Instantaneous shower water heater - Operation and installation instructions
ไทย
คู ่ ม ื อ แนะนำ � ก�รใช้ ง �นและติ ด ตั ้ ง เครื่ อ งทำ � น้ ำ � อุ ่ น
This shower water heater must be installed (water and electrical installation),
commissioned and serviced by approved service technicians in
accordance with these instructions.
เครื่ อ งทำ � น้ ำ � อุ ่ น นี ้ จ ะต้ อ งทำ � ก�รติ ด ตั ้ ง ต�มวิ ธ ี ก �รในคู ่ ม ื อ โดยช่ � งผู ้ ช ำ � น�ญง�นเท่ � นั ้ น
Advertisement
Table of Contents
Related Manuals for STIEBEL ELTRON DX 35 E
Summary of Contents for STIEBEL ELTRON DX 35 E
- Page 1 35 E / 45 E English Instantaneous shower water heater - Operation and installation instructions ไทย คู ่ ม ื อ แนะนำ � ก�รใช้ ง �นและติ ด ตั ้ ง เครื่ อ งทำ � น้ ำ � อุ ่ น This shower water heater must be installed (water and electrical installation), commissioned and serviced by approved service technicians in accordance with these instructions.
- Page 2 เครื่ อ งทำ � น้ ำ � อุ ่ น หรื อ น้ ำ � ร้ อ นนี ้ โ ดยไม่ ไ ด้ ร ั บ Cleaning and user ก�รควบคุ ม ดู แ ล maintenance shall not be made by children without supervision. STIEBEL ELTRON...
-
Page 3: Table Of Contents
2.7 Regulations and provisions ...................... 13 2.8 Installation location ........................13 2.9 First operation ..........................14 2.10 Care and maintenance ......................14 2.11 Service note ..........................14 3. Guarantee ............................. 15 4. Fault elimination for the user ...................... 15 STIEBEL ELTRON... -
Page 4: Installation Instruction
1. Installation Instruction for the qualified installer 4 x 35 mm 6 mm min. 4.5 mm max. 5.5 mm 4 x 35 mm 6 mm Fig 1 90 mm 186 mm 76 mm Fig 2 STIEBEL ELTRON... - Page 5 A - Heating Element B - Electronic control set (Phase Cut) Flow Sw. C - ELSD Circuit D - Triac Set E - Double Action Thermostat F - ELSD-Button Board G - ELSD Sensor Coil 220-240 V. AC. ONLY Fig 5 STIEBEL ELTRON...
-
Page 6: Components Of The Unit
3 Terminal block shower hose 4 Cable entry with seal 10 Combination filter 5 Power light 11 Washer 6 Rotary control for temperature 12 ELSD (option) adjustment 13 Lower fixing hole 7 Reed switch control 14 Plastic tank Fig 6 STIEBEL ELTRON... -
Page 7: Installing The Unit
Please ensure that the power is turned off at the mains. Fig 8 Fig 10 - Hang the unit on the screws mounted on - Open the cover of the unit. the wall, and slide the heater down into position. STIEBEL ELTRON... - Page 8 Fig 12 Fig 14 - Fit a secure connection cable ensure - After installation is complete, close dimension are correct. the cover and screw in tightly. (See cable size in Technical Data) STIEBEL ELTRON...
- Page 9 - Fit the cold water pipe thoroughly. position. - The knob will automatic correct the position. Fig 16 Fig 18 - Fit the filter and silicone gasket . - Fit the silicone gasket shower accessories to the hot water pipe thoroughly. STIEBEL ELTRON...
-
Page 10: Operation Instruction
2.1 Description of the unit. This appliance is designed for domestic The Stiebel Eltron DX pressureless use. It can be used safely by untrained (open) instantaneous water heater is persons. The appliance can also be used a device for heating water for shower. -
Page 11: The Essentials - In Brief
A periodical Test button, the Trip light will go on. scale removal is essential for the Press the Reset button. function of the shower head. Shower head level must not be higher than the unit. Fig 19 STIEBEL ELTRON... -
Page 12: Technical Data
(hot water connection - Technical data. downwards). - Install the unit flush with the wall. - Electrical connection to be secure. - New hose-sets are to be used* and old hose-sets should not be reused.. STIEBEL ELTRON * (not included) -
Page 13: First Operation
Do not use any abrasive cleaning agents or agents containing solvents. Maintenance work may only be carried out by a qualified installer. - Clean the filter Disconnect water valve, remove filter (Fig 6 No. 10) and clean. Re-assemble in reverse order. STIEBEL ELTRON... -
Page 14: Guarantee
- The shower head is - Clean shower head blocked with dirt or or remove limescale. limescale. - ELSD activated. - Press “Reset” button. STIEBEL ELTRON...
