Specification -
Spec.
CAMERA
Image Sensor 1/2.8" 5.14MP CMOS
Total Pixels 2592(H) X 1944(V)
Focal Length 6 ~ 50mm, F1.6, MFZ
D: 8.6° ~ 52°, H: 6.9° ~ 40.8°,
Horizontal Angle
V: 5.2° ~ 30.2°
Auto, Manual (1/15 ~ 1/32000),
Shutter Speed Anti-Flicker, Slow Shutter (off, 2X,
3X, 5X, 6X, 7.5X, 10X)
MIN. Illumination 0 Lux with IR (F1.6)
IR 80ft
Pan/Tilt/Zoom Z: X8 Optical Zoom
DNR 3D-DNR
Privacy Zone 16 Programmable Zones
AGC Auto
Other Image
Configurable Exposure, Sharpness
Processing
ENCODER (VIDEO AND AUDIO)
Video
H.264, H.265, MJPEG
Compression
H.264 Profile MP / HP
H.265 Profile MP
Multiple Profile
2592x1944p30 + 480p30 with
Streaming
H.264, H265 + MJPEG
Performance
100kbps ~ 10Mbps, Multi-rate for
Video Bitrate
Preview and Recording
Multi Streaming CBR/VBR at
Bitrate Control H.264, H.265 (Controllable frame
rate and Bandwidth)
Edge Storage Micro SD Card (SD/SDHC/SDXC)
I/O AND EVENT
Audio In/Out 1 (1.0Vrms, 3kΩ) / 1
Alarm In/Out 1 / 1
Video Output 1 (CVBS 1.0V p-p (75Ω)), 4:3
(2nd Video Out) aspect ratio
Event Notification FTP, E-mail, Alarm out, SD card
SECURITY AND NETWORK
IPv4: TCP/IP / UDP / AutoIP /
RTP (UDP/TCP) / RTSP / NTP /
HTTP / HTTPS / SSL / DNS /
Network Protocol
DDNS / DHCP / FTP / SMTP /
ICMP / SNMPv1/v2/v3 (MIB-2) /
ONVIF
HTTPS (TLS), IP filtering, 802.1x,
Security
Digest Authentication (ID/PW)
Plug in CGI API, ONVIF
GENERAL
Power
Temperature
Cold Start
Material
Dimensions
(WXDXH)
Weight
Certification
Warranty
81
(Adaptor is not Included)
DC12V: Max 9W
POE IEEE 802.3af Class3: Max
10.5W
-4°F ~ 122°F (-20°C ~ 50°C)
-40°F ~ 122°F (-40°C ~ 50°C)
Aluminum Die-casting
9.73" x 3.8" (247.2 x 96.7mm)
*Dimensions based on the
position of the sun shield cover
1.98 lbs (0.9kg)
FCC, CE, ROHS, IP66, IK9
5 year warranty
