1.4 Block Diagram
1.4.1 i.MX 8M Mini Block Diagram
Security
TrustZone
DRM Ciphers
Secure Clock
eFuse Key Storage
Random Number
32 KB Secure RAM
System Control
3x Smart DMA
XTAL
PLLs
3x Watchdog
4x PWM
6x Timer
Secure JTAG
Temperature Sensor
Customize the embedded system based on
Main CPU Platform
Quad Cortex-A53
32 KB I-cache
32 KB D-cache
NEON
512 KB L2 Cache
Low Power, Security CPU
Cortex-M4
16 KB D-cache
16 KB I-cache
256 KB TCM
Multimedia
3D Graphics: GC NanoUltra
2D Graphics: GC320
1080p60 H265, VP9 decoder
1080p60 H264, VP8 decoder
1080p60 H.264, VP8 encoder
4-lane MIPI-CSI Interface
4-lane MIPI-DSI Interface
5
Connectivity and I/O
1 GB Ethernet
(IEEE1588, EEE, and AVB)
S/PDIF Rx and Tx
FPU
5x I2S/SAI
2x USB 2.0 OTG and PHY
1x PCIe 2.0 (1-lane)
4x UART
4x I2C, 3x ECSPI
PDM
External Memory
LPDDR4/DDR4/DDR3L
2x eMMC 5.1/SD 3.0
NAND CTL (BCH62)
1x FlexSPI
