MPMan MP-FUB 31 User Manual
  1. Manuals
  2. Brands
  3. MPMan Manuals
  4. MP3 Player
  5. MP-FUB 31
  6. User manual

MPMan MP-FUB 31 User Manual

Digital music player mp3&wma
Hide thumbs Also See for MP-FUB 31:

Advertisement

Quick Links

Download this manual
Enlarged version
DIGITAL MUSIC PLAYER
MP3&WMA
USER MANUAL
MP-FUB 31
www.mpmaneurope.com
___________________________________________________________________
Before connecting, operating or adjusting this product please read these
instructions completely.
- 1 -

Advertisement

loading
Need help?

Need help?

Do you have a question about the MP-FUB 31 and is the answer not in the manual?

Questions and answers

Related Manuals for MPMan MP-FUB 31

Summary of Contents for MPMan MP-FUB 31

  • Page 1 DIGITAL MUSIC PLAYER MP3&WMA USER MANUAL MP-FUB 31 www.mpmaneurope.com ___________________________________________________________________ Before connecting, operating or adjusting this product please read these instructions completely. - 1 -...
  • Page 2 ♠ Seven colors display ♠ Supports Firmware upgrade function ♠ Voice equalizer ♠ GUI (graphical user interfaces). Inside the box: (1) MP3 player (2) Stereo earphone one pair (3) Installation disk (4) User’s manual (5) USB cable (6) Battery 1.5V/”AAA”...
  • Page 3 The player appearance interface 1.2 The buttons ” ⇒ OPEN/PLAY/PAUSE/STOP/POWER OFF (1) PLAY “ (2) “REC” ⇒ Rec/A-B (3) “HOLD” ⇒ Keyboard lock switch (4) “VOL-”⇒Volume decrease/fast decrease (5) “VOL+”⇒Volume increase/fast increase (6) “ ” ⇒ NEXT/FWD (7) “ ” ⇒ PREV/REV (8) “MODE”...
  • Page 4 Push-button includes four operation methods as short push, long push, push and hold, single push. Display This player adopts big LCD of 128*32 lattice 2 Operating instruction 2.1 Turning on the MP3 player Push the “PLAY” button for several seconds. The LCD display will light up. - 4 -...
  • Page 5 2.2 Main menu Press the “MODE” button for several seconds, from any point in the menu, and the player returns automatically back to the main menu. Six options: 1) MUSIC 2) RECORD 3) VOICE REPLAY 4) FM 5) TELBOOK 6) SYSTEM Music Record Replay...

  • Page 6: Local Folder

    2.3 “Music” mode Select “Music” mode in the main menu. 2.3.1 Stop submenu Press "Mode" button once to enter the stop submenu. Four options: - Local Folder - Delete file - Delete all - Exit 2.3.1.1 Local folder 主盘目录 Local folder Files can be stored in different folders.
  • Page 7 2.3.2 Play submenu During playback, press "MODE "button to enter "Play submenu “: Six options: Repeat Equalizer Tempo Rate Replay Replay times Replay gap Exit 2.3.2.1 Repeat All songs are played once Normal Repeats the current song Repeat One Plays all the music of a specific folder Folder Repeats the music of a specific folder Repeat Folder...
  • Page 8 2.3.2.2 Equalizer Seven options: - Natural - Rock - Pop - Classic - Soft - Jazz - DBB 2.3.2.3 Tempo Rate The music can be played faster or slower (only with MP3 files) Change the rate by pushing the “Mode” Button left or right. 2.3.2.4 Replay mode - A-B replay When replay mode is selected, the A-B icon is visible...
  • Page 9 2.3.2.6 Replay gap Choose the time( 1-10 sec) between each A-B section. 2.3.3 Lyrics This MP3 player supports "*. lrc "Lyric files Lyrics can be downloaded from the internet. Make sure that lrc-file has the same name as the corresponding song.
  • Page 10 2.4.1 Record submenu In the Record mode, press mode button once 3 options: - Local folder - REC type - Exit 2.4.1.1 Local folder cfr 2.3.1.1 2.4.1.2 REC type Four options: - “Fine REC”: high quality recording, wav format, good quality. - “Long REC”: lower quality recording, act format, uses less space - “Fine VOR”: wav format - “Long VOR”: act format...
  • Page 11 2.5.1.1 Local folder (Stop submenu) cfr 2.3.1.1 2.5.1.2 Delete file (Stop submenu) 2.5.1.3 Delete all (Stop submenu) Deletes all files of the current catalog 2.5.2 Voice play submenu During playback, press “Mode” button to enter the Voice play submenu. 4 options: - Repeat - Tempo rate - Replay - Exit...
  • Page 12 2.6.1 FM mode submenu In "FM mode " press "Mode" button to enter the FM submenu 7 options: - Save - Delete - Delete all - Normal band - Japan band - Fine rec - Long rec - Exit Freq Mode Move mode button once left or right to change frequency with 0.1Hz.
  • Page 13 2.6.1.3 Delete all broadcaster With this function, all stored stations can be removed. 2.6.1.4 Normal band 87MHz –108MHz 2.6.1.5 Japan band 76MHz –96MHz 2.6.1.6 Fine REC type With this function music from a radio station can be recorded. Press “Mode” button to start recording. Press Mode button again to stop/save the recording.
  • Page 14 2.8 Systems set up Select “System” in the main menu - Record Time - Backlight - Language - Power off - Replay mode - Contrast - Online Mode - Memory info - Firmware version - Firmware upgrade Exit 2.8.1 Record Time Enter here the correct date and time.
  • Page 15 2.8.4 Power off - Off time With this function the device will automatically shut down after a preset time.(0-60sec), when no button is touched and music is not playing. If time is set at 0 seconds, the function is cancelled. - Sleeping mode With this function the device will always shut down after a preset time (0-120 min).
  • Page 16 2.9 USB disk use The unit functions as a standard USB disk with most operating systems. - Windows98 (driver needed) - above Windows 2000 ( no need to install driver) - Mac OS 10.3 and above - Linux 8.0 and above. When connected with PC(battery not needed), the device can be in 3 different modes - “wait”...
  • Page 17 2.10 Hold switch When "HOLD " switch is moved left, the other buttons are inactive and “Hold icon” will light up. 2.11 Specification (1) FLASH Memory 128MB, 256MB, 512MB,1GB (2) music format MP3, WMA, WAV (3) FM 76MHz– 96MHz / 87MHz– 108MHz (4) FM sensitivity 6dB (100MHz) (5) liquid crystal display monitor...
