User's manual
Customer Service
US: 1-800-645-2986
Frame and Leg Kit for 48/60/72 Manual Hand
Crank Adjustable Workbench - Black
Tools Needed
Components
Hardware
Manual del usuario
Servicio de atención al Cliente
US: 1-800-645-2986
Frame & Leg Kit Model: 493780BK
1
Manuel de l'utilisateur
Service à la clientèle
Canada: 888-645-2986
Caution:
• Requires 2 people for
assembly.
• Ensure you are using proper
PPE such as glove, steel
toe boots, safety glasses.
• Perform regular inspections
on the hardware by
checking their tightness
every 4 months.
• If table height isn't adjusting,
remove items off table
and inspect. Do not force
adjustment.
MODEL # 493780BK
Advertisement
Table of Contents
Related Manuals for Global Industrial 493780BK
Summary of Contents for Global Industrial 493780BK
- Page 1 Service à la clientèle US: 1-800-645-2986 Canada: 888-645-2986 US: 1-800-645-2986 Frame and Leg Kit for 48/60/72 Manual Hand Crank Adjustable Workbench - Black Frame & Leg Kit Model: 493780BK Tools Needed Caution: • Requires 2 people for assembly. Components • Ensure you are using proper PPE such as glove, steel toe boots, safety glasses.
- Page 2 User Manual Hand Crank Adjustable Workbench 1) Lay out all components and hardware to ensure that you have all the components and hardware. Fully separate the Crossbard ends ( Ref 5). You will find the Crossbar Center Rails (Ref 6) Inside. 2) Prop up the assemblies from Step 1 As shown.
- Page 3 User Manual Hand Crank Adjustable Workbench 6) Place the table under the accessories and place it in the corect position. Then attach the Handle Holder (Ref 9) to the Table Board with x4 M5*16 wood screws (Ref 23) and tighten them. Then connect the Table Board to the desk frame with x6 M5*16 wood screws (Ref 23) and tighten them.
