MPMan MP-FUB26 User Manual

Mpman mp-fub26: user guide
Hide thumbs Also See for MP-FUB26:

Advertisement

Quick Links

Download this manual See also: Setup Manual
Enlarged version
User's manual
MP-FUB26
MP-Ki
&
www.mpmaneurope.com
Before connecting, operating or adjusting this product please read these
instructions completely.

Advertisement

loading
Need help?

Need help?

Do you have a question about the MP-FUB26 and is the answer not in the manual?

Questions and answers

Related Manuals for MPMan MP-FUB26

Summary of Contents for MPMan MP-FUB26

  • Page 1 User’s manual MP-FUB26 MP-Ki & www.mpmaneurope.com Before connecting, operating or adjusting this product please read these instructions completely.
  • Page 2 ♠ Big display (128*32) LCD display ♠ Supports Firmware upgrade function ♠ Voice equalizer ♠ GUI (graphical user interfaces). The box: (1) MP3 player….…………………….. (2) Stereo earphone …………………… (3) CD ROM…………….. …………… (4) Manual…………………. …………. (5) USB cable ………….….………….. (6) Battery 1.5V/”AAA”…….………….
  • Page 3 1.1 The player interface (12) (11) (10) (13) REC A-B HOLD (14) (12 ) (11 ) (10 ) ( 1) ( 3) ( 4) (13) ( 8) ( 5) HO LD VO L (14 ) —— 3——...
  • Page 4 1.2 The buttons ” ⇒ OPEN/PLAY/PAUSE/STOP/POWER OFF (1) “ (2) “MODE” ⇒ Switch modes, menu selection by pressing on button (3) “ ” ⇒ NEXT/FWD (4) “ ” ⇒ PREV/REV (5) “VOL+”⇒Volume increase/fast increase (6) “VOL-”⇒Volume decrease/fast decrease (7) “HOLD” ⇒ Keyboard lock switch (8) “...
  • Page 5 2 Display and operating instruction 2.1 Turning on the MP3 player Push the “PLAY” button for several seconds. The LCD display will light up. 2.2 Main menu Four options: 1) MUSIC 2) RECORD 3) VOICE 4) SYSTEM You can switch between those 4 options by sliding the “MODE” button right “...
  • Page 6 Press “MODE” key to enter “MUSIC” mode. 2.2.1 Lyrics display synchronization The player supports LRC V0.2 format. It will show the corresponding lyrics synchronously with the playback. The LRC document should be identical with the name of the song. If no lyrics are available, it will show ID3 information.
  • Page 7 1. Natural 2. Rock 3. POP 4. Classic 5. Soft 6. Jazz 7. DBB Choose a sound effect by sliding the “MODE” button to the right “ ” 2.2.5 A-B replay mode The idea of this mode is to select a part of a song that will be repeated continuously.
  • Page 8 The selected section between point A and point B is repeated continuously. 2.2.5.2 Record A-B section After the replay from the A-B section, you can slide right “ ” to record your own voice. The microphone icon becomes visible. The record time is the same as the time of the A-B section.
  • Page 9 In Stop state, press the “MODE” button to exit recording mode and return to main menu. 2.3.4 De-noise record De-noise recording is the same as VOX recording, When using “VOX record”, the player enters into the state of “pause recording” if no sound is detected by the microphone.
  • Page 10 1. Music Dir 2. Record Dir 3. Exit Push “MODE” button to confirm. 2.5.2 Lyrics On & Off Select “2. Lyric” in the main menu of system setup and push “MODE” button to enter submenu. 1. Lyric On 2. Lyric Off Press “...
  • Page 11 2.5.6 Power off setting Select “6. Auto Off” in the main menu of system setup and push “MODE” button. Slide right “ ”or left “ ” to select and confirm with the “MODE” button. In Stop state, the device will power-off after setting time (max 60 sec) if nothing is touched during this period.
  • Page 12 Enter in next submenu with “MODE” button: 1. Delete One 2. Delete All 3. Exit If you choose “Delete one”, you’ll able to select a song. Confirm removal with “ ” button to delete If you choose “Delete All” detailed submenu shows: 1.
  • Page 13 WINDOWS2000/XP) must be installed prior to using the player. You can find driver software in the additional CD-ROM. A、Startup WIN98 operating system B、Insert CD-ROM into CD drive. C、Run the installation software. D、Restart the system. E、Insert the MP3 player into USB port of PC, the system will find the Portable-disk automatically.
  • Page 14 2.12 Upload and download removal of MP3 songs or other files After the MP3 player is connected to PC, the PC will identify the player as a “Portable (D :)” drive, hence the operating process for the MP3 player is the same as operating its own HD or SD.
  • Page 15 WAVE files with the attached software. Please install the software and follow the instructions. Chinese text By accident, the menu on MP3 player can be changed from English into Chinese. To change back to English, please follow these steps: Select page 4/5 by pushing the button left or right, press it once.
  • Page 16 FOR MORE INFORMATION AND UPDATES PLEASE VISIT www.mpmaneurope.com...

This manual is also suitable for:

Mp-ki
