX Channel Function Description Value 0-255 Tilt Tilt 0-255 Pan Fine Pan Fine 0-255 Tilt Fine Tilt Fine 0-255 Pan/Tilt Speed (From fast to slow) Max Speed 1-249 Speed Blackout During Movement 250-252 Reset Reset 200-209...
-
Page 9: Main Control Menu
Main Control Menu The control board on the fixture base is your interface to access and control all the functions on the unit. Its digital display gives you a code view of the options and functions. The following will explain each function and its options. MODE ENTER DOWN... -
Page 10: Cleaning And Maintenance
Cleaning and maintenance Installation Maintenance: The operator has to make sure that the unit is operating safely and has the installations and electron- ics checked by an expert every 2 years. The following points have to be considered during the inspection: 1) All screws used for installing the device or part of the device have to be tightly connected and must not be corroded. - Page 11 Mega-Lite 5718 Kenwick St San Antonio, TX 78238 Ph 210-684-2600 Fax 210-855-6279 www.mega-lite.com / info@mega-lite.com...
