Electriq Power PowerPod 2 Installation Manual page 97

Appendix / What's in the Box
Description
Cable, PE Grounding (Enclosure
to inverter) 48" (1220mm)
(10AWG)
Cable, PE Grounding (Enclosure
to front panel) 24" (610mm)
(10AWG)
Description
4 - 91478A595, Hex Head Screw
for Wood, Zinc-Plated Steel, 5/16"
Size, 3" Long
4 - 98023A030, Zinc Yellow-
Chromate Plated Grade 8
Steel Washer for 5/16" Screw
Size, 0.344""ID, 0.688" OD"
24 - Nut, Class 8, M6 x 1.00mm,
Medium-Strength Zinc-Plated
Steel Flange. Torque min. 3.3
max. 4.0 Nm (min. 2.4 max. 3.0 ft
lb).
28 - Tooth Lock Washers, 10mm
2 - Wing Nut, M6. Torque min. 3.3
max. 4.0 Nm (min. 2.4 max. 3.0 ft
lb)
Installation Manual
PN or Image
PN or Image
97
