UM2803
User manual
STSW-L9026-Y0 GUI
Introduction
The present document describes the Graphical User Interface (GUI) that allows to initialize and control the EVAL-L9026-
Y0 evaluation board by changing parameters through the SPI protocol. The L9026 GUI has been developed using, as
microcontroller interface, the PT&S Connect.
UM2803 - Rev 1 - November 2020
www.st.com
For further information contact your local STMicroelectronics sales office.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STSW-L9026-Y0 and is the answer not in the manual?

Questions and answers

Related Manuals for ST STSW-L9026-Y0

Summary of Contents for ST STSW-L9026-Y0

  • Page 1 UM2803 User manual STSW-L9026-Y0 GUI Introduction The present document describes the Graphical User Interface (GUI) that allows to initialize and control the EVAL-L9026- Y0 evaluation board by changing parameters through the SPI protocol. The L9026 GUI has been developed using, as microcontroller interface, the PT&S Connect.

  • Page 2: Hardware Connection

    UM2803 Hardware connection Hardware connection The EVAL-L9026-Y0 should be connected to PT&S Connect as shown in the following figures: Figure 1. PT&S Connect connected to EVAL-L9026-Y0 Figure 2. Particular of EVAL-L9026-Y0 connectors associated to the proper flat cable of PT&S Connect UM2803 - Rev 1 page 2/16...

  • Page 3: Flashing Firmware On Pt&S Connect

    To use the EVAL-L9026-Y0 GUI the PT&S connect must be programmed with the dedicated Firmware (EVAL- L9026-Y0.elf). In the following paragraph it will be shown the procedure to program the PT&S Connect using the ST toolchain based on SPC5-UDEDEBG: Start UDE Visual Platform If not yet done, create a New Workspace for SPC56M.
  • Page 4 UM2803 Flashing firmware on PT&S connect Name the new Workspace i.e. "monaco.wsx" and select OPEN UDE Visual Platform will be refreshed and new functionalities will appear, then click on "Load Program" (or File/LoadProgramm) Browse the file "EVAL-L9026-Y0.elf" and click "Open" UM2803 - Rev 1 page 4/16...
  • Page 5 UM2803 Flashing firmware on PT&S connect In the next window click on “Cancel” Then click on "Program All" The UDE Visual Platform will start to load the program UM2803 - Rev 1 page 5/16...
  • Page 6 UM2803 Flashing firmware on PT&S connect When the procedure is terminated click on "Exit" on all windows 10. After clicking "Exit" on all windows, close UDE Visual Platform. After disconnecting and reconnecting, the PT&S connect will be ready to be used with the Graphical User Interface (GUI) for EVAL-L9026-Y0. UM2803 - Rev 1 page 6/16...

  • Page 7: Gui Package Installation

    UM2803 GUI package installation GUI package installation Before the first run of STSW-L9026-YO on your PC, you need to install the following components: • Microsoft .NET Framework 4.6.1 • Microsoft Office Web Component (OWC) ver. 11 • PTS Connect COM driver (PTS_USB-COM_driver.zip contained in the PTS GUI package.zip file) •...

  • Page 8: Gui Description

    UM2803 GUI description GUI description In order to run the GUI, once extracted the EVAL-L9026-Y0.zip archive please click on PTS_GUI.exe. To exit the GUI the user should choose the menu "File" and click on EXIT. The GUI is composed by three main tabs: Config, Normal Operation and SPI. The other tabs are used for Serial log and PTS connect PIN configuration.

  • Page 9: Config Tab

    UM2803 Config Tab Config Tab The Config Tab is used for the preliminary configuration of L9026. There are 6 parts: Parallel input configuration: to configure the functionality of parallel input IN0 and IN1 of L9026. Pushing on the radio button it is possible to associate the parallel input to one of the outputs. For further information please refer to L9026 datasheet.

  • Page 10: Spi Tab

    UM2803 SPI Tab Except Driver 0 and Driver 1 that are only High Side (HS) driver, all the other drivers can be configured, according to the HW configuration of EVAL-L99026-YO, either as Low side (default) or as High Side clicking on the HS/LS button.

  • Page 11: Appendix A Other Information

    UM2803 Other information Appendix A Other information Reference documents Table 1. Reference documents Doc Name Title DS13397 034478 Configurable multi channel relay driver 2HS + 6HS/LS UM2803 - Rev 1 page 11/16...

  • Page 12: Revision History

    UM2803 Revision history Table 2. Document revision history Date Version Changes 18-Nov-2020 Initial release. UM2803 - Rev 1 page 12/16...

  • Page 13: Table Of Contents
