Rayleigh Instruments RI-ENERGYFLOW-MODULAR Series Quick Start Installation Manual page 10

Menu Path: Setup > Enter Password (Default 00000) > Grid STD):
1. China
2. Germany
3. Australia
4. Italy
5. Spain
6. UK
Grid STD 7. Hungary
8. Belgium
9. New
Zealand
10. Greece
11. France
12. Bangkok
Menu Path: Setup > Enter Password (Default 00000) > Run Setting:
REACT MODE
GRID POWER
VOLT MAX
VOLT MIN
FREQ MAX
FREQ MIN
Run Setting
OVER VOLT
UNDER VOLT
OVER FREQ
UNDER FREQ
REACT RESP
VRT ENABLE
POW SI RATE
Telephone : +44 (0) 1245 428500
Email : sales@rayleigh.com
13. Thailand
14. South Africa
15. 50549
16. Brazil
17. 0126
18. Ireland
19. Israel
20. Poland
21. Chile
22. Local
23. 60Hz
24. Denmark
Enabled -
Power Factor
PF1.0 (UK)
React Power
QU Curve
QP Curve
0...110%
INV Max 264V (UK)
Grid Max 276V (UK)
INV Min 184V (UK)
Grid Min 172V (UK)
INV Max 52Hz (UK)
Grid Max 53.5Hz (UK)
INV Min 47Hz (UK)
Grid Min 46Hz (UK)
Disable Enabled (264V
Enable
Disable Enabled (200V
Enable
Disable Enabled
Enable (50.2Hz UK)
Disable Enabled
Enable (49.25Hz UK)
0...60
10 Seconds
Disable
Enable
Enable
0...300%
RI-ENERGYFLOW-MODULAR SERIES
Allows the user to select the country that the system is
6. UK
The inverter can monitor reactive power in several ways.
This setting is set according to the selected grid standard
and should not be changed. For UK grid setting the
default method is power factor.
Limit or increase the power exported from the system to
100%
These settings should not be altered. They are set
automatically according to the country selected within
If the inverter sees that these values have been reached,
UK)
or exceeded, then the inverter will stop generating.
UK)
This is the time it takes for the exported reactive power
to reach the grid standard level. This setting should not
be changed and is set according to the grid standard.
Voltage-ride-through. This setting should not be
changed and is set automatically according to the grid
This is the rate of change of the output. This setting
100% should not be changed and is set according to grid
standard. 100% means that the output will hit full power
www.rayleigh.com
installed in
the grid.
Grid Setting.
| Continued
