I2C3_SCL I2C3 serial clock
I2C3_SDA I2C3 serial data
I2C4_SCL I2C4 serial clock
I2C4_SDA I2C4 serial data

2.11 PWM

The pulse-width modulator (PWM) has a 16-bit counter and is optimized to generate sound from stored
sample audio images. It can also generate tones. It uses 16-bit resolution and a 4x16 data FIFO to
generate sound.
Signal Description
PWM1 PWM1 output
PWM2 PWM2 output
PWM3 PWM3 output
PWM4 PWM4 output

2.12 JTAG

Support for 6-pin (JTAG) debug interface
Signal Description
JTAG MOD JTAG MODE
JTAG nTRST JTAG reset
JTAG TCK JTAG clock
JTAG TDI JTAG data input
JTAG TDO JTAG data output
JTAG TMS JTAG mode select
Customize the embedded system based on
162
164
158
160
Pin
194
196
160
184
198
158
189
200
164
187
182
162
Pin
Un-pinout
122
120
118
116
114
23
Your Idea
I2C3_SCL
I2C3_SDA
I2C4_SCL
I2C4_SDA
Defaults Function
GPIO1_IO01
SPDIF_EXT_CLK
I2C4_SDA
GPIO1_IO13
SPDIF_RX
I2C4_SCL
GPIO1_IO14
SPDIF_TX
I2C3_SDA
GPIO1_IO15
SAI3_MCLK
I2C3_SCL
Defaults Function
JTAG nTRST
JTAG TCK
JTAG TDI
JTAG TDO
JTAG TMS
