Installing System / Commissioning
PowerPod 2 Display Indicators
State
Power On
Commissioning
Normal
Issue Detected
Installation Manual
PowerPod 2
Display
Solutions
A full white circle indicates
that the display just turned
on and has received no
communication from
PowerHub 2
A full blue circle indicates
that the system is ready to be
commissioned and that the
system is communicating with
the PowerHub 2.
The state of charge is
indicated by the amount of
the ring that is filled. The ring
to the left is indicating that the
state of charge is at 75%.
A full yellow circle indicates
that the system has detected
an issue.
79
