Synthesis Page - Korg modwave native Manual

Synthesis page

Synthesis page
1: Oscillator Mode 2: Program Select
3: Layer
Select
4: Osc
Select
5: A/B
Blend
For information on all of the standard Edit page elements, see "Edit pages" on page 7.
1. Oscillator Mode
This three-way switch controls the basic capabilities of the current Oscillator. A plays a single Wavetable, A/B plays a
blend of two phase-synchronous Wavetables, and Sample plays a Multisample.
2: Program Select
This is the Program assigned to the Layer (see "Structure" on page 2). Programs contain all of the settings in the
Synthesis, Sequencer, and Effects pages. Use the < and > arrows to step through Programs one by one, or click on the
name to bring up a browser window. Right-click/control-click (macOS) on the name to bring up a contextual menu for
saving and renaming.
3: Layer Select
These select a Layer to view and edit. The power buttons turn the Layers on and off. When a Layer is selected, its
Synthesis, Motion Sequence, Arp & Setup, and Effects tabs appear below. The edit pages are color-coded to match the
layer; A is purple, and B is green.
4: Osc Select
The large tabs on the side, labeled 1 and 2, select which of the two oscillators is shown.
5: A/B Blend
This appears only if Mode is set to A/B. It controls the balance between Waves A and B. For more information, see "A/B
Blend" on page 26.
23
