Installing System / Battery
PowerPod 15 kWh
PowerPod 20 kWh
52
BMS
1
2
3
4
BMS
1
2
3
4
Communications Cables (Black - located
in the middle of the batteries).
Battery Power Cables (Red, Black -
located on the top and bottom edge of
the batteries).
ZN with Orig (Rev. 1) 15 kWh
Communication cable (plugs labeled
SA1 to PA1; SA4 to PA4 and D5 & D6 into
batteries 5 and 6).
ZN with Univ (Rev. 2) 15
kWh Communication cable
(plugs labeled SA1(SA2) to
PA1; SA4(SA5) to PA4(PA5)
6
and D5(DA7) & D6(DA8) into
batteries 5 and 6).
Topband with Orig (Rev. 1) 15
kWh Communication cable
5
(plugs labeled "To expansion
module" to "COM_IN" and
P9(P11) & P10(P12) into
batteries 5 and 6).
ZN with Orig (Rev. 1) 20 kWh Communication
cable (plugs labeled SA2 to PA2; SA5 to PA5
and D7 & D8 into batteries 5 and 6).
ZN with Orig (Rev. 1) 20 kWh
Communication cable (plugs
labeled SA2 to PA2; SA5 to PA5 and
8
D7 & D8 into batteries 5 and 6).
Topband with Orig (Rev. 1) 20
kWh Communication cable (plugs
labeled "COM_OUT" to "COM_IN"
7
and P9(P11) & P10(P12) into
batteries 7 and 8).
15 kWh Communication cable (plugs
labeled SA1 to PA1; SA4 to PA4 and
D5 & D6 into batteries 5 and 6).
6
ZN with Univ (Rev. 2) 15 kWh
Communication cable (plugs
labeled SA1(SA2) to PA1; SA4(SA5)
5
to PA4(PA5) and D5(DA7) &
D6(DA8) into batteries 5 and 6).
Topband with Orig (Rev. 1) 15
kWh Communication cable (plugs
labeled "To expansion module" to
"COM_IN" and P9(P11) & P10(P12)
into batteries 5 and 6).
