- Page 1 CXL65-F - Instruction Booklet 472160 Welcome and thank you for choosing Installation is EASY with our step-by-step Video Guide Scan here or visit avf-info.com/vid65en We’re happy to help! 1-800-667-0808 avf-info.com/support...
- Page 2 Mount your TV in 3 easy steps! Assembly Overview Installation Video Guide Attach the TV Mounting Plate to the TV Attach the Wall Plate to the Wall Hook the TV on to the Mount...
-
Page 3: You Will Need
STRONG SECURE Suitable Wall Types Solid Concrete Block Wall W ood St ud Wall You will need " Stud Finder 12mm / 15/32" Masonry 5mm / 13/64" Wood... - Page 4 Parts Included 1-800 667 0808 Contact us for help!
- Page 5 Just use the screws that fit your TV. Keep left over screws in a safe place. Preparing the Wall Bracket Remove the Wall Bracket Covers and safely keep for Step 2C. Push the Wall Bracket Covers out from behind using a screwdriver. avf-info.com/support...
- Page 6 Preparing the TV Mounting Plate Before you can attach the TV mounting plate to your TV you need to remove the plate from your wall mount. TV Mounting Plate Level Lock Screw Remove the Level Lock Screw and safely keep for Step 3A. Remove the TV Mounting Plate.
- Page 7 VESA adaptors before proceeding to Step 1C. Keep the adaptors and fixings in a safe place in case they are needed in future. Only remove if both distance are 200mm or less VESA Adaptor For reference, the images in the rest of the booklet show the VESA Adaptors still fitted. avf-info.com/support...
- Page 8 Attach the TV Mounting Plate to the TV Position the TV Mounting Plate • Position the TV Mounting Plate on the back of your TV. The plate must be level and positioned on the vertical centre line of your TV. •...
- Page 9 TV is not flat. Check and Secure the TV Mounting Plate Make sure the TV Mounting Plate is still level and positioned on the vertical centre line of your TV. Fully tighten the Thumb Nuts. avf-info.com/support...
- Page 10 TV Height Calculator Determine the exact position for your drill points with our easy online tool at avf-info.com/tvhc65en Determine the Height for Your Drill Points • Measure A from the bottom of the TV mounting plate to the bottom of your TV as shown.
- Page 11 • Use the Wall Bracket as a template to mark the drill points on your wall. • If fixing to a wood stud wall only four screws are required. • Position the Wall Plate so that it spans two wood studs. • The TV can be positioned anywhere along the wall bracket. avf-info.com/support...
-
Page 12: Attach The Wall Plate To The Wall
Attach the Wall Plate to the Wall Solid Concrete Block Wall 75mm (3") 12mm / 15/32" Masonry DO NOT drill into the Remove dust from holes. mortar between blocks. It can be difficult to accurately drill holes with a large drill bit. Try drilling 6mm pilot holes first. - Page 13 Lubricate screw thread with soap. DO NOT overtighten screws. Tighten screws by hand only. avf-info.com/support...
- Page 14 W ood St ud Wall 50 x 100mm (2 x 4”) Min Ensure you drill in the centre of the 75mm (3") wood stud. 5mm / 13/64" Wood 1-800 667 0808 Contact us for help!
- Page 15 DO NOT use wall plugs in a wood stud wall. Lubricate screw thread with soap. DO NOT overtighten screws. Tighten screws by hand only. avf-info.com/support...
- Page 16 Fitting the Wall Plate Covers 1-800 667 0808 Contact us for help!
- Page 17 Attach the Mount Arm Position the Mount Arm where you want the centre of your TV, when flat against the wall. You can adjust this later if required. Fully tighten both screws to lock Mount Arm to Wall Plate. avf-info.com/support...
- Page 18 Connect the TV to the Mount Arm Reuse Level Lock Screw saved in step 1B. When the TV is level, ensure the Level Lock Screw is fully tightened. To remove the TV, reverse this procedure. 1-800 667 0808 Contact us for help!
-
Page 19: Cable Management
Cable Management Push cables through the slots in the arms to keep them neat and tidy. avf-info.com/support... - Page 20 Post-Installation Adjustment TV Levelling Loosen the Level Lock Screw, adjust your TV until it is level, then re-tighten the screw. 1-800 667 0808 Contact us for help!
- Page 21 Adaptor thumb nuts. If you feel the tilt is too stiff or too loose you can adjust the Tilt Thumb Nuts to achieve perfect tilt resistance. You must adjust both nuts equally. You can also lock the tilt if required. avf-info.com/support...
- Page 22 Side-to-Side Positioning To help position your TV perfectly on the wall you can slide the Mount Arm side-to-side and secure it anywhere along the Wall Plate. Remove TV before starting. Loosen both locking screws. Slide arm into the required position and re-tighten both locking screws. Reconnect your TV.
- Page 23 4 nuts located at the wall end of the arms. Adjust all 4 nuts equally. For safety and easier access remove the TV from the arms and the arms from the wall bracket before adjusting. Swivel Resistance Nut Arm Tension Nuts Arm Tension Nuts avf-info.com/support...
-
Page 24: Year Warranty
YEAR WARRANTY AVF warrants that the product is free from defects in material and workmanship, as long as the product is owned by the original consumer purchaser. If, during the stated warranty of this product, it proves to be defective, AVF will remedy the defect by either repairing or replacing the defective part or, replacing the entire product.
