USER MANUAL
Safety Information........................................................................3
Specifications..............................................................................4
Main Power Connection.................................................................5
DMX-512 Connection....................................................................5
Main Control Menu......................................................................................6
Installing the Fixture.......................................................................8
Cleaning & Maintenance.............................................................................8
Parts List.....................................................................................................8
Advertisement
Table of Contents
Related Manuals for MegaLite XWITCH
Summary of Contents for MegaLite XWITCH
-
Page 1: Table Of Contents
USER MANUAL Table of Contents Safety Information………………………………………………………………3 Specifications…………………………………………………………………...4 Main Power Connection………………………………………………………..5 DMX-512 Connection…………………………………………………………..5 Main Control Menu..................6 Installing the Fixture……………………..……………………………………...8 Cleaning & Maintenance................8 Parts List.....................8... -
Page 3: Table Of Contents Safety Information
Check that the unit has not been damaged during transport Protection Against Fire 1. Maintain a minimum of 1 foot distance from any type of flame. 3. Replace fuse only with the specified type and rating. 4. Do Not install the unit to close to a heat source. 5. -
Page 4: Specifications
Technical Information Part Numbers Fixture MC-2030 Xwitch MEA-APV-12-12 Mean Well 12V power Supply (included) Mechanical Specifications .42” 2.95” DMX Connectors: 3 screw binding strip Power Connections: 2 screw binding strip Thermal: Maximum ambient temperature 104° Maximum surface temperature 140° Display:... -
Page 5: Main Power Connection
Main Power Connection Caution! Do not connect power supply to a dimmer system. This unit has Auto switching power supply. It will respond to 110V or 220V automatically The occupation of the connection-cable is as follows: This fixture is equipped with an electronic power supply that will let the unit operate from 100V to 240V from 50Hz to Cable 110V 220V... -
Page 6: Main Control Menu
Main Control Note: Controller only works on fixtures that are 3 or 4 Channel. And that the Channel are as fol- lows. Channel 1 Red LED Channel 2 Green LED Channel 3 Blue LED Channel 4 White LED And the fixture must be addressed to DMX start Channel 001 Power On/Off Tap the screen for power on a blue LED indicator will light showing controller is Tap the screen for power Off a red LED indicator will light showing the controller... - Page 7 CTO Control Tap the CTO button to select the White mixed color. There is 3 options Note: the white color LED will not be active on the fixture. Pre Programs Control Tap once to start the preprogram function, tap once again to pause the program. Tap twice to select the next preprogram.
-
Page 8: Installing The Fixture
Installing the fixture Caution! 1. The installations must be carried out by an authorized dealer or trained profes- sional. 2. Unit may cause severe electrical injures if you have doubts concerning the safety do not install. When installing a unit it is very important that you follow common safety procedures. Installing requires extensive experi- ence including but not limited to calculating voltage loads, material being used and periodic safety inspections. - Page 9 Warranty Information Warranty Conditions -Unless otherwise stated in writing, your product is covered by a one year parts and labor limited warranty. -LEDs are not guaranteed to match in color temperature or output. -It is the owner’s responsibility to furnish receipts or invoices for verification of purchase, date, and reseller or distributor. If purchase date cannot be provided, date of manufacture will be used to determine warranty period.
