SCAN Basic1 Instructions For Installation And Use page 3

SCAN Basic 1 & SCAN Basic 3
Accessories
For these models you can have the following accessories:
• Lateral covering in soapsto-
ne or ceramic tiles (white or
blue) for SCAN Basic 3
• Top plate in soapstone for
SCAN Basic 3
• Baking-compartment door
The stoves can be prepared for an external air supply where
fresh air is let directly into the combustion chamber (must be
mounted from the factory).
Adjustment screws
The stove has two adjustment screws
on the bottom that can be used for
levelling the stove.
Data for calculation of the chimney
Connecting
Stove
model adaptor
SCAN mm
B1&3 150
Column 2 and 5 show the flue gas temperature in the connecting adaptor
Column 3 and 6 show the lowest/minimum draft in Pa by rated value
Column 7 shows the lowest/minimum draft in Pa by 0.8 x rated value
• Small grill
• Steel floor plate
• Connection piece
for fresh-air intake
With open doors
1 2
Density of Flue gas Minimum
flue gas tempera- draft
flow ture
o C
g/s
23 240
Adjustment of the handle
The vertical position of the handle can be
adjusted with the screw in the door frame.
Handle
The door is opened by turning the handle
counter-clockwise.
Self-closing door (BA 1)
The door is prepared with a self-closing function at the
factory. If you tighten the spring with the hexagon spanner,
the door will close automatically when you let go of it.
With closed doors
3 4 5
Density of Flue gas
flue gas temperature
flow
Pa o C
g/s
10 6 300
6 7
Minimum 0,8
draft Minimum
draft
Pa Pa
14 11
