Inverter and Battery Module Displays
Object
A
B
C
D
E
F
H
The inverter online pages will are shown below. The displayed page will change every 3 seconds automatically. If the user wishes
to manually cycle through the pages, use the UP and DOWN buttons. If the user wishes to stop the pages cycling, press the ENTER
key to lock the screen.
PV1 INPUT
VOLT : 33.8V PV1 Input Voltage
CURR : 0.00A PV1 Input Current
POWER : 0W PV1 Input Power
BATTERY
VOLT : 42.2V Battery Input Voltage
Battery Current
CURR : 20.2A
CAPACITY : 40Ah Battery Capacity
GRID DATA
Mains Voltage
VOLT : 239.8V
Mains Current
CURR : 0.00A
Mains Frequency
FREQ : 50.12Hz
POWER
Inverter Total Power
INV : W
GRID : W Grid Total Power
LOAD : W Load Total Power
STATE
SYS : G-BYPASS Current System Status
INV : STANDBY Current Inverter Status
DCDC : STANDBY Current DC-DC Status
Telephone : +44 (0) 1245 428500
Email : sales@rayleigh.com
Name
Green: Grid connection (Solid). Not connected (Flashing)

Indicator LED

Green: Indication of Off - grid status
Red: The inverter is in fault.
Return key: Enter programming or return one level .
Up key: Move cursor up or increase value.

Key Function

Down key: Move cursor down or decrease value.
Enter key: Confirm the selection.
PV2 INPUT
VOLT : 49.8V
CURR : 0.00A
POWER : 0W
BMS PARAM
TYPE : RI-MOD 5.1
TEMP : 25°C
SOC : 90%
INV DATA
VOLT : 50.0V
CURR : 0.00A
FREQ : 0.00Hz
POWER
PV : W
BACKUP : W
BAT : W
ERROR NO.
WARNING : W20-1
FAULT : XXX-X
RI-ENERGYFLOW-MODULAR SERIES
Description
DC VOLTAGE
PV2 Input Voltage
PV2 Input Current BUS :
PV2 Input Power
BMS PARAM
Battery Type
CHAR VOLT :
Battery Temperature CHARGE :
Percentage of Battery
DISCHARGE :
BACKUP DATA
Inverter Voltage
VOLT :
Inverter Current
CURR :
Inverter Frequency
TEMPERATURE
PV Generation Power
INV :
Backup Output Power
DCDC :
Total Power Supplied
AMBIENT :
from battery
Warning Code STATE :
Fault Code GRID :
PV I/P :
www.rayleigh.com
310.8V DC Bus Voltage
50V Battery Charging Voltage
60A Battery Charging Current
10A Battery Discharging
Current
237.3V Backup Output Voltage
0.00A Backup Output Current
Inverter Heat-sink Temperature
23.1°C
DC-DC Heat-sink Temperature
21.5°C
Internal Ambient Temperature
24°C
SYSTEM
Setup Status (Work Mode)
SELF CSM
Grid Standard
U.K.
PV Mode (PV Input)
INDEPEN
| Continued
