- Page 1 User’s manual MP-FUB27 www.mpmaneurope.com Before connecting, operating or adjusting this product please read these instructions completely.
- Page 2 ♠ Supports two lines of lyrics display synchronization ♠ Big display (128*32) LCD display ♠ Seven colors display ♠ Supports Firmware upgrade function ♠ Voice equalizer ♠ GUI (graphical user interfaces). The box: (1) MP3 player 1Pcs (2) Stereo earphone 1Pcs (3) CD ROM 1Pcs (4) Manual...
- Page 3 1.1 The player appearance interface (12) (11) (10) (13) REC A-B HOLD (14) (11 ) (12 ) (10 ) ( 1) ( 3) ( 4) (13) ( 8) ( 5) HO LD VO L (14 )
- Page 4 1.2 The buttons ” ⇒ OPEN/PLAY/PAUSE/STOP/POWER OFF (1) “ (2) “MODE” ⇒ Switch modes, menu selection by pressing on button (3) “ ” ⇒ NEXT/FWD (4) “ ” ⇒ PREV/REV (5) “VOL+”⇒Volume increase/fast increase (6) “VOL-”⇒Volume decrease/fast decrease (7) “HOLD” ⇒ Keyboard lock switch (8) “...
- Page 5 2 Display and operating instruction 2.1 Turning on the MP3 player Push the “PLAY” button for several seconds. The LCD display will light up. 2.2 Main menu Five options: 1) MUSIC 2) FM 3) RECORD 4) VOICE 5) SYSTEM You can switch between thos e 5 options by sliding the “MODE”...
- Page 6 1. MUSIC 2. FM 3.RECORD 4. VOICE 5.SYSTEM 1. D irectory 2. Lyric 3.Memory Info 4.Rec Filter 5.Back Light 6. Auto Off 7. Font Set 8. Contrast 9.Delete File 10. S/W version 11.Record Mode 12. Back Light 13. Exit 6. USB Select “1.MUSIC”...
- Page 7 The submenu structure: 1. Repeat 2. EQ Select 3. A-B play 4. Exit 2.2.3 Repeat mode Press “MODE” button to enter into repeat mode submenu: 1. Normal 2. Repeat One 3. Repeat All 4. Introduce Select the desired playback mode by sliding the but ton right “...
- Page 8 Choose a soundeffect by slidin g the “M ODE” button to the right “ ” .5 A-B replay mode idea of this mode is to select a part of a song that will be repeated continuously. Afterwards y ou can imitate that song while your voice is recorded. In the end the the real song and your recording will be heared.
- Page 9 Slide right“ ” during the original playback to hear your recorded voice. Otherwise the recording will restart, and the previous recording will be lost. Push the “MODE”button any time to leave this menu. 2.3 F 2.3 F M Reception M Reception Radio m Radio m ode has five states: stop, search, receiving, auto, store.
- Page 10 2.3.2.2 Half-auto searching In “ SEARCHING” state: Slide right “ ” or left “ ” and hold. The device wi ll automatically search for the next av ailable station 2.3.2.3 Auto searching Push the “MODE” button and hold for a few seconds. The device will enter auto searching mode uring auto searching, all the channels (87.5-108 MHz) will be searched, once a valid signals is...
- Page 11 2.4 Recording mode Select “3. Recording mode” in the main menu. Push the “MODE” button to enter “3. RECORD” m here are three recording formats: Fine record, long record and VOX record. 2.4.1 Record In Record mode, press “ ” key to record. 2.4.2 P ause During recordi...
- Page 12 2.5 V oice mode Select “4. VOICE” in the main menu. Push “MODE” button to confirm 2.5.1 Voice play In the mode of record play, push “ ”button to play record. 2.5.2 Pause voice play During playback, push “ ”button to pause. 2.5.3 S top voice play Push “MODE”...
- Page 13 2.6 System setup Select “5. SYST EM” in the main menu. Push “MODE” button to confirm 2.6.1 D irectory selection lect “1. DIRECTORY” in the main menu of system setup and push “MODE” button to enter the directory submenu. 1. Music Dir 2.
- Page 14 confirm. 2.6.5 Backlight setting Select “5. Back Light ” in the main menu of system setup and push “MODE” button to en ter. Slide right “ ” or left “ ” to set the light activating time and push “MODE” button to confirm The setting time is 0-30se c.
- Page 15 range is between 00 (lightest) and 31 (darkest). 2.6.9 Delete File Select “9. Delete File” in the main menu of syste m setup and push “MODE” button to enter submenu: 1. Del Music 2. Del Record 3. Exit Enter in next submenu with “MODE” button: 1.
- Page 16 VOX REC 2.6.12 Backlight color Select “12.Backlight color” i n the main me nu of system setup and push “MODE” k ey to enter its submenu, slide “ ” or “ ” to select and confirm with “MODE” button. Backlig ht 0 Backlight1 Backlight2...
- Page 17 The player will return to the main menu automatically when connection between PC and the player is cut off.. ote: The player supplies WIN98/WIN ME /WIN 2K./ WIN XP system format (under WIN 2K/WIN XP system, only support FAT/FAT16 format.) 2.7 V olume adjustment Press “V...
- Page 18 2.12 Upload and dow nload, removal of MP3 songs or other files After the MP3 player is connected to PC, the PC will identify the play “Portable (D:)” drive, hence the operating process for the MP3 player is the same as operating its own HD or SD. From the PC all the files on the player can be copied and deleted .
- Page 19 17 Weight 30g (without battery) 18 Size 96mm×30mm×21mm (length×width×height)
- Page 20 WAVE files with the attached software. Please install the software and follow the instructions. Chinese text By accident, the menu on MP3 player can be changed from English into Chinese. To change back to English, please follow these steps: Select page 4/5 by pushing the button left or right, press it once.
