Instructions
55 - 100" / 140 - 254 cm
Please read these instructions thoroughly before installation.
Helpline
1300 762 219 (Australia)
(09) 9302 0077 (New Zealand)
Australian Supplier - Arisit P/L · 40-50 Mark Anthony Drive · Dandenong · South Victoria · 3175
New Zealand Supplier - Arisit P/L · 1a Howe Street · Newton · Auckland · 1145 · New Zealand
600 x 400 max
VESA
Product
Information
bit.ly/QB600S-AU
471678
Rev00
68 kg / 150 lb.
You will need
6mm (15/64")
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for AVF 471678
Summary of Contents for AVF 471678
- Page 1 Instructions 471678 Rev00 55 - 100" / 140 - 254 cm 600 x 400 max 68 kg / 150 lb. VESA Please read these instructions thoroughly before installation. You will need 6mm (15/64”) Helpline Product Information 1300 762 219 (Australia) (09) 9302 0077 (New Zealand) bit.ly/QB600S-AU...
-
Page 2: Parts Included
Parts Included TV Screws, Reducers and Spacers M4’s M6’s M8’s 45mm 25mm 16mm You will only need one set of TV Screws... -
Page 3: Easy Steps
3 Easy Steps Attach the Brackets Assemble the Stand Hang and secure to your TV Measure your VESA fixings and select TV Screws 75 - 600mm 75 - 400mm This product fits fixing holes up to 600 x 400mm (MAX). Determine which diameter TV Screws fit your TV and put them to one side. - Page 4 Fitting the TV Brackets After completing this step, you will have lots of TV screws left over. Keep them in a safe place in case you require them in future. Select the correct length TV screw. If required You may need to use Spacers K1 or K2 if the screws are too long or the back of your TV is not flat.
- Page 5 Assemble the Legs...
- Page 6 Attach the Backplate Place the Backplate in the top slot on the TV Brackets. Measure from the lower mounting holes on the Backplate to the bottom of your TV. Measure the legs, from above the feet, the same distance to find the bottom hole for fixing the backplate.
- Page 7 The legs can be attached in four different positions. Choose the setup that works best for your TV and furniture. 53.7cm 63.7cm 73.7cm 83.7cm 21.1” 25.1” 29” 33”...
- Page 8 Hanging the TV Locking the TV...
