- Page 1 OPERATING MANUAL TRITON HEAVY TRNH 300 P Edition: 1 | effective from: 1. 9. 2022 IČ: Farmet a. s. telefon: +420 491 450 111 46504931 web: www.farmet.cz Jiřinková 276 DIČ: CZ46504931 fax: +420 491 450 136 e-mail: farmet@farmet.cz 552 03 Česká Skalice, CZ...
- Page 2 TRITON TRNH 300 P Dear customer, Semi-carried cultivators TRITON HEAVY are quality products of Farmet a.s. Ceska Skalice. You can fully utilise the advantages of your machine after thoroughly studying the operating manual. The serial number of the machine is punched on the production label and written in the operating manual (see Table 1).
-
Page 3: Table Of Contents
Manual TRITON TRNH 300 P TABLE OF CONTENTS MACHINE LIMIT PARAMETERS ........................ 4 Technical parameters ......................... 4 Safety statement ..........................5 A. GENERAL INTRUCTIONS FOR USE ....................... 6 B. MACHINE TRANSPORT USING TRANSPORT MEANS ................7 C. MACHINE HANDLING USING LIFTING EQUIPMENT ................8 D. -
Page 4: Machine Limit Parameters
Manual TRITON TRNH 300 P MACHINE LIMIT PARAMETERS • The machine is designed for soil cultivation when agricultural soil cultivation. Another type of use exceeding the determined purpose is forbidden. • The machine is only operated by one person - the tractor operator. •... -
Page 5: Safety Statement
Manual TRITON TRNH 300 P Weight distribution on the machine during transport Version with a double roller 420 kg 4 850 kg SAFETY STATEMENT This warning sign warns about an immediate dangerous situation ending with death or severe injury. This warning sign warns about a dangerous situation ending with death or severe injury. -
Page 6: General Intructions For Use
Manual TRITON TRNH 300 P GENERAL INTRUCTIONS FOR USE The machine is made in accordance with the latest equipment state and approved safety regulations. ▪ However, dangers of user or third person injury or machine damage or creation of other material damage may arise during use. -
Page 7: Machine Transport Using Transport Means
Manual TRITON TRNH 300 P MACHINE TRANSPORT USING TRANSPORT MEANS The transport means designed for machine transport must have the load capacity minimally identical with the weight of the transported machine. The total weight of the machine is stated on the production label. -
Page 8: Machine Handling Using Lifting Equipment
Manual TRITON TRNH 300 P MACHINE HANDLING USING LIFTING EQUIPMENT The lifting equipment and tying means designed for handling of the machine must have their load capacity at least identical with the weight of the handled machine. Machine fastening for handling may only be performed in places designed for that and marked with self- adhesive labels showing the "chain"... -
Page 9: Work Safety Labels
Manual TRITON TRNH 300 P WORK SAFETY LABELS Warning safety labels serve for operator protection. General: A) Strictly observe the warning safety labels. B) All safety instructions also apply to other users. C) Upon damage or destruction of the aforementioned "SAFETY LABEL" located on the machine, THE OPERATOR IS OBLIGED TO REPLACE IT WITH A NEW ONE!!! The position, appearance, and precise meaning of work safety labels on the machine is determined in the following tables (Tab. - Page 10 Manual TRITON TRNH 300 P Secure the machine against P 52 H unwanted movement by positioning on its working bodies. Stay outside the reach of the tractor P 53 H - agricultural machine set, if the tractor engine is in operation. The shown positions of the lever and P 101 H the function of the hydraulic...
- Page 11 Manual TRITON TRNH 300 P LOCATION OF SAFETY LABELS ON THE MACHINE P20H P20H P52H P20H P37H P20H P53H P20H P20H P52H P20H P37H P53H P20H P13H P20H P100 11 │ 38...
-
Page 12: Description
Manual TRITON TRNH 300 P 1. DESCRIPTION The TRITON 300 P machine is designed as semi-carried and not folding. The basic version consists of the drawbar, which connects to the pulling vehicle according to the corresponding equipment. Then, there is a central frame with the transport axle and the working section frames. -
Page 13: Working Parts
Release force 2,000 kg ▪ Massive, welded beam for the row of discs ▪ Individual Farmet maintenance-free bearing of the individual discs with grease CHISEL WORKING UNIT ▪ The scope of release of the unit is determined by the piston-rod lift. - Page 14 Manual TRITON TRNH 300 P OVERVIEW OF THE WORKING PARTS CHISEL CARBIDE 55 CHISEL CARBIDE 75 CHISEL MULTICARBIDE PRO 50 CHISEL MULTICARBIDE PRO 75 SHARE TOP CUTTING WINGS 100 or 135 14 │ 38...
