- Page 1 DIGITAL MUSIC PLAYER MP3&WMA USER MANUAL MP-FUB30 www.mpmaneurope.com ___________________________________________________________________ Before connecting, operating or adjusting this product please read these instructions completely.
- Page 2 ♠ Supports two lines of lyrics display synchronization ♠ Big display (128*32) LCD display ♠ Voice equalizer ♠ GUI (graphical user interfaces). Inside the box: (1) MP3 player (2) Stereo earphone one pair (3) Installation disk (4) User’s manual (5) USB cable (6) Battery 1.5V/”AAA”...
- Page 3 The player appearance interface 1.2 The buttons ” ⇒ OPEN/PLAY/PAUSE/STOP/POWER OFF (1) PLAY “ (2) “REC” ⇒ Rec/A-B (3) “HOLD” ⇒ Keyboard lock switch (4) “VOL-”⇒Volume decrease/fast decrease (5) “VOL+”⇒Volume increase/fast increase (6) “ ” ⇒ NEXT/FWD (7)“ ” ⇒ PREV/REV (8) “MODE”...
-
Page 4: Operating Instruction
Push-button includes four operation methods as short push, long push, push and hold, single push. 1.4 Display This player adopts big LCD of 128*32 2 Operating instruction 2.1 Turning on the MP3 player Push the “PLAY” button for several seconds. The LCD display will light up. - Page 5 2.2 Main menu Press the “MODE” button for several seconds, from any point in the menu, and the player returns automatically back to the main menu. Four options: 1) MUSIC 2) RECORD 3) VOICE REPLAY 4) SYSTEM Music Record Replay System You can switch between options by sliding the “MODE”...
- Page 6 Four options: Local Folder Delete file Delete all Exit 2.3.1.1 Local folder 主盘目录 Local folder Files can be stored in different folders (maximum 10 folders including root folder). Create new folders in Windows explorer when MP3 is connected. Open “external drive”. Create new folder - Press "Mode"...
- Page 7 Repeat Equalizer Tempo Rate Replay Replay times Replay gap Exit 2.3.2.1 Repeat All songs are played once Normal Repeats the current song Repeat One Plays all the music of a specific folder Folder Repeats the music of a specific folder Repeat Folder Repeats all the music.
- Page 8 Here you are able to choose how many times (1-10) the A-B section will be repeated. 2.3.2.6 Replay gap Choose the time (1-10 sec) between each A-B section. 2.3.3 Lyrics This MP3 player supports "*. lrc "Lyric files Lyrics can be downloaded from the internet. Make sure that lrc-file has the same name as the...
- Page 9 corresponding song. For example: If the song name is “Yesterday.mp3 “, the lyric file should be named “Yesterday.lrc” MP3 and LRC file must be stored in the same folder! No Lyric Lyric included Attention: A lyric can not be larger then 500 words. 2.4 Record mode -Select "Record mode "...
- Page 10 2.4.1.2 REC type Four options: “Fine REC”: high quality recording, wav format, good quality. “Long REC”: lower quality recording, act format, uses less space “Fine VOR”: wav format “Long VOR”: act format When using “VOR recording”, the player enters into the state of “pause recording” if no sound is detected by the microphone.
- Page 11 2.5.2 Replay submenu During playback, press “Mode” button to enter the Replay submenu. 4 options: - Repeat - Tempo rate - Replay - Exit Those options are similar to the music play submenu 2.6 Systems set up Select “System” in the main menu Record Time Backlight Language...
- Page 12 When date and time are correct, press mode button to confirm. 2.6.2 Backlight Adjust the backlight intensity between 0 and 30, by pushing Mode button left or right. Press Mode Button to confirm 2.6.3 Language Change the language by moving Mode button left or right. Press Mode button to confirm.
- Page 13 2.6.7 Online mode Multi drive Normal ( 1 drive) Encrypted drive 2.6.8 Memory info Gives a percentage of the used memory compared to the total memory size 2.6.9 Firmware version Info about software version 2.7 USB disk use The unit functions as a standard USB disk with most operating systems. Windows98 (driver needed) Windows 2000 and above ( no need to install driver, the driver is automatically recognized by the PC)
- Page 14 - “ send data” mode Attention!! Removing the device from the PC during data transfer can cause severe damage to the device! 2.8 Hold switch When "HOLD " switch is moved left, the other buttons are inactive and “Hold icon” will light up. 2.9 Specification (1) FLASH Memory 128MB, 256MB, 512MB, 1GB...
- Page 15 battery and reinstall it afterwards. FOR MORE INFORMATION DO NOT HESITATE TO VISIT OUR WEBSITE www.mpmaneurope.com...
