- Page 1 DIGITAL MUSIC PLAYER MP3&WMA USER MANUAL MP-FUB35 www.mpmaneurope.com ________________________________________________________________________________ Before connecting, operating or adjusting this product please read these instructions completely.
- Page 2 ♠ Supports two lines of lyrics display synchronization ♠ Big display (128*32) LCD display ♠ Voice equalizer ♠ GUI (graphical user interfaces). Inside the box: (1) MP3 player (2) Stereo earphone one pair (3) Installation disk (4) User’s manual (5) USB cable (6) Battery 1.5V/”AAA”...
- Page 3 1.1 The player appearance interface 1.2 The buttons (1) “HOLD” ⇒ Keyboard lock switch (2) “MENU” ⇒ Switch modes, menu selection by pressing on button (3) “REC” ⇒ Rec/A-B (4) “VOL-”⇒Volume decrease/fast decrease (5) “VOL+”⇒Volume increase/fast increase (6) “ ” ⇒ NEXT/FWD (7)“...
-
Page 4: Operating Instructions
2 Operating instructions 2.1 Turning on the MP3 player Push the “PLAY” button for several seconds. The LCD display will light up. 2.2 Main menu Press the “MENU” button for several seconds, from any point in the menu, and the player returns automatically back to the main menu. - Page 5 2.3.1.1 Local folder Files can be stored in different folders (maximum 10 folders including root folder). Create new folders in Windows explorer when MP3 is connected. Open “external drive”. Create new folder - Press " MENU " button to open Local folder - Move PLAY button left or right to select the catalog - Press “MENU ”...
- Page 6 Choose the time (1-10 sec) between each A-B section. 2.3.3 Lyrics This MP3 player supports "*. lrc "Lyric files Lyrics can be downloaded from the internet. Make sure that lrc-file has the same name as the corresponding song. For example: If the song name is “Yesterday.mp3 “, the lyric file should be named “Yesterday.lrc”...
- Page 7 2.4 Record mode -Select "Record mode " in the main menu. The unit can store 99 recordings in each folder with a maximum of 10 folders (including root folder) - Press “PLAY” button to start recording. - Press “PLAY” button again to pause the recording (Time flashes). - Press “PLAY”...
- Page 8 2.5.1.3 Delete all (Stop submenu) Deletes all files of the current catalog 2.5.2 Replay submenu During playback, press “MENU” button to enter the Replay submenu. 4 options: - Repeat - Tempo rate - Replay - Exit Those options are similar to the music play submenu 2.6 FM mode Choose in main menu "FM mode ".
- Page 9 2.6.1.2 Delete broadcaster With this function, stored stations can be removed. 2.6.1.3 Delete all broadcaster With this function, all stored stations can be removed. 2.6.1.4 Normal band 87MHz –108MHz 2.6.1.5 Japan band 76MHz –96MHz 2.6.1.6 Fine REC type With this function music from a radio station can be recorded. Press “PLAY”...
- Page 10 2.7.1 System Time Enter here the correct date and time. Press VOL+ button and the year- number will start flashing. Change the year number by pushing PLAY button left or right Press again VOL+ button and the months will start flashing…. When date and time are correct, press “MENU”...
- Page 11 2.8 USB disk use The unit functions as a standard USB disk with most operating systems. Windows98 (driver needed) Windows 2000 and above (no need to install driver, the driver is automatically recognized by the PC) When connected with PC (battery not needed), the device can be in 3 different modes - “wait”...
- Page 12 2.10 Specification (1) FLASH Memory (2) music format (3) FM (4) FM sensitivity (5) liquid crystal display monitor (6) Display Color (7)Languages (8) Power supply (9) USB2.0 (10) recording (11) frequency response (12) distortion (13) baud rate (14) weight (15) size 3.0 Troubleshooting If for any reason your player is blocked, you can simply do a firmware reset by taking out the battery and reinstall it afterwards.
