- Page 1 DIGITAL MUSIC PLAYER MP3&WMA USER MANUAL MPF-59 www.mpmaneurope.com ___________________________________________________________________ Before connecting, operating or adjusting this product please read these instructions completely.
- Page 2 UP TILL 99 SONGS IN ONE DIRECTORY YOUR MP-F59 ACCEPTS UPTILL 99 SONGS IN ONE DIRECTORY IF YOU WANT MORE THEN 99 SONGS, STORE THEM IN A NEW DIRECTORY IN PLAY MODE, YOU CAN CHANGE THE DIRECTORY IN THE MENU. DON’T FORGET: MAXIMUM 99 SONGS IN EACH DIRECTORY...
- Page 3 1.1The player characteristics ♠ Supports MP3 and WMA music format. ♠ Supports USB function ♠ Supports two lines of lyrics display synchronization ♠ Big display (128*32) LCD display ♠ Supports Firmware upgrade function ♠ Voice equalizer ♠ GUI (graphical user interfaces).
- Page 4 1.2 The player appearance interface...
-
Page 5: Power On/Off
1.3 Figure & Keys 1) Play/Pause 2) F.FWD/F.REV, Previous/Next, 3) Menu, 4) REC, 5) Vol+/-, 6) LCD, 7) Push button of USB Port, 8) Power ON/OFF 9) Earphone, 10) USB Port, 11) Cord Hole, 12) Mic 1.4 Display This player adopts big LCD of 128*32 lattice 1.5 Battery The screen shows a battery indicator with nine levels. - Page 6 2 Operating instruction 2.1 Turning on/off the MP3 player Slide switch (8) to the right. The LCD display will light up. Slide switch (8) to the left. The MP3 player will shut off. 2.2 Main menu Press the “Menu” button for several seconds, from any point in the menu, and the player returns automatically back to the main menu.
- Page 7 You can switch between options by press the “F.FWD” or “F.REV” button “ ” or “ ”. Then press shortly on the “Menu” button to enter the submenu or confirm a function. 2.3 “Music” mode Select “Music” mode in the main menu. 2.3.1 Stop submenu Press "Menu"...
- Page 8 2.3.2 Play submenu During playback, press "Menu "button to enter "Play submenu “: Six options: - Repeat - Equalizer - Tempo Rate - Replay - Replay times - Replay gap - Exit 2.3.2.1 Repeat All songs are played once Normal Repeats the current song Repeat One Plays all the music of a specific folder...
- Page 9 2.3.2.2 Equalizer Seven options: - Natural - Rock - Pop - Classic - Soft - Jazz - DBB 2.3.2.3 Tempo Rate The music can be played faster or slower (only with MP3 files) Change the rate by Press “F.FWD” or “F.REV” button . 2.3.2.4 Replay mode A-B replay When replay mode is selected, the A-B icon is visible...
- Page 10 2.3.2.5 Replay times Here you are able to choose how many times (1-10) the A-B section Here you are able to choose how many times (1-10) the A-B section will be repeated. will be repeated. 2.3.2.6 Replay gap 2.3.2.6 Replay gap Choose the time( 1-10 sec) between each A-B section.
- Page 11 2.4.1 Record submenu In the Record mode, press menu button once 3 options: - Local folder - REC type - Exit 2.4.1.1 Local folder cfr 2.3.1.1 2.4.1.2 REC type Four options: - “Fine REC”: high quality recording, wav format, good quality. - “Long REC”: lower quality recording, act format, uses less space - “Fine VOR”: wav format - “Long VOR”: act format...
- Page 12 2.5 Voice mode In this mode you can listen to the recordi gs created in “Record mode” Select in the main menu "Voice mode ". 2.5.1 Voice stop submenu When playback is stopped, press “Menu” button to enter the Voice submenu. 2.5.1.1 Local folder (Stop submenu) cfr 2.3.1.1 2.5.1.2 Delete file (Stop submenu)
- Page 13 2.6 FM mode Choose in main menu "FM mode ". Press “Mode” button to enter 2.6.1 FM mode submenu In "FM mode " press "Mode" button to enter the FM submenu 7 options: - Save - Delete - Delete all - Normal band - Japan band - Fine rec...
- Page 14 2.6.1.1 Save (radio station) When searching a radio station manually, it can be stored with this function. Maximum 20 frequencies can be stored. 2.6.1.2 Delete broadcaster With this function, stored stations can be removed. 2.6.1.3 Delete all broadcaster With this function, all stored stations can be removed. 2.6.1.4 Normal band 87MHz –108MHz 2.6.1.5 Japan band...
- Page 15 2.7 Systems set up Select “System” in the main menu - Record Time - Backlight - Language - Power off - Replay mode - Contrast - Online Mode - Memory info - Animation - Logo - Firmware version - Exit 2.7.1 Record Time Enter here the correct date and time.
- Page 16 2.7.4 Power off - Off time With this function the device will automatically shut down after a preset time.(0-60sec), when no button is touched and music is not playing. If time is set at 0 seconds, the function is cancelled. - Sleeping mode With this function the device will always shut down after a preset time (0-120 min).
- Page 17 2.8 USB disk use The unit functions as a standard USB disk with most operating systems. - Windows98 (driver needed) - above Windows 2000 ( no need to install driver) When connected with PC(battery not needed), the device can be in 3 different modes - “wait”...
- Page 18 2.9 Specification (1) FLASH Memory 128MB, 256MB, 512MB, 1GB (2) music format MP3, WMA, WAV (3) liquid crystal display monitor 128× 32 lattices (4) Display Color 7color display (5) Languages English, French, Italian, German Spanish, Swedish, Dutch, Czech. (6) Power supply 3.8v Rechargeable Lithium battery (7) USB2.0 Read 1033K Byte/S...
