Page 1: Table Of Contents
USER MANUAL Table of Contents Safety Information Specifications Main Power Connection DMX-512 Connection Main Control Menu DMX Profile Rigging the Fixture Cleaning & Maintenance Parts List... - Page 3 Check that the unit has not been damaged during transport Protection Against Fire 1. Maintain a minimum of 1 foot distance from any type of flame. 3. Replace fuse only with the specified type and rating. 4. Do Not install the unit to close to a heat source. 5.
-
Page 4: Specifications
Technical Information Part Numbers 7202– Outshine WW100 Mechanical Specifications 11.25 10.5” DMX Connectors: Neutrik X-HD Series 3 or 5 pin IP 65 Rated XLR connectors in and out Thermal: Maximum ambient temperature 104° Maximum surface temperature 140° Fastening System: Double Mounting Yoke 7.65”... -
Page 5: Main Power Connection
Main Power Connection Caution! Do not connect fixture to a dimmer system. This unit has Auto switching power supply. It will respond to 110V or 220V automatically This unit must be earthed. (electronically grounded) Replace fuse only with the specified type and rating. The occupation of the connection-cable is as follows: This fixture is equipped with an electronic power supply that will let the unit operate from 100V to 240V from 50Hz to 60Hz Cable (USA) -
Page 6: Main Control Menu
Display Menu The control board on the fixture base is your interface to access and control all the functions on the unit. Its digital display gives you a code view of the options and functions. The following will explain each func- tion and its options. -
Page 7: Dmx Address
DMX Address Press Enter to select the DMX start address channel. The first display will let you know what operation mode you are in. Use the up/down keys to select the desired mode. Press Enter to confirm. (first Letter will also change depending on what mode you are in) Use the up/down keys to select the desired start address press Enter to confirm Set Color Menu Press Enter to set a Dim via display control. -
Page 8: Dmx Profile
DMX Profile Outshine WW 100 Mode A DMX Chanel Function Description Value LED Off 0-127 On/Off LED On 128-255 Outshine WW 100 Mode P DMX Chanel Function Description Value Dimmer Dimmer Off to Full 0-255 Outshine WW 100 Mode H DMX Chanel Function Description... -
Page 9: Rigging The Fixture
Rigging the fixture Caution! 1. The installations must be carried out by an authorized dealer or trained profes- sional. 2. Unit may cause severe injures if you have doubts concerning the safety do not install. When rigging a unit it is very important that you follow common safety procedures. Rigging requires extensive experi- ence including but not limited to calculating working loads, material being used and periodic safety inspections. -
Page 10: Warranty Information
Warranty Information Warranty Conditions -Unless otherwise stated in writing, your product is covered by a one year parts and labor limited warranty. -LEDs are not guaranteed to match in color temperature or output. -It is the owner’s responsibility to furnish receipts or invoices for verification of purchase, date, and reseller or distributor. If purchase date cannot be provided, date of manufacture will be used to determine warranty period.