-
Page 15: Working Without Rollers
Manual TRITON TRNH 300 P 1.3. WORKING WITHOUT ROLLERS • The machine is designed to be used without the rollers. • It makes it possible to use the machine when the conditions are wet or when a coarser soil structure is required after cultivation. -
Page 16: Hydraulics
Manual TRITON TRNH 300 P 2. HYDRAULICS 2.1. SHUT OFF (BALL) VALVE FUNCTION AND POSITION Shut-off (ball) valves are used in the machine on a well-arranged panel. ▪ HYDRAULICS CONTROL PANEL 2.2. HYDRAULICS CONTROL PANEL WITH TWO CLOSING VALVES LOCKING THE FRONT CHISEL ROW AXLE UNLOCKING/LOCKING 16 │... -
Page 17: Description Of Machine Hydraulics
Manual TRITON TRNH 300 P 2.3. DESCRIPTION OF MACHINE HYDRAULICS When disconnecting the quick couplers, both valves on the drawbar must be closed in the same way as ▪ for road transportation. Connect the hydraulics only when the hydraulic circuits of the machine and the tractor (aggregate) are in ▪... - Page 18 Manual TRITON TRNH 300 P YELLOW DUST CAPS – controlling the transport axle GREEN DUST CAPS – controlling the position of the front disc section BLUE DUST CAPS – controlling the position of the rear packer discs (supporting legs – when included) WHITE DUST CAPS –...
-
Page 19: Using The Hydraulics Control Panel
Manual TRITON TRNH 300 P 2.4. USING THE HYDRAULICS CONTROL PANEL ▪ There is a control panel with valves (the number of levers may differ according to the machine equipment). ▪ Changing the levers switch over or close the ball valves in the hydraulic circuits. ▪... -
Page 20: Working With The Disc And Chisel Sections
Manual TRITON TRNH 300 P 2.5. WORKING WITH THE DISC AND CHISEL SECTIONS ▪ The protection of both rows of discs and chisels is performed using the pressure accumulators. ▪ The circuits of the hydraulic protection of discs and chisels must be pressurized at the prescribed values. ▪... -
Page 21: Machine Assembly At The Customer
Manual TRITON TRNH 300 P 3. MACHINE ASSEMBLY AT THE CUSTOMER ▪ The operator must perform the assembly according to the instructions of the producer, best in cooperation with the expert servicing technician determined by the producer. ▪ The operator must secure a functional test of all assembled parts after the completion of the machine assembly. -
Page 22: Aggregation To A Tractor
Manual TRITON TRNH 300 P 5. AGGREGATION TO A TRACTOR ▪ The machine can be connected only to a tractor, whose curb weight is identical or higher than the overall weight of the connected machine. The machine operator must observe all generally valid regulations of work safety, health protection, fire ▪... -
Page 23: Machine Transport On Roads
Manual TRITON TRNH 300 P 6. MACHINE TRANSPORT ON ROADS TRITON TRNH 300 P Transport position of o Connect the machine by attaching it to the tractor. o Lift the machine up on the axle, move the lever for locking the machine on the hydraulics control panel into the locked position for transport. - Page 24 Manual TRITON TRNH 300 P Checking the nuts on the transport axle ▪ Use the plastic arrow “Check Point” to check for loose nuts. It promptly shows the condition of the nuts, whether they are loose or not. ▪ Always check the Check Points before driving. ▪...
-
Page 25: Scharp Machine Projection
Manual TRITON TRNH 300 P SCHARP MACHINE PROJECTION ▪ The machine contains sharp structural projections ▪ It is prohibited to operate and transport the machine on roads when visibility is reduced!! - Persons or objects, or other road traffic participants could get caught. ▪... -
Page 26: Machine Adjustment
Manual TRITON TRNH 300 P 7. MACHINE ADJUSTMENT 7.1. WORKING DEPTH ADJUSTMENT ADJUSTING SETTING DISC DEPTH OF THE SECTION ROLLERS DEPTH DEPTH SETTING – WORK WITHOUT ROLLERS SETTING THE TRACTOR ARM HEIGHT 26 │ 38... - Page 27 Manual TRITON TRNH 300 P SETTING THE WORKING DEPTH OF THE CHISELS ▪ The chisel working depth is set by adjusting the height of the machine support frame above ground. ▪ In the front of the machine, depth is set using the height of the tractor hitch above ground. ▪...
