Typical Applications
General procedures for all applications:
1.
Remove any molding from the ground conductor so that the jaws can close completely around the
conductor.
2.
Center the conductor in the jaw for highest accuracy.
3.
Take the reading.
4.
Replace the molding.
Service Entrance or Meter
Multiple Ground Rods
Service Meter
Water Pipe Ground
Building Wall
Service Box
Service Meter
Note: Clamp onto the conductor between the
service neutral and both grounded points.
CMGRT-100A
Building Wall
Service Box
Water Pipe
25
