Boardcon Embedded Design PICO-IMX8M-MINI Reference User Manual page 9

47 SAI1_RXD1
48 SAI1_RXD0
49 SAI5_RXFS
50 GND
51 SAI5_RXC
52 SAI5_RXD2
53 SAI5_MCLK
54 SAI5_RXD3
55 SAI5_RXD1
56 GND
57 GND
58 SAI5_RXD0
59 PWRON
60 SAI1_MCLK
61 GND
62 GND
63 ENET_TXC
64 ENET_TX_CTL
65 GND
66 ENET_TD0
67 ENET_TD1
68 ENET_TD2
69 ENET_TD3
70 ENET_RX_CTL
71 ENET_RXC
72 GND
73 ENET_RD0
74 ENET_RD1
75 PMIC_ON_REQ
76 ENET_RD2
77 GND
78 ENET_RD3
79 USB2_DP
80 ENET_MDC
81 USB2_DN
82 ENET_MDIO
83 GND
84 GND
85 USB1_DP
86 GND
87 USB1_DN
88 SD2_CD_B
89 GND
GPIO4_IO03/SAI5_RxData1 pull Up 10K
GPIO4_IO02/SAI5_RxData0 pull Up 10K
GPIO3_IO19/SAI1_TxData0
ground
GPIO3_IO20/SAI1_TxData1/PDM_CLK
GPIO3_IO23/SAI1_TxSYNC/PDM_Data2
GPIO3_IO25/SAI1_TxBCLK
GPIO3_IO24/SAI1_TxData5/SAI1_TxSYNC/PDM_Data3
GPIO3_IO22/SAI1_TxData3/SAI1_TxSYNC/PDM_Data1
ground
ground
GPIO3_IO21/SAI1_TxData2/PDM_Data0
System reset
GPIO4_IO20/SAI5_MCLK/SAI1_TxBCLK/PDM_CLK
ground
ground
GPIO1_IO23/ENET1_RGMII_TXC/ENET1_TX_ER
GPIO1_IO22/ENET1_RGMII_TX_CTL
ground
GPIO1_IO21/ENET1_RGMII_TD0
GPIO1_IO20/ENET1_RGMII_TD1
GPIO1_IO19/ENET1_RGMII_TD2/INPUT=ENET1_TXCLK
GPIO1_IO18/ENET1_RGMII_TD3
GPIO1_IO24/ENET1_RGMII_RX_CTL
GPIO1_IO25/ENET1_RGMII_RXC/ENET1_RX_ER
ground
GPIO1_IO26/ENET1_RGMII_RD0
GPIO1_IO27/ENET1_RGMII_RD1
PMIC require on
GPIO1_IO28/ENET1_RGMII_RD2
ground
GPIO1_IO29/ENET1_RGMII_RD3
USB2 data positive
GPIO1_IO16/ENET1_MDC
USB2 data negative
GPIO1_IO17/ENET1_MDIO
ground
ground
USB1 data positive
ground
USB1 data negative
GPIO2_IO12/usdhc2_CD_B
ground
8
Customize the embedded system based on
Your Idea
3.3V
3.3V
3.3V
0V
3.3V
3.3V
3.3V
3.3V
3.3V
0V
0V
3.3V
1.8V
3.3V
0V
0V
3.3V
3.3V
0V
3.3V
3.3V
3.3V
3.3V
3.3V
3.3V
0V
3.3V
3.3V
1.8V
3.3V
0V
3.3V
3.3V
3.3V
3.3V
3.3V
0V
0V
3.3V
0V
3.3V
3.3V
0V