- Page 28 Manual TRITON TRNH 300 P SETTING THE WORKING DEPTH OF THE CHISELS DURING WORK WITHOUT THE ROLLER ▪ When working without the rollers, the depth can be set using the transport axle. ▪ Working without rollers is especially convenient when the conditions are wet, or when a coarser soil structure is required, for example, in winter.
- Page 29 Manual TRITON TRNH 300 P Setting the working depth of the front disc section ▪ The working depth of the disc section depends on the set depth of the chisels. ▪ The setting range for the front disc section is 330 mm so that it is possible to cover the range of the working depth of the discs from 60 to 180 mm for all the working depths of the chisel section.
-
Page 30: Adjusting The Levelling Discs
Manual TRITON TRNH 300 P 7.2. ADJUSTING THE LEVELLING DISCS The depth of the levelling discs is set using the hydraulic circuit (BLUE). Be careful when performing the adjustment. The height setting of the levelling discs can be checked on the indicator as shown in the picture (1 –... -
Page 31: Adjusting Side Deflectors
Manual TRITON TRNH 300 P 7.3. ADJUSTING SIDE DEFLECTORS ▪ The side deflectors must be slightly adjusted for proper setting of passes. ▪ The side deflectors must not exceed the width of 3 metres when travelling on roads. ▪ After readjusting the deflector, check that there is no collision with the machine frame. ▪... -
Page 32: Edge Levelling Discs
Manual TRITON TRNH 300 P 7.4. EDGE LEVELLING DISCS ▪ The edge levelling discs must be inserted for transport in order to reach the transport width below 3 metres. ▪ For work, you can choose one of two working positions according to the specific conditions. ▪... -
Page 33: Machine Maintenance And Repairs
Manual TRITON TRNH 300 P 8. MACHINE MAINTENANCE AND REPAIRS Observe the safety instructions for treatment and maintenance. ▪ If it is necessary to weld during the repair and have the machine connected to the tractor, it must have disconnected supply cables from the alternator and the accumulator. Check the tightening of all screw and other assembly connections at the machine before every use of the ▪... -
Page 34: Checking The Accumulator Pressure
Manual TRITON TRNH 300 P 8.1. CHECKING THE ACCUMULATOR PRESSURE ▪ A proper pressure is required for the proper protection function. ▪ In case of a pressure loss in the accumulator, the release force quickly increases, the protection is overloaded, which may lead to its damage. ▪... -
Page 35: Machine Storage
Manual TRITON TRNH 300 P 9. MACHINE STORAGE Long-term machine shutdown: ▪ Store the machine under a roof if possible. ▪ Store the machine on a flat and solid surface with sufficient load capacity. ▪ Clean the machine before storing and conserve so that it is not damaged in any way during storage. ▪... -
Page 36: Machine Lubrication Schedule
Manual TRITON TRNH 300 P MACHINE LUBRICATION SCHEDULE During machine maintenance and its lubrication, it is necessary to observe the safety regulations. LUBRICATION POINT INTERVAL LUBRICANT ▪ Once a week TOW BAR JOINT ▪ Always before the work with the Grease class NGLI 2 with EP machine additives... -
Page 37: Environmental Protection
This provision does not apply to the replacement of wearable spare parts (see point 13.2.3). 13.2.8 The warranty is conditioned by using the genuine spare parts of the manufacturer. Prepared by: Technical Department, Farmet a.s., Jirinkova 276, Ceska Skalice 552 03, On 12 October 2022, changes reserved. 37 │ 38... -
Page 38: Ce Certificate Of Conformity
CE CERTIFICATE OF CONFORMITY EG-KONFORMITÄTSERKLÄRUNG DÉCLARATION CE DE CONFORMITÉ СЕРТИФИКАТ СООТВЕТСТВИЯ ЕС DEKLARACJA ZGODNOŚCI WE Nous Мы Farmet a.s. Jiřinková 276 552 03 Česká Skalice Czech Republic DIČ: CZ46504931 Tel/Fax: 00420 491 450136 Vydáváme na vlastní zodpovědnost toto prohlášení. Hereby issue, on our responsibility, this Certificate.
