Xerox
AltaLink
C8130/C8135/C8145/C8155/C8170
Color Multifunction Printer
Control Panel
Available apps can vary based on your printer setup. For details about apps and features, refer to the User
Guide.
5
1
Home
returns to the main app screen.
2
Power/Wake
starts the printer or provides options to sleep, restart or power off the printer.
3
Reset
restores settings to their default values in all apps.
4
Language
provides choice of screen languages.
5
Log In
provides special access to tools and settings.
6
Device app
provides access to printer information and settings.
7
Pause Printing
temporarily stops an active print job.
8
Interrupt Print Job
interrupts the current job to copy or print another job.
9
Status messages
shows printer status and warnings.
10
Status LED
indicates printer status. For detailed information, refer to the User Guide.
11
NFC Area
allows pairing with a mobile device to print or scan from an app.
© 2019 Xerox Corporation. All Rights Reserved. Xerox
of Xerox Corporation in the United States and/or other countries. BR25977
9
®
®
, and AltaLink
are trademarks
8
7
2
4
3
1
6
11
10
www.xerox.com/office/support

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AltaLink C8130 and is the answer not in the manual?

Questions and answers

Related Manuals for Xerox AltaLink C8130

Summary of Contents for Xerox AltaLink C8130

  • Page 1 ® ® © 2019 Xerox Corporation. All Rights Reserved. Xerox , and AltaLink are trademarks of Xerox Corporation in the United States and/or other countries. BR25977...

  • Page 2: Billing And Usage Information

    In the Device features menu, to view basic impression counts, touch Billing/Usage. To view detailed usage counts, touch Usage Counters. The list provides detailed impression count categories. www.xerox.com/office/support ® ® © 2019 Xerox Corporation. All Rights Reserved. Xerox , and AltaLink are trademarks of Xerox Corporation in the United States and/or other countries. BR25977...

  • Page 3: Printer Tour

    To select sleep mode, press the secondary power switch (1). At the printer control panel touch screen, touch a selection. www.xerox.com/office/support ® ® © 2019 Xerox Corporation. All Rights Reserved. Xerox , and AltaLink are trademarks of Xerox Corporation in the United States and/or other countries. BR25977...

  • Page 4: Paper Handling

    fit the paper size. Do not load paper above the maximum fill line. Paper Orientation Letterhead Hole Punched Envelope www.xerox.com/office/support ® ® © 2019 Xerox Corporation. All Rights Reserved. Xerox , and AltaLink are trademarks of Xerox Corporation in the United States and/or other countries. BR25977...
  • Page 5 Reset. Select feature settings from the list, then touch Start. www.xerox.com/office/support ® ® © 2019 Xerox Corporation. All Rights Reserved. Xerox , and AltaLink are trademarks of Xerox Corporation in the United States and/or other countries. BR25977...
  • Page 6 Scanning. If your scan destination is stored in the Address Book or saved as a Favorite, touch Scan To. www.xerox.com/office/support ® ® © 2019 Xerox Corporation. All Rights Reserved. Xerox , and AltaLink are trademarks of Xerox Corporation in the United States and/or other countries. BR25977...
  • Page 7 To restore the default settings in an app, scroll to the bottom of the feature list, then touch Reset. Change the settings as needed, then touch Scan, or for Email, touch Send. www.xerox.com/office/support Scanning and Emailing...

  • Page 8: Retrieving Scan Files

    Home, touch Device > About then scroll to check the IP Address. http://xxx.xxx.xxx.xxx http://xxx.xxx.xxx.xxx Click the Scan tab. In a Web browser, type the printer IP address, then press Enter or Return. www.xerox.com/office/support Scanning and Emailing...
  • Page 9 To refresh the list, click Update View. To save the file to your computer, select Download. To print the saved file again, select Reprint. To permanently remove the stored job, select Delete. To open a directory, select Open. www.xerox.com/office/support Scanning and Emailing...
  • Page 10 To send the fax as an email attachment, touch Home, then touch Internet Fax. www.xerox.com/office/support ® ® © 2019 Xerox Corporation. All Rights Reserved. Xerox , and AltaLink are trademarks of Xerox Corporation in the United States and/or other countries. BR25977...
  • Page 11 Note: Settings from previous users remain onscreen for a short time. To restore the default settings in an app, scroll to the bottom of the feature list, then touch Reset. Change the settings as needed, then touch Send. www.xerox.com/office/support Faxing...

  • Page 12: Printing From A Usb Flash Drive

    Reset. Select settings as needed, then touch Print. www.xerox.com/office/support ® ® © 2019 Xerox Corporation. All Rights Reserved. Xerox , and AltaLink are trademarks of Xerox Corporation in the United States and/or other countries. BR25977...

  • Page 13: Printing Jobs Stored On The Printer

    You can send a print job to save to the printer, then select the job from the printer control panel to print at ® a later time. Jobs can be saved in the public folder or be password protected. In the Xerox printer driver, select Properties (Windows) or Xerox Features (Mac OS), then Job Type.
